Part no.:
| DESCRIPTION
36483
3m DisplayPort 1.4 Cable, Anthra Line
DP Male to Male
Professional choice DisplayPort 1.4 cable for commercial and high performance AV and IT installations
Supports UHD resolutions up to 8K 7680x4320@60Hz 4:2:2 8bit including 4K 4096x2160@144Hz 4:2:2 10bit
Robust ABS housing 24K gold plated connectors and contacts
Triple shielded cable, corrosion resistant tinned copper 28AWG conductors
DisplayPort 1.4, 8K 4K, 3D, 32.4Gbps; 10 year warranty
From the Lines cable connectivity concept developed by Lindy, Anthra Line DisplayPort cables are the professional choice for high
performance connections in commercial AV and IT installations.
Anthra Line DisplayPort cables are premium connections that feature triple shielded with 28AWG tinned copper conductors for
performance and corrosion resistance. High quality 24K gold plated contacts and connectors maintain optimal signal integrity and
maximum reliability.
UHD resolutions up to 8K 7680x4320@60Hz 4:2:2 8bit, including 4K 4096x2160@144Hz 4:2:2 10bit and HDCP are supported.
DisplayPort 1.4 technology and DisplayPort compliance certification ensures compatibility with all DisplayPort enabled devices.
Anthra Line DisplayPort cables are available in lengths: 0.5m, 1m, 2m, 3m, 5m, 7.5m and 10m.
•
•
•
•
•
Connectors
Connector A: DisplayPort Male
Connector B: DisplayPort Male
Housing Material: ABS
•
•
•
| TECHNICAL DATA SHEET
Connector Plating: 24K Gold 15µm
Pin Construction: Phosphor Bronze
Pin Plating: 24K Gold 3µm
Dimensions (approx.) WxDxH: 20.7x42.6x13mm (0.81x1.68x0.51in)
Cable Construction
Length: 3m (9.84ft)
Standard: DisplayPort 1.4
Colour: Black
Type: Round
Jacket Diameter: 7.0mm (0.28in)
Jacket Material: PVC
Conductor Material: Copper
Conductor Gauge: 28AWG
Shielding: Copper Braid 65%
Speci cationsfi
Supported Bandwidth: 32.4Gbit/s
Maximum Resolution:
7680x4320@60Hz 4:2:2 8bit
4096x2160@144Hz 4:2:2 10bit
Nominal Attenuation: 100MHz-450MHz <5.1dB, 450MHz-8100MHz <33.28dB
Minumum Band Radius: 58.4mm (2.14in)
Operating Temperature: -20°C - 80°C (-4°F - 176°F)
Storage Temperature: -25°C - 85°C (-13°F - 185°F)
ATC Approved: -
Miscellaneous
Packaging Type: Polybag
Warranty (Years): 10
Product Compliance: RoHS, REACH, UL
Purchasing Information
No.: 36483
EAN: 4002888364836
This product is also available in other lengths
36480 - 0.5m (1.64ft)
36481 - 1m (3.28ft)
36482 - 2m (6.56ft)
36483 - 3m (9.84ft)
36484 - 5m (16.40ft)
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
◦
◦
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
| TECHNICAL DATA SHEET
Artikelnr.:
| BESCHREIBUNG
36483
3m DisplayPort 1.4 Kabel, Anthra Line
DP Stecker an Stecker
Professionelle DisplayPort 1.4-Kabel für hochperformante, kommerzielle AV- und IT-Anwendungen
Unterstützt UHD-Auflösungen bis zu 8K 7680x4320@60Hz 4:2:2 8Bit inklusive 4K 4096x2160@144Hz 4:2:2 10Bit
Robustes ABC-Gehäuse mit 24K vergoldeten Kontakten und Steckerhülsen
3-fach geschirmtes Kabel mit korrosionsbeständigem, 28AWG-verzinntem Kupferleiter
DisplayPort 1.4, 8K 4K, 3D, 32.4Gbit/s; 10 Jahre Garantie, mehr über Garantiebedingungen hier
Cable Lines steht für das Konzept zeitgemäßer, kabelgebundener Konnektivitätslösungen von Lindy. Die Anthra Line DisplayPort-
Kabel aus dem Cable-Line-Konzept sind die professionelle Wahl, wenn es darum geht, Verbindungen für höchste Auflösungen in
kommerziellen AV- und IT-Anwendungen zu realisieren.
Die Anthra Line DisplayPort-Kabel verfügen über eine 3-fache Schirmung und verzinnte Kupferleiter mit 28AWG-Querschnitt für
höchste und verlustfreie Übertragungsleistung. Dauerhafte Korrosionsbeständigkeit und maximale Zuverlässigkeit gewährleisten
die hochqualitativ gefertigten, mit 24K vergoldeten Kontakte und Steckerhülsen.
Unterstützt werden UHD-Auflösungen bis zu 8K 7680x4320@60Hz 4:2:2 8Bit inklusive 4K 4096x2160@144Hz 4:2:2 10-bit. Die
DisplayPort 1.4-Technologie und die DisplayPort-Compliance-Zertifizierung gewährleisten die Kompatibilität mit allen DisplayPort-
fähigen Geräten.
Verfügbar in den Längen 0.5m, 1m, 2m, 3m, 5m, 7.5m und 10m.
•
•
•
•
•
Anschlüsse
Steckverbinder A: DisplayPort-Stecker•
| TECHNICAL DATA SHEET
Produktspezifikationen
Marke: | Lindy |
Kategorie: | Kabels voor pc's en randapparatuur |
Modell: | 36483 |
