Seite 1/2
ENGLISH
PowerWalker VI 600-3000 SCL
Quick Guide
Back Panel:
PowerWalker VI 400-800 SCL
PowerWalker VI 1000 SCL
PowerWalker VI 1500-2000 SCL
A. Output sockets
B. AC input
C. Fuse / circuit breaker
D. USB port with HID support
E. Ethernet line surge protecon
F. Cooling fan (only for 1500-3000 VA
models
PowerWalker VI 3000 SCL
1. Output sockets
2. AC input
3. Circuit breaker
4. Ethernet line surge protecon
5. RS232 port
6. USB port
Usage:
You can turn on and turn oî…ş the unit by pressing the power switch.
Models in the range 400-2000 VA have touch display. You can change
the display content by touching it. If the backlight shuts oî…ş, you may
acvate it by touching the screen.
PowerWalker VI 3000 SCL does not have touch display, all available
data are shown on the screen.
Display:
UPS
Mode
VI 400-2000 SCL
touch display
V I 3000 SCL
display
Descripon
Power on
When UPS is powered on, it will enter this
mode for few seconds.
Standby
Mode
No output is provided.
ENGLISH
Line
Mode
The screen displays output voltage, input
voltage, load level and baery capacity.
AVR
Mode
blinks
blinks
Voltage regulaon acvated
Overload
blinks
blinks
When overload occurs, alarm will beep
every 0.5s
Baery
Mode
blinks
blinks
Output voltage is generated from the
baery. Alarm will beep every 10s.
Troubleshoong
Fault Code
Fault condion
Soluons
or F03 or F05
Internal Error
Alarm will connue beeping. Contact technical
support.
F01 / F02
Output short-circuit
/ overload
Disconnect the loads and restart the UPS.
F04 or beeping every 2s
Weak baery
Please replace the baery.
F06
Over-temperature
Turn o the unit wait unl it cools down and ,
change to a beer venlated environment.
Specicaons
Model
VI SC SeriesL
Input
Voltage
230 VAC
Voltage Range
162-290 VAC
Frequency Range
60/50 Hz (Auto Sensing)
Output
Voltage Regulaon
+/- 10%
Transfer Time
Typical 2-6 ms
Waveform
Simulated Sine Wave
Protecon
Overload, discharge, and overcharge protecon
Humidity
0-90 % RH @ 0-40° C (non-condensing)
Noise Level
Less than 40 dB
Model
VI 400 SCL
VI 600 SCL
VI 800 SCL
VI 1000 SCL
VI 1500 SCL
VI 2000 SCL
VI 3000 SCL
Power
Capacity
400VA
240W
600VA
360W
800VA
480W
1000VA
600W
1500VA
900W
2000VA
1200W
3000VA
1800W
Baeries
4.5Ah x 1
7Ah x 1
9Ah x 1
7Ah x 2
9Ah x 2
9Ah x 2
9Ah x 2
Charging
6 hours recover to 90% capacity
6-8h to 90%
Dimension
(DxWxH)
300mm x 101mm x 142mm
320mm x 130mm x 182mm
3 x 1 205 97 46 x
Net weight
3.7 kg
4.4 kg
5.0 kg
8.2 kg
10.4 kg
11.0 kg
11.5 kg
