VR1 VR2
U s e r M a n u a l
2
User Manual - EN
Thank you
We would like to thank you cordially for choosing this sE microphone! This manual contains some
important instructions for setting up and operating your new equipment. Please take a few minutes
to read the instructions below carefully. We hope you will enjoy working with it as much as we
enjoyed designing and building it for you.
Most Sincerely,
Your sE Team
Brief Description
The VR1 and VR2 ribbon microphones mark a new era in ribbon technology. Whereas most ribbon
microphones have a dark, muted high-frequency response, the VR1 and VR2 utilize a clever
mechanical device to achieve nearly full-range frequency response that extends well beyond that of
most other ribbon microphones, approaching nearly 20kHz. This provides an extended level of top-
end detail, so the result includes not only the distinctly natural low end and midrange that most -
ribbons provide, but also minimal loss in high frequency content. Guitar and brass tones retain their
“edge”, cymbals still sound rich and full, and a supremely natural sound is achieved from top to
bottom.
Additionally, the VR1 and VR2 can handle very high sound pressure levels and thus can be utilized
for applications not normally considered for most ribbon microphones, including loud brass, drums,
and electric guitar cabinets both in the studio and on stage.,
The VR1 is a passive ribbon, so it does not require phantom power – -though it is “phantom
protected”, so it will not be damaged by accidental application of phantom power. Given its lower
output, it is ideally suited for loud sources such as electric guitars, drum overheads, and brass.
The VR2 is an active ribbon and requires +48V phantom power for operation. higher sensitivity With
than the VR1, it is ideally suited for applications including acoustic instruments, piano, and vocals,
as well as the same sources as the VR1 (guitars, drums, brass).
What’s in the box
Your packaging should contain the follow items. If anything is missing, please contact your sE
Electronics dealer and let them know.
• VR1 / VR2 microphone
• m icrophone stand clip
• t t hread adap er
• wooden case
• shock mount
3
Powering - VR2 ONLY
To ensure proper operation, the VR2 microphone requires a phantom power source providing 48
Volts according to IEC 61938.
Risk of damage
Do not connect the VR2 microphone to any power supply other than a
phantom power source (input with phantom power or external IEC
standard phantom power supply) with a floating connector, using a
balanced cable with studio grade connectors to IEC 268-12 only. This is
the only way to ensure safe and reliable operation.
Note: The VR1 is a passive ribbon microphone and does not require phantom power for
operation.
Safety and maintenance
Risk of damage
Please make sure that the piece of equipment to which your microphone
will be connected fulfils the safety regulations enforced in your country
and is fitted with a ground lead.
Cleaning icrophone the m
After every use, clean the microphone with a dry, soft cloth tissue and store it in a solid case or a
zipper pouch.
Technical Specifications
VR1
VR2
Electronics
Passive
Active
Transducer
Hand-tensioned 2.5µm aluminum ribbon
Hand-tensioned 2.5µm aluminum ribbon
Magnet
Neodymium
Neodymium
Polar Pattern
Figure-8
Figure-8
Frequency Range
20 18,000 Hz–
20 18,000 Hz–
Sensitivity
1.78 mV/Pa ( 55 dB)-
14.1 mV/Pa ( 37- dB)
Electrical Impedance
300 Ohms
200 Ohms
Recommended Load
Impedance
>1k Ohms
>1k Ohms
Max SPL
135 dB (0.5% THD @ 1kHz)
135 dB (0.5% THD @ 1kHz)
Equivalent Noise Level
-
18 dB(A)
Dynamic Range
-
117 dB
Signal to Noise Ratio
-
76 dB
