Seite 1/2
Features
HDMI Male x1
Introduction
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• Main unit x1
• User Manual x1
• 5V DC power supply
1- Plug the Pigtail of the HDMI Splitter into HDMI source device.
2- Connect output devices to the outputs of the HDMI Splitter by using HDMI
cable. (HDMI cables are optional)
*please refer to the connection diagram section.
3- Insert the DC side of 5v power supply into it and then connect the AC side of
the power supply into the wall outlet.
This is a premium Rocstor HDMI Amplier Splitter is an HDMI splitter with two outputs.
It distributes the input of the HDMI signal into the two identical outputs simultaneous-
ly. It adopted pigtail type design to reduce cost and provide more convenience for
customers. It supports full 3D format and 4Kx2K. Its video amplier bandwidth can be
up to 3.4 Gpbs/340MHz.
This HDMI Amplier Splitter oers solutions for HDTV retail and show site, HDTV, STB,
DVD and Projector factory, noise, space and security concerns, data center control,
information distribution, conference room presentation, school and corporate training
environments.
HDMI Female x2
• Easy to Use: Install in seconds, no need of setting.
• One HDMI Input, two HDMI outputs
• Supports Full 3D and 4Kx2K resolution.
• Supports 340MHz/3.4Gbps per channel (10.2Gbps all channel)
bandwidth.
• Supports 12bit per channel (36bit all channel) deep color.
• Supports HDCP 1.4
Input:
Output:
Specication
Operation
Input / Output Connector
Operating Frequency
Maximum Single Link Range
Vertical Frequency Range 50/60Hz
Video Amplier Bandwidth 3.4Gbps/340MHz
Resolutions(HDTV)
Interlaced(50&60Hz) 480i,576i,1080i
Progressive(50&60Hz) 480p,576p,720p,1080p,4Kx2K
Input DC Signal
Output HDMI (with full 3D and 4Kx2K)
5 volts p-p (TTL)
Warranty 2 Year
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
0°C to + 45°C - (32°F to + 113°F)
10% to 90 % RH (no condensation)
-10°C to + 70°C - (14°F to + 158°F)
10% to 90 % RH (no condensation)
Regulatory Approvals
Certications
Power Requirement
External Power Supply DC 5V/1A
Power Consumption 2.1W
Mechanical
Size(L-W-H) 63x54x18mm - (2.4”x2.1”x0.7”)
Weight(Net) 167gr - (5.90oz)
Accessory
User Manual English Version
AC Power Adapter US standard, UK standard and so on
FCC, CE
4K x 2K
®
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
1x2 4K 30Hz HDMI® 2-Port Video Splitter
Includes Power Adapter - Black
User Manual
Y10A235-B1
Technical Support / RMA
Hours: 9:00 am - 5:00 pm PST
Monday to Friday (except holidays)
Tell: +1 (818) 727-7000
( )National and international
Fax: +1 (818) 875-0002
Email: support@Rocstor.com
Support
Warranty Information
Technical support is available to all the registered users of Rocstor products.
Connection Diagram
Safety Information:
©2021 Rocstroge, Inc. All rights reserved. Rocstor is registered trademark of Rocstorage, Inc.
Apple®, the Apple logo, Mac®, MacBook®, MacBook Pro®, MacBook Air®, iPad®, iPad Air®, iPad mini®,
iPad Air®, iPhone®, MacOS® are registered trademarks of Apple, Inc. Google® and Chromebook™ are
registered trademarks of Google, LLC. Microsoft® is registered trademarks of Microsoft corporation. Al
other product names and logos mentioned herein may be trademarks of their respective companies.
Thunderbolt is a trademark of Intel Corporation or its subsidiaries. USB Type-C® and USB-C® are
registered trademark of USB Implementers Forum. Feature and specication are subject to change
without notice. All trademarks and registered trademarks are the property of their respective. All
rights reserved.
HD TV HD TV
WARNING: Please follow these safety instructions. Failure to do so may result damages or injury.
It is normal that the Rocstor adapter becomes very warm during use.
Please note that:
continuous contact with warm surfaces for extended time may cause discomfort or injury. In order to
reduce the possibility of overheating or heat-related injuries, always allow needed ventilation around
the Rocstor adapter and use care when handling it. Avoid instances where your skin is in extended
contact with the hub when plugged into the host computer. It is not recommended to sleep with the
adapter when plugged into a host computer. Avoid placing the hub adapter under a pillow, blanket,
or your body when connected to a host computer. If you have a medical condition that aects your
ability to detect heat against the body, extra care should be used. Never use the adapter in locations
with water, such as a sink, bathtub, or shower stall. Never connect or disconnect the adapter with wet
hands.
!
Limitation of Liability
In no event shall the liability of Rocstorage, Inc. and Rocstor (or their ocers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or
otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of
the product exceed the actual price paid for the product. Some states do not allow the exclusion or
limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
Warranty Information
This product is backed by a (2) two-year warranty. Rocstor warrants its products against defects in
materials and workmanship for the periods noted, following the initial date of purchase. During this
period, the products may be returned for repair, or replacement with equivalent products at our
discretion. The warranty covers parts and labor costs only. Rocstor does not warrant its products from
defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
