Seite 1/8
©COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Metraonline.comMetra Electronics Corp. ®REV. 10/20/2020 INSTJP-JLKT
Attention! When testing the aftermarket
equipment, ensure that all factory equip-
ment is connected before cycling the key to
ignition.
JP-JLKT
INSTALLATION INSTRUCTIONS
Camera Removal ................................................ 2-4
Assembly 5 ................................................................
Wiring 6 .....................................................................
Specifications 7 .........................................................
TABLE OF CONTENTS
TOOLS REQUIRED
• 3/16 Allen bit
• Phillips bit
• Reciprecating saw or other cutting device
Jeep Wrangler JL 2018-UP*
Replacement Camera Kit
*Visit Metraonline.com for more detailed informatuon about the product and up-to-date vehicle specific
applications.
Part Components
A) Camera B) Housing Front/back C) Harness and Hardware
A B C
Product Features
• Designed to replace the LVDS camera on Jeep Wranglers
• Direct OE replacement
• ABS housing
• Resolution: 500 TV lines
• Viewing Angle: 160 degrees
386-257-1187
|
Metraonline.com
2
1. Remove the interior panel. It is held on with
panel clips. (Figure A)
2. Disconnect the two connectors shown. (FIg-
ure B) Pop out the grommet behind these
two connectors and run the harness outside.
This will allow easier access when removing
the spare tire mount from the vehicle. Retain
this harness as it will still be needed for the
third brake light.
Figure A Figure B
CAMERA REMOVAL
REV. 10/20/2020 INSTJP-JLKT 3
1. Remove the bolts holding the tire
onto the back of the tailgate.
2. To remove the camera it is easiest to
remove the spare tire mount from
the tailgate. Remove the four 14mm
bolts from the mount to remove it
from the tailgate. (Figure A)
3. Disconnect any wiring and remove
the mount from the tailgate. Re-
move the two T-25 torx to release
the camera mount from the spare
tire mount. (Figure B)
Figure A Figure B
CAMERA REMOVAL (CONT.)
