INTRODUCTION:
e SI Airbrush is simple in design and operation. Ideal for Hobbyists and Craers that are just learning to use an Airbrush. Available
o the shelf as size #3 with size #1 and #5 components available for your assembly. PTFE Packings.
OPERATING INSTRUCTIONS:
Adjustments in the ow of color are made by turning the Needle Chuck (#9) in to decrease, or out for increased ow. To spray,
press the Trigger (#6). To disassemble, loosen the Needle Locknut (#10) by holding the Needle Chuck (#9) rmly so it will not turn.
Unscrew the Needle Chuck from the Handle (#7) and remove the Handle. Now carefully remove the Needle (#16) and then the
Finger Button Assembly. e Head (#2) and Tip (#3) may now be removed. Reassembly should always be done with care, especially
when reinserting the Needle. Reverse the procedure used for disassembly. Aer the Needle has been gently pushed forward into
the tip, assemble the Needle Chuck (#9) and screw it in rmly. Hold the Needle Chuck while screwing the Needle Locknut (#10)
down to lock the needle. Caution should always be used when reinserting the Needle - too much pressure can damage the tip.
ADJUSTING OR REPLACING WORN PACKING WASHER:
1. If PTFE Packing & Packing Nut (#5) become worn or loose they must be tightened or replaced.
2. When replacing your PTFE Packing press Packing into the Packing Nut (#5). Use a small screwdriver to tighten packing nut
into shell until it is tight then back out one-half turn, may vary.
3. Now insert Trigger then Needle - you should feel a slight resistance to the needle as it goes through packing. If too loose/tight
adjust the Packing Nut with screwdriver until some slight resistance. Replace the Needle Chuck and the Needle Locknut.
Head Sizes - Patterns - Fluid Thickness
Size 1 - Tip size .022 inches or .55mm
- Used for ne detail. Pencil Line to 1’’ patterns
- Paint must be thinned further than 3 & 5 heads
Size 3 - Tip size .029 inches or .73mm
- Less detail than the size 1 head. 1/32’’ to 1-1/2’’ patterns
- Can spray slightly thicker paint than size 1 head
Size 5 - Tip Size .042 inches or 1.06mm
- Less detail than the size 3 head. 1/16’’ to 2’’ patterns
- Can spray slightly thicker paint than size 3 head
Working Pressures:
Operating pressures 20-55 PSI; Maximum pressure 75 PSI
20-30 PSI is best for detail spraying w/ properly thinned paint
Use the higher pressures for thicker material where ne detail is not critical or thin the paint to allow lower pressures.
Equipment Set-up:
e Airbrush is held in the same manner as a pen, with the index nger comfortably over the Trigger.
1. Attach airhose to air supply and to airbrush. If using a regulator, set pressure between 20 -30 PSI.
2. Attach the color cup or bottle assembly to color socket.
3. Spray with needle protecting cap #1 on or remove it for ner detail spraying.
TROUBLESHOOTING:
Bubbling in cup:
1. VLH Head #3 needs to be wrench tightened
Skipping or spitting:
1. Paint too thick -Reduce with thinner
2. Tip not seated -Tighten VLH Head with wrench
3. Tip split or damaged needle -Replace tip or needle
4. Needle or tip dirty -Clean and replace
5. Air pressure too low -Increase pressure or thin paint further (need 20 or more PSI to spray most paints)
Airbrush not spraying:
1. Clogged tip -Remove tip and clean
2. Needle not retracted -Adjust back knob
3. Loose VLH Head -Wrench tighten
4. Low air pressure -Increase pressure (need 20 or more PSI to spray most paints)
5. Bottle vent hole plugged -Use needle or pin to clear air hole
Sprays double line or heavy to one side:
1. Split tip or bent needle - Replace
2. Dirty tip or needle - Remove and clean
3. Tip not centered in head - Remove head and clean airbrush seat and tip seat then reassemble. Use wrench for head
INSTRUCTIONS AND PARTS LIST SI-8/06/2019
SI Airbrush
Double Action - Internal Mix
Siphon Feed
Paasche® model SI features hand crafted
construction using quality materials. The body
is machined brass, polished and chrome plated.
Fluid tips are nickel silver, needles are stainless
steel & the needle packing is PTFE. Preferred
by professional and hobbyist alike.
Paasche Airbrush Co. 9511 58th Place Kenosha, WI. 53144 Phone:773/867-9191 Email: info @ paascheairbrush.com
2.
Printed in the USA
No. Part No. Description
1. XI-41 Needle Protecting Cap
2. VLH-1, 3 or 5 Head
3. VLT-1, 3 or 5 Tip (.022’’ - .029’’ - .-042’’)
4. SA-210A Shell Assembly
5. MU-612 PTFE Packing & Packing Nut
(sold as set)
6. SI-10 Trigger
7. SI-9 Handle
No. Part No. Description
8. 3A-4 “O” Ring
9. SI-7 Needle Chuck
10. SI-8 Needle Locknut
11. MIL-9 Valve Casing
12. VL-214 Valve Plunger (with A-53)
13. A-53 Valve “O “ Ring (pack of 6)
14. A-22 Air Valve Spring
15. A-23R Air Valve Nut
16. SIN-1, 3, or 5 Needle
VL-1/4-OZ
(1/4oz Metal)
VL-3-OZ
(3oz Glass)
VL-1-OZ
1oz Glass)
VLP-3-OZ
(3oz Plastic)
VL-2-OZ
(2oz Metal)
VLP-8-OZ
(8oz Plastic)
BA-60-3P
(3oz Plastic)
BA-60-1P
(1oz Plastic)
BA-60-4P
(3oz Plastic)
BA-60-2P
(1oz Plastic)
e BA bottle assemblies are a new cover conguration and all
use plastic bottle. e 2P and 4P are narrow neck and work with
most airbrush paint bottles like Createx and Paasche
WARNING: Spray materials may be harmful if inhaled or
allowed to come into contact with the skin or eyes. Consult
the product label and material safety data sheet supplied for
the spray material. Follow all safety precautions. CAUTION:
Well Ventilated Area Required to remove fumes, dust or
overspray. Maximum Air Pressure 75 P.S.I.
For Multi-Language Manuals o o: www.paascheairbrush.comg t
