CANPRO Harness
for Select Tesla Vehicles
CP1- TSL1
Output 8 Pos. 250mA
Output 7 Pos. 250mA
Output 6 Pos. 250mA
Output 5 Pos. 250mA
Output 4 Pos. 250mA
Output 3 Speed Pulse
Output2 Pos. 250mA
Output1 Pos. 250mA
Output 9 Neg. 250mA
The CP1TSL1 is a factory matched plug & play harness for use with the CANPRO CP1-S CAN-Bus Interface Module for
Tesla Model 3 and Model Y applications using the 26pin data harness. The harness and module allow a simple and safe
way to access vehicle information, status and triggers from the CAN-Bus for a wide range of aftermarket uses such as
radar detectors, camera activation, sound system upgrades, lighting and more!
Introduction and Features
Important Notes
1. Any unused outputs should be insulated to prevent shorting.
2. The outputs of the CANPRO are low current (250mA) and require the use of a separate relay if additional current is required.
3. The vehicle should be in a resting state prior to opening connection to the 26pin data harness. See Installation note for further
information.
Wiring Connection Chart
Outputs
To Factory
Harness
To Factory
Harness
Description
Description
Description
Description
Description Polarity
Polarity
Polarity
Polarity
Polarity Wire Color
Wire Color
Wire Color
Wire Color
Wire Color
Output 1 Accessory + Positive (250mA) White-Red
Output 2 Illumination + Positive (250mA) Blue
Output 3 Speed Pulse Pulse Green-Black
Output 4 Reverse + Positive (250mA) Violet-Black
Output 5 Ignition* + Positive (250mA) Yellow-Black
Output 6 Left Turn Signal + Positive (250mA) Red-Black
Output 7 Right Turn Signal + Positive (250mA) Gray-Red
Output 8 High Beam + Positive (250mA) Blue-Black
Output 9 Parking Brake - Negative (250mA) Brown-Black
Output Wires
1-9
DIP Switches
16pin
Interface
Connector
Status
LED
CANPRO CP1-S
* In Electric Vehicles, Output 5 provides a positive output when the vehicle is in a “Ready to Drive” state.
© 2023 AAMP Global. All rights reserved. PAC is a Power Brand of AAMP Global.
PAC-Audio.com
C
Page 2
Rev: V1
Date: 021323
CANPRO Harness
for Select Tesla Vehicles
CP1- TSL1
Installation
1. Set the DIP switches on the CP1-S as shown in below.
2. Access the vehicle's CAN data harness by removing the
panel located at the rear of the center console. (FIG A)
3. To remove the console end panel, pull out (towards rear
of vehicle) along the bottom edge to release the lower
retaining clips and then pull out along the top of the panel
to release the upper retaining clips.
4. Ensure the vehicle is (Refer to NOTE at the Powered O󰀨
top of the page) and unplug the 26pin CAN data harness.
(FIG A)
5. Connect one end of the CP1-TSL1 harness to the matching
connector in the vehicle. Connect the remaining vehicle
connector from the CP1-TSL1 to the other end of the
vehicle harness. (FIG B)
6. On the passenger side of the center console, unclip the
side trim panel. (FIG C)
7. Route the CP1-TSL1 16pin interface connector from the
rear of the console to the passenger side of the console.
8. Determine a mounting location for the CP1-S module and
connect the 16pin connector to the module.
9. Lengthen and route any Output wires needed. Insulate any
unused Output wires!
10. After wire connections and testing are complete, secure the
CP1-S module and reinstall the console panels.
1 2 3 4 5 6 7 8
ON
FIG A
FIG B
FIG C
NOTE! Before and during installation, ensure the vehicle is in the Power Off status (Controls > Safety > Power Off).
Do not press the brake pedal, touchscreen or wake-up the vehicle until installation is complete. If the radio display turns
back on prior to unplugging the 26pin data harness, repeat the Controls>Safety>Power Off cycle prior to unplugging.
© 2023 AAMP Global. All rights reserved. PAC is a Power Brand of AAMP Global.
PAC-Audio.com
C
Page 3
Rev: V1
Date: 021323
CANPRO Harness
for Select Tesla Vehicles
CP1- TSL1
LED Status Information
ACTION/COLOR
ACTION/COLOR
ACTION/COLOR
ACTION/COLOR
ACTION/COLOR Description
Description
Description
Description
Description
Fast Flashing RED Update mode, for updating of the application or resource îšżles.
Slow Flashing (0.5sec) GREEN Normal Operation
Slow Flashing (0.5sec) GREEN,
plus additional 0.5sec RED
System Fault. The number of times the interface ashes RED indicates the chan-
nel (output) with a fault condition. For example, if the LED ashes GREEN, then
ashes RED twice, then back to Green, Channel 2 has a fault condition.
To check the fault, see Troubleshooting section below.
Troubleshooting
1. No LED activity: Disconnect and reconnect the CP1-S, does the LED ash? If not, check the 3 amp fuse in the fuse-holder
that is located 2 inches from the 16pin connector on the Yellow wire.
2. No Outputs: Verify the DIP switch setting is correct (Installation section, FIG A). If the DIP switch setting needs to be changed,
unplug the CP1-S, change the DIP setting and then reconnect. If the LED is ashing green, test the outputs using a multimeter.
If the multimeter is showing the proper output, add a relay to the output to increase current capability.
3. System Fault: Disconnect the faulty output (1-9), disconnect and reconnect the 16pin connector to the CP1-S so that it loses
and gains back power and ground, does it stop ashing red? Check wiring to faulty output to make sure it is not shorted to
ground, or add a relay.
Technical Support
Email: support@PAC-audio.com
Phone: 727-592-5991
Chat: PAC-Audio.com
