1
L.O.C.PRO™ LPGL-2
Universal Ground Loop Isolator
Installation Instructions
The professional way to eliminate noise
General Overview
Install It Right with L.O.C. PRO™
Don’t cheat yourself out of all the performance your audio system can deliver. Noise is the enemy, but we don’t
want to sacriîšżce audio quality to eliminate it. The PAC L.O.C.PRO
™ Universal Ground Loop Isolator will eliminate
that unwanted alternator “whine” or ignition "ticking" while retaining the original audio quality from bass to treble.
This universal module works with standard RCA connections commonly found in car audio or 3.5mm headphone
style audio cables for use with smartphones or portable media players. PAC L.O.C.PRO
™ interfaces have been
professionally designed for those who want the very best.
The L.O.C.PRO™ LPGL-2 can be utilized for minimizing or eliminating noise in either RCA or 3.5mm applications.
Utilizing precision transformers to break ground loop potential while retaining full audio îšżdelity. The L.O.C.PRO
™
LPGL-2 is easy to install and features a compact housing for expanded mounting options. Inputs are reversible
for installation at source unit or at ampliîšżer.
RCA Level Input - Output
Commonly used to solve noise problems in car audio systems.When utilizing the L.O.C.PRO
™ LPGL-2 for RCA
input/output connect the male and female adapters to the LPGL-2. These can be reversed if connecting at the radio
or the ampliîšżer. Most applications will not require connection of the ground wires. If noise is still present, on a clean
grounding point, try temporarily connecting one ground at a time. Then alternating between the two and îšżnally
connecting both. Test the system and permanently make the connections with the best sounding conîšżguration.
Mount the LPGL-2 using wire ties, screws or double tape.
Copyright 2013 Paciîšżc Accessory Corporation. Content subject to change without notice.
Output
Input
Audio Ground Input -
Audio Ground Input -
(OPTIONAL
)
(OPTIONAL
)
Input and Outputs are
reversible for use at radio
or ampliîšżer
2
Paciîšżc Accessory Corporation
Santa Ana, CA 92705
techsupport@pac-audio.com • www.pac-audio.com
Copyright 2013 Paciîšżc Accessory Corporation. Content subject to change without notice.
3.5mm Audio to 3.5mm Audio
Commonly used when using a Smartphone as a 3.5mm audio input and noise enters phone through the phone
charger. When utilizing the L.O.C.PRO™ LPGL-2 for 3.5mm input/output disconnect the original 3.5mm cable and
connect it to the input of LPGL-2. Then connect the included 3.5mm output cable to the original input point and the
output from the LPGL-2. Most applications will not require connection of the ground wires. If noise is still present,
on a clean grounding point try temporally connecting one ground at a time, alternating between the two and îšżnally
connecting both. Test the system and permanently make the connections with the best sounding scenario.
Mount the LPGL-2 using wire ties, screws or double tape.
Audio Ground Input -
Audio Ground Input -
3.5mm Input / Output
(
OPTIONAL)
(
OPTIONAL)
Input
Output
3.5mm Audio to RCA Audio
When utilizing the L.O.C.PRO™ LPGL-2 for 3.5mm input to RCA output disconnect the original 3.5mm cable and
connect it to the input of LPGL-2. Then connect the included 3.5mm to RCA adapter to the LPGL-2 output and the
RCA cable input. Most applications will not require connection of the ground wires. If noise is still present, on a clean
grounding point try temporally connecting one ground at a time, alternating between the two and îšżnally connecting
both. Test the system and permanently make the connections with the best sounding scenario.
Mount the LPGL-2 using wire ties, screws or double tape.
Audio Ground Input -
Audio Ground Input -
(
OPTIONAL)
(
OPTIONAL)
Input
Output
Choose for your
application.
Note: Only One 3.5mm cable is included with interface
