Seite 1/14
© LINDY Group - EIGHTH EDITION
(February 2022)
USB 3.0 Active Extension System Pro
User Manual English
Benutzerhandbuch Deutsch
Manuel Utilisateur Français
Manuale Italiano
Manual de Usuario Español
No. 43157, 43158, 43159, 43229
lindy.com
User Manual English
Safety Instructions
! WARNING !
Please read the following safety information carefully and always keep this document with
the product.
Failure to follow these precautions can result in serious injuries or death from electric
shock, fire or damage to the product.
Touching the internal components or a damaged cable may cause electric shock, which
may result in death.
This device is a switching type power supply and can work with supply voltages in the range 100 - 240
VAC For worldwide usability four different AC adapters are enclosed: Euro type, UK type, US/Japan type
and Australia/New Zealand type. Use the appropriate AC adapter as shown in the picture and ensure it
is firmly secured in place and does not detach by pulling before installing into a power socket.
To reduce risk of fire, electric shocks or damage:

Do not open the product nor its power supply. There are no user serviceable parts inside.

Only qualified servicing personnel may carry out any repairs or maintenance.

Never use damaged cables.

Do not expose the product to water or places of moisture.

Do not use this product outdoors it is intended for indoor use only.

Do not place the product near direct heat sources. Always place it in a well-ventilated place.

Do not place heavy items on the product or the cables.

Please ensure any adapters are firmly secured and locked in place before inserting into a wall socket
Instructions for Use of Power Supply
Attach the required adapter to the plug. Push the adapter firmly, twist until the latch secures the adapter.
To remove, push the button and twist in the opposite direction.
User Manual English
Introduction
Thank you for purchasing the Lindy USB 3.0 Active Extension System Pro. This product has been
designed to provide trouble free, reliable operation. It benefits from both a Lindy 2 year warranty and free
lifetime technical support. To ensure correct use, please read this manual carefully and retain it for future
reference.
The USB 3.0 Active Extension System Pro allows access to USB 3.0 SuperSpeed peripherals over long
distances. With support for data transfer speeds of up to 5Gbps it is perfect for transferring large data
volumes quickly and reliably.
It consists of four different units (each sold separately):
• USB 3.0 Active Extension Pro 8m (No. 43158)
• USB 3.0 Active Extension Pro 10m (No. 43157)
• USB 3.0 Active Extension Hub Pro 10m (No. 43159)
• USB 3.0 Active Extension Pro 15m (No. 43229)
Each unit can be used standalone or as part of the Lindy Active Extension System Pro to create
extension systems of about 40m (depending on the cable configurations used).
Features
• USB 3.2/3.1 Gen 1 / USB 3.0 specification, backwards compatible with USB 2.0/1.1
• Supports USB SuperSpeed data transfer rates up to 5Gbps
• Plug & Play
• Chipset: VL210 (No. 43159: VL817)
• USB bus powered or externally powered (No. 43159 includes a 5VDC 3.5A Multi-Country Power
Supply)
• No. 43157, 43158, 43229 include a USB power adapter cable (USB A male to DC 2.5/0.7mm male,
approximately 1.5m) for use with a power supply (not included)
• Locking Type A female connector for secure attachment to other cables from the LINDY Active
Extension System Pro range (not for Nr. 43159)
• Easy to use – connects to the device’s existing USB cable (5m maximum)
Installation
Please Note: Only the USB 3.0 Active Extension Pro 8m (Nr. 43158) or 15m (Nr. 43229) can be connected
directly to your computer. If you are creating an extension using multiple units from the Extension Pro
System then the first unit must always be the USB 3.0 Active Extension Pro 8m (Nr. 43158) or 15m (Nr.
43229).
Once the first cable has been connected, you can then cascade further cables to achieve a maximum
distance of 40m. The final part of the extension can be any of the three parts of the Extension Pro System.
If you need to extend multiple devices or if you connect a USB device with high power requirement, then
you should use the 10m Hub Pro unit (Nr. 43159) with it’s power supply as the final part of the extension.
Example Set-up:
8m Extension Pro
43158
8m Extension Pro 43158 /
10m Extension Pro 43157 /
10m Extension Hub Pro 43159
Computer
