INSTRUCTIONS AND PARTS LIST H AIRBRUSH 8/06/2019
H Model Airbrush
Single Action–External Mix–Siphon Feed
Instruction Manual & Replacment Parts
OPERATING INSTRUCTIONS:
Approximate Working Pressures:
• 20lbs.orLess:Stippleandgranulatede󰀨ects,pressurewillvarywithviscosityofuid.
20to30lbs.:Mediumconsistencywatercolors,inks&dyes.
30 lbs. or More:Heavyuids,acrylics,reducedlacquers,varnishes,paintsorceramicglaze.
Sizes:
• H-1(.45mm)HeadandHC-1-3Aircapforlightuids.
• H-3(.64mm)HeadandHC-1-3Aircapformediumuids.
• H-5(1.06mm)HeadandHC-5Aircapforheavieruids.
1.Attach hose to airsupplyand allow airto blow afew seconds. Shut o󰀨 beforeattaching to Airbrush. This procedurewill
removedirtfromairlineandhose.
Caution: Hold rmly and point away from face.
2. Attachhosecouplingtotheairbrush.
3.AttachColorCuporBottletoHN-1-3,or5Needlebyexertingarmtwistingmotiontottaperedtubesecurelyintotapered
Needleinlet.
4. FillColorCuporBottle1/2to3/4full.Useeyedropperorbrushforaddingsmallamountsofcolortometalcolorcup.Whenusing
ColorBottle,ventholemustbekeptopen.
5.ToSpray,holdAirbrushlikeapencilcomfortablybetweenthumbandforengerusingmiddlengerasaguideandsupport.
Likewriting,holdforengereasilyonH-155FingerButtonandPresstoopenairvalve.
6.Regulate volume of color and size of spray by rotating HT-1,3 or 5 Tipclockwise to increase andcounter clockwise to
decreaseowofcolor.
7.StippleAdjustment:Reducingtheairlinepressureistheeasiestmethodusedwhencreatingastipplede󰀨ectwiththeairbrush.
Pressurecanbereducedbyusinganyofthefollowingitems:3ANeedleValveinstalledontheH-128AValveCasingofthe
AirbrushorbyusingtheR-75AirRegulatorandreducingthepressure.
8.Toadjustforheavieruids,turntipwideopen,loosensetscrew,slideneedlebacktoobtainbetterow.
CARE AND CLEANING:
1.Pouranyremainingcolorbackintoitsoriginalcontainer.
2.WipeColorCuporBottleclean,usingclothmoistenedwithpropersolvent.
3.HoldAirbrushatadownwardangleandputafewdropsofsolventthroughColorAdjustingPartAssembly.Toushoutthe
remainingcolorintheHColorAdjustingPartAssembly,applypressuretothe H-155FingerButton.
4. ApplyatinydabofVaselinetotheHColorAdjustingPartandHC-Aircapthreadseverytwoorthreemonthstopreventcolor
buildupandconsequentfreezingoftheColorAdjustingPartAssemblyandAircap.
HOW TO OPEN CLOGGED FLUID PASSAGES:
1.AgitatecolorinBottleAssemblybyplacingngermomentarilyoverHC-AircapwhileairispassingthroughtheAirbrush.This
willblowcolorbackintobottlethusopeningcloggeduidpassages.Do not do this with open cup as color may blow out
of cup.
2.ShouldH-1,3or5ColorAdjustingPartAssemblybecomeclogged,loosenH-153SetScrew,unscrewHT-1,3or5Tipfrom
HNNeedle,gentlypullbackthroughball-shapedsupportandremoveTip.
3.CleanPartscarefully,usingnothingharderthanawoodentoothpick.
4. Toreassemble,reversethisprocedure,makingsuretheshoulderoftheNeedleseatsupagainstball-shapedsupport.
5.Iftheneedleandtiparecompletelyclogged,soakinaclosedbottleofpropersolventuntilclean.
INTRODUCTION:
Paasch H model Airbrush features machined Brass Body and Nickel
SilverColorPart, simplicityofdesign andeaseinoperation.Theair and
colorfeeds are independentand adjustable togive axed line, shadeor
stipplee󰀨ect.
For Multi-Language Manuals Go To: www.paascheairbrush.com
2
H - AIRBRUSH MODEL REPLACEMENT PARTS
# Part No. Description
1. HC-1-3,5  Aircapw/O-ring(SelectSize)
2. 3A-4  “O”Ring(Packof6)
3. H-1,3,5  ColorAdjustingPart(SelectSize)
4. HT-1,3,5  Tip(SelectSize)
5. H-185  Packing
6. H-184  PackingNut
7.  Needle(SelectSize)HN-1-3,5
8.    SetScrewH-153
9. H-150N  Shell(IncludesH-128A)
10. H-155  FingerButton
11. H-143  Handle(Nylon)
12. HVL-200 Metal Handle (Aluminum - optional)
14. H-128A  ValveCasing
15. H-192A  ValvePlungerw/A-53
16. A-53  ValveWasher(Packof6)
17.   ValveSpringA-22
18.  AirValveNutA-23R
19. F-186  Wrench
20. A-34 Hanger
H-OldStyleReplacementParts
22. H-175A AirValveAssembly
23. A-23R AirValveNut
24. A-22  ValveSpring
25. H-21A ValvePlunger
26. A-52  ValveWasher(Packof6)
27. H-128A ValveCasing
28.   NeedleGuideSpringA-143
29. H-156 Stipple Adjuster
30. H-157  FingerLeverAssembly
Old Style Replacement Parts
H-1/4-OZ
(1/4oz Metal)
H-3-OZ
(3oz Glass)
H-1-OZ
(1oz Glass)
HP-3-OZ
(3oz Plastic)
H-2-OZ
(2oz Metal)
A-1/8-4, 6, 8. 10, 15, 20, 25 or 50
Braided Air Hose with couplings (Select Length)
(3A-4 -- O-ring for airbrush coupling)
WARNING: Spraymaterialsmaybe harmfulifinhaledor
allowedtocomeintocontactwiththeskinoreyes.Consult
theproductlabelandMaterialSafetyDataSheetsupplied
for the spray material.  Follow all safety precautions.
CAUTION: Well Ventilated Area Required to remove
fumes,dustoroverspray.Maximum Air Pressure 75 P.S.I.
HP-8-OZ
(8oz Plastic)
BA-30-3P
(3oz Plastic)
BA-30-1P
(1oz Plastic)
BA-30-4P
(3oz Plastic)
BA-30-2P
(1oz Plastic)
e BA bottle assemblies are a new cover conguration and all use plastic
bottle. e 2P and 4P are narrow neck and work with most airbrush paint
bottles like Createx and Paasche
For Multi-Language Manuals Go To: www.paascheairbrush.com
