Seite 1/6
10M
CROSS LINE LASER
10M
CROSS LINE LASER
CROSS LINE
LASER
10M RED
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 3V DC (2 x AA Batteries)
Working Range: 10m
Accuracy: ±0.5mm/m
Self Levelling Time: <5s
Self Levelling Range: ±3°
Laser: Class II, <1mW
Laser Wavelength: 635nm (Red)
Battery Life: 16h
Weight: 0.4kg
LCL-10R
STANDARD EQUIPMENT
3 YEAR REPLACEMENT WARRANTY*
Your product is guaranteed for a period of If 36 months from the original date of purchase.
a product is defective it will be replaced in accordance with the terms of this warranty. Warranty
excludes consumable parts, for example: valve adapters and accessories.
*This product is intended for DIY use only and replacement warranty covers domestic use.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other than that specified on the tool.
• If the tool shows signs of damage or defects caused by or resulting from abuse, accidents
or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
WARRANTY
Ozito Industries Pty. Ltd. 25 Fox Drive, Dandenong South, VIC 3175, Australia.
ozito.com.au
Cross Line Laser
Multi-Axis Clamp & 2 x AA Batteries
0123
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY
YOU MUST RETURN THE PRODUCT TO YOUR NEAREST
BUNNINGS WAREHOUSE WITH YOUR BUNNINGS
REGISTER RECEIPT. PRIOR TO RETURNING YOUR
PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR
CUSTOMER SERVICE HELPLINE:
Australia: 1800 069 486
New Zealand: 0508 069 486
The benefits provided under this warranty are in addition to other rights and remedies which
are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this warranty,
however, where you have suffered any additional direct loss as a result of a defective product
you may be able to claim such expenses by contacting our customer service helpline above.
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE
THE MODEL NUMBER AND DATE OF PURCHASE
AVAILABLE. A CUSTOMER SERVICE REPRESENTATIVE
WILL TAKE YOUR CALL AND ANSWER ANY QUESTIONS
YOU MAY HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
10M
CROSS LINE LASER
Installing Batteries
1. Pinch the sides of the battery cover
and pull it off the laser unit.
2. Insert two AA batteries.
Follow the markings in the
battery slot for the proper
orientation.
3. Pinch the battery cover and
push it back onto the unit.
Mounting The Laser
1. Hold the thread ring on the
multi-axis clamp and screw
the laser onto the thread.
Note: The laser comes with a ¼” thread slot, making it compatible
with most universal camera mounts and stands on the market.
2. Rotate the clamping screw
anti-clockwise to loosen the
clamping jaws.
3. Place the jaws around the
desired mounting surface.
4. Rotate the clamping screw
clockwise to lock the clamp
in place.
1. Pendulum Lock
2. Indicator LED
3. Power Button
4. Battery Cover
5. Clamping Screw
6. Clamping Jaw
7. Adjustment Screw
8. Thread Ring
9. Laser Lens
CROSS LINE LASER
KNOW YOUR PRODUCT
1. ASSEMBLY
SETUP & PREPARATION
10M
CROSS LINE LASER
10M
CROSS LINE LASER
10M
CROSS LINE LA SER
10M
CROSS LINE LASER
CROSS LINE
1
5 6
789
4
2
3
ONLINE MANUAL
Scan this QR Code with your mobile
device to take you to the online manual.
Using The Auto-Levelling Function
1. To switch on the laser, slide the
pendulum lock up to the unlock position.
Note: Remove the filament tape when
using the tool for the first time.
2. If the laser cross is within ±3°
of horizontal, the laser will
automatically self-correct, and
the indicator LED on the top will
turn green.
If there is more than a 3° tilt
on the laser, the cross line
will flash intermittently. The
indicator LED will also turn
red.
3. To switch the laser off, slide the
pendulum lock down to the lock position.
WARNING! ENSURE THE PENDULUM LOCK IS IN THE
‘LOCK’ POSITION AND THE LASER IS SWITCHED OFF
WHEN NOT IN USE.
Adjusting The Clamp
1. Loosen the adjustment
screw slightly.
2. Move to laser and mounting
arm to the desired position.
Note: The mounting arm has
2 ball joints, allowing the laser
position the be adjusted in a
range of directions.
3. Tighten the adjustment
screw to lock it in place.
2. ADJUSTMENTS 3. CONTROLS
OPERATION
10M
10M
CROSS LINE LASER
10M
CROSS LINE LASER
