Seite 1/8
WWW.LOSI.COM
©2010 Losi, a Division of Horizon Hobby, Inc.
Printed 04/10 17416800-0432
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole
discretion of Horizon Hobby, Inc. For up-to-date product literature, visit
http://WWW.LOSI.COM/SUPPORT
Meaning of Special Language
The following terms are used throughout the product literature to indicate various levels of potential harm when
operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property
damage AND a little or no possibility of injury.
WARNING: Procedures, which if not properly followed, create the probability of property
damage, collateral damage, and serious injury OR create a high probability of
superficial injury.
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the
product before operating. Failure to operate the product correctly can result in
damage to the product, personal property and cause serious injury.
This is a sophisticated hobby product and NOT a toy. It must be operated with caution and common sense and
requires some basic mechanical ability. Failure to operate this Product in a safe and responsible manner could
result in injury or damage to the product or other property. This product is not intended for use by children
without direct adult supervision. Do not attempt disassemble, use with incompatible components or augment
product in any way without the approval of Horizon Hobby, Inc. This manual contains instructions for safety,
operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual,
prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.
MICRO SCT
1/24-SCALE ELECTRIC RTR 4WD SHORT COURSE TRUCK
Replacement Parts for Micro SCT
LOSB0817 Servo w/Servo Saver
LOSB0843 AM Receiver/ESC Unit: Micro SCT, Rally
LOSB0846 4.8V 220mAh NiMh Pack: MC SCT, Rally
LOSB0879 Micro Wall Charger NiMH: Micro SCT, Rally
LOSB1523 Wheel Nuts
LOSB1583 Tires, Mounted, Chrome: Micro SCT
LOSB1585 Tires, Mounted, Black: Micro SCT
LOSB1730 Bearing Set: Micro SCT, Rally
LOSB1740 Chassis Set: Micro SCT, Rally
LOSB1741 Suspension Arm Set: Micro SCT, Rally
LOSB1742 Spindles, Carriers, Hubs: Micro SCT, Rally
LOSB1743 Diff Covers & Shock Towers: Micro SCT, Rally
LOSB1744 Steering & Servo Saver Hardware: Micro SCT, Rally
LOSB1745 Bumper Set: Micro SCT
LOSB1747 Side Bumpers & Mounts: Micro SCT, Rally
LOSB1748 Main Drive Shaft & Hardware: Micro SCT, Rally
LOSB1749 Hinge Pin Kit: Micro SCT, Rally
LOSB1751 Motor: Micro SCT & Rally
LOSB1752 Pinion & Spur Set: Micro SCT, Rally
LOSB1754 Complete Front Gear Box: Micro SCT, Rally
LOSB1755 Complete Rear Gear Box: Micro SCT, Rally
LOSB1757 Diff Outdrive Set: Micro SCT, Rally
LOSB1758 Dogbone Set: Micro SCT, Rally
LOSB1759 Axle Set: Micro SCT, Rally
LOSB1760 Ring & Pinion Gear Set: Micro SCT, Rally
LOSB1762 Oil Filled Damper (Shock) Set: Micro SCT, Rally
LOSB1763 Damper Spring Set, Hard (4): Micro SCT, Rally
LOSB1764 Screw Set: Micro SCT, Rally
LOSB1781 1/24 4WD Short Course Painted Body, Black
LOSB1782 1/24 4WD Short Course Painted Body, White
LOSB1783 1/24 4WD Short Course Painted Body, Silver & Red
LOSB1784 1/24 4WD Short Course Painted Body, White & Red
LOSB1799 Micro SCT Sticker Set
LOSB4605 Wrench Set: Micro SCT, Rally
Option Parts
LOSB1765 Damper Spring, Soft (4): Micro SCT, Rally
LOSB1766 Damper Spring, Medium (4): Micro SCT, Rally
LOSB1780 Micro SCT Body, Clear
LOSB9635 LiPo Charger & 7.4v 250 mAh Lipo Battery Combo
LOSB9825 7.4V 250mAh LiPo: Micro Rally, SCT
2
3
Operations Guide
Introduction
Thank you for choosing the 1/24 Micro 4WD Short Course Truck. This guide contains the basic instructions for
operating the vehicle. Read all of the instructions and all accompanying printed material in order to operate your
model correctly and avoid unnecessary damage. Please take a moment to look them over before running your
model.
DO NOT RUN YOUR MICRO-4WD SHORT COURSE TRUCK ON PLUSH CARPET, GRASS OR SAND.
NOTICE: Although the best materials and components are used, and due to the size of this
model, using anything other than genuine Losi replacement and performance parts specifi-
cally designed for the Losi Micro 4WD Short Course could cause damage.
CONNECT - REGISTER - WIN
Register your product online so we can notify you about the latest option parts, product updates, tech tips,
service bulletins and more. Visit WWW.LOSI.COM and follow the Product Registration link to stay connected.
For registering your Losi Product you will be automatically entered for a chance to win the
Losi Pick Your Prize Sweepstakes. The winner will be allowed to select a total prize package of
$1,000 (retail value) based on their preference.
WWW.LOSI.COM/REGISTER
Safety Guidelines and Warnings
Age Recommendation: 14 years or over. This is not a toy. This product is not intended for use by chil-
dren without direct adult supervision. This is a sophisticated radio controlled model that must be operated
with caution and common sense. Failure to operate your Micro 4WD Short Course Truck in a safe and responsible
manner could result in damage to the model and property.
Losi and Horizon Hobby, Inc. shall not be liable for any loss or damages, whether direct, indirect, special, inciden-
tal, or consequential, arising from the use, misuse, or abuse of this product or any product required to operate it.
• This model is controlled by a radio signal that is subject to interference from many sources outside your
control. This interference can cause momentary loss of control so it is advisable to always keep a safety
margin in all directions to avoid collisions.
• Always operate your model in an open area away from cars, trafc and people.
• Never run out into the street for any reason.
• Never run your Micro 4WD Short Course with low transmitter batteries.
• Carefully follow the directions and warnings for this and any optional support equipment that you use.
• Keep all chemicals, small parts and anything electrical out of the reach of children.
• Never leave vehicle on when not in use. By doing so, damage to the battery may occur.
Tools and Items You Will Find Handy
• Soft bristle brush for cleaning
• Losi Micro Phillips Screwdriver - LOSB1602
• Losi Nutdriver: 4.5mm - LOSA99160
• Small at blade screwdriver
1.
2. Plug the AC charger into the proper wall receptacle (110V - US version). Plug the battery pack into the
charger and let it charge for 1 hour for the rst time. Charge for 1 hour thereafter for a full charge. Battery
charged for over 1 hour may cause an overcharge.
Open
Push and Slide
4
5
Battery and Charging Guidelines and Warnings
Failure to exercise caution while using this product and comply with the following warnings
could result in product malfunction, electrical issues, excessive heat, FIRE, and ultimately
injury and property damage.
• Read all safety precautions and literature prior to use of this product
• Never leave the battery and charger unattended during use
• Never allow minors to charge battery packs without adult supervision
• Never drop charger or batteries
• Never attempt to charge dead or damaged batteries
• Never charge a battery if the cable has been pinched or shorted
• Never allow batteries or charger to come into contact with moisture at any time
• Never charge batteries in extremely hot or cold places (recommended between 50–80 degrees Fahrenheit)
or place in direct sunlight
• Always use only NiMH rechargeable batteries. This charger cannot charge batteries such as “heavy duty,”
“alkaline battery,” or “mercury battery”
• Always connect the positive red lead (+) and negative black lead (-) terminals of the battery to the charge
terminals correctly
• Always disconnect the battery and charger after charging and let them cool between charges
• Always inspect the battery before charging
• Always terminate all processes and contact Horizon Hobby if the product malfunctions
• Always make sure you know the specications of the battery to be charged or discharged to ensure it
meets the requirements of this charger
• Always constantly monitor the temperature of the battery pack while charging
• Always end the charging process if the charger or battery becomes hot to the touch or starts to change
form during the charge process
3.
4. Plug battery in and reinsert into vehicle.
5. 6.
Transmitter
Steering Wheel: Controls direction (left/right).
Throttle Trigger: Controls speed and direction
(forward/reverse).
Antenna: Transmits signal to the model.
On/Off Switch: Turns the power on/off for the
transmitter.
Indicator Lights: Green (right) light indicates
adequate battery power. Red (left)
indicates signal strength.
ST. Trim: Adjusts the “hands off” direction of the
model.
TH. Trim: Adjusts the motor speed to stop at neutral.
Steering Rate: Adjusts amount front wheels move
when the steering wheel is turned
left and right.
ST. REV: Reverses the function of the steering when
the wheel is turned left or right.
TH. REV: Reverses the function of the speed control
when pulled back or pushed forward.
Battery Door: Covers and holds the batteries that
power the transmitter.
Antenna
Steering
Reverse
Throttle
Reverse
On/Off
Switch
Steering
Rate
Throttle
Trigger
Steering
Wheel
Steering
Trim
Throttle
Trim
Battery
Door
Close
Step 1 - ON Step 2 - ON
