Installation Guide
Desktop Switch
* MS108 is used for demonstration in this guide.
Images may dier from actual product.
Connection Diagram
Connect the hardware according to the connection diagram.
FAQ (Frequently Asked Questions)
A1: Make sure that the cable connectors are firmly plugged
into the switch and the device.
A2: Make sure the connected device is turned on and working
properly.
A3: The cable must be less than 100 meters long (328 feet).
Q2. What should I do if the Ethernet LED is off when a device
is connected to the corresponding port?
A1: Make sure the power adapter is connected to the switch
with power source properly.
A2: Make sure the voltage of the power supply meets the
requirements of the input voltage of the switch.
A3: Make sure the power source is ON.
Q1. What should I do if the Power LED is off ?
LED Explanation
Power
On: The power is on.
O: The power is o.
Ethernet Ports
On: The port is connected.
Blinking: The port is sending or receiving
data.
O: The port is not connected.
12345678
12345678
LAN PortWAN Port
Router
Switch
Internet PC
Power AdapterEthernet Ports
Explicación del LED
Alimentación Encendido: La alimentación está encendida.
Apagado: La alimentación está desconectada.
Puertos Ethernet
Encendido: El puerto está conectado.
Parpadeo: El puerto está enviando o
recibiendo datos.
Apagado: El puerto no está conectado.
Español (Latinoamérica)
Conecte el equipo de acuerdo con el diagrama de conexión.
Français
Explication de la LED
Connectez le matériel conformément au schéma de connexion.
Alimentation On: le courant est allumé.
O: l'alimentation est éteinte.
Ports Ethernet
On: le port est connecté.
Clignotant: le port envoie ou reçoit des
données.
O: le port n'est pas connecté.
Türkçe
LED Açıklaması
Donanımı bağlantı şemasına göre bağlayın.
Güç Açık: Güç açıktır.
Kapalı: Güç kapalı.
Ethernet Portları
Açık: Port bağlı.
Yanıp sönüyor: Port veri gönderiyor veya alıyor.
Kapalı: Bağlantı noktası bağlı değil.
Português
Explicações sobre LEDs
Conecte o hardware de acordo com o diagrama de conexão.
Energia Aceso: O dispositivo está ligado.
Apagado: O dispositivo está desligado.
Portas Ethernet
Aceso: A porta está conectada.
Piscando: A porta está enviando ou
recebendo dados.
Apagado: A porta não está conectada.
LED
Safety Information
· Keep the device away from water, fire, humidity or hot environments.
· Do not attempt to disassemble, repair, or modify the device, If you need service, please
contact us.
· Do not use damaged charger or USB cable to charge the device.
· Do not use any other chargers than those recommended.
· Place the device with its bottom surface downward.
· Adapter shall be installed near the equipment and shall be easily accessible.
· Operating Temperature: 0 ~ 40˚C ˚C
Please read and follow the above safety information when operating the device. We
cannot guarantee that no accidents or damage will occur due to improper use of device.
Please use this product with care and operate at your own risk.
Explanation of the Symbols on the Product Label
The product label is at the bottom of the product
Operator’s manual
Caution
Energy eciency Marking
Class II equipment
Alternating current
Direct current
For indoor use only
RECYCLING
This product bears the selective sorting symbol for Waste electrical and
electronic equipment (WEEE). This means that this product must be handled
pursuant to European directive 2012/19/EU in order to be recycled or
dismantled to minimize its impact on the environment.
User has the choice to give his product to a competent recycling organization or
to the retailer when he buys a new electrical or electronic equipment.
.
For technical support, the user guide and more information, please visit
http://www.mercusys.com/en/support.
This is a class B product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
CE Mark Warning
Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність
вимогам нормативних документів та вимогам, що передбачені чинними
законодавчими актами України.
Para informações de aspectos de segurança e adequação do
produto no território brasileiro consulte: www.gov-
.br/anatel/pt-br/
UK Declaration of Conformity
Mercusys hereby declares that the device is in compliance with the essential
requirements and other relevant provisions of the Electromagnetic Compatibility
Regulations 2016 and Electrical Equipment (Safety) Regulations 2016.
The original UK declaration of conformity may be found at
https://www.mercusys.com/support/ukca/
