LEICA SUMMILUX-M 50 mm f/1.4 ASPH. 1
Leica Camera AG has unveiled a new highspeed standard lens for the Leica M System offering maximum imaging performance:
the new LEICA SUMMILUX-M 50mm f/1.4 ASPH. It supersedes the predecessor lens with the same speed, which, notwithstanding
a few minor modifications, had been part of our range since 1962. The aim of this new development was to create a reference lens
to push the technical boundaries of photography using standard focal lengths into new dimensions. The LEICA SUMMILUX-M 50mm
f/1.4 ASPH. delivers virtually the same outstanding performance throughout all apertures and focus settings. Whether using selec-
tive focus at close range, high-contrast available light applications or an extended depth of field to capture landscapes, the
LEICA SUMMILUX-M 50mm f/1.4 ASPH. handles every situation with ease. It therefore delivers on its promise to be a genuine
universal lens in impressive fashion. Every innovation currently available in lens technology – aspherical lenses, glass with anoma-
lous partial dispersion, glass with a high refraction index and a floating element – has been combined to create a lens that sets the
new standard in this focal length class.
Lens shape
Asphere
Floating Element
LEICA SUMMILUX-M 50 mm f/1.4 ASPH. 2
Engineering drawing
Technical Data
Angle of view (diagonal, horizontal, vertical)
Optical design
Distance setting
Diaphragm
Bayonet
Filter (type)
Lens hood
Dimensions and weight
47°, 40°, 27°
Number of elements / groups: 8 / 5
Focal length: 51.6 mm
Entrance pupil: 25.7 mm (related to the first lens surface in light direction)
Focusing range: 0.7 m to Infinity
Scale: combined meter/feet-increments
Smallest object field: 271 x 407 mm
Highest reproduction ratio: 1:11.3
Setting / Type: Preset, with click-stops, half values available
Smallest aperture: f/16
Leica M quick-change bayonet
Internal thread for screw-on filters size E46, non-rotating
Built-in, telescopic, lockable
Length: 52.5 mm
Largest diameter: 53.5 mm
Weight: approx. 335 g
LEICA SUMMILUX-M 50 mm f/1.4 ASPH. 3
0 5 2010 15
Y'[mm]
0
20
40
60
80
100[%] Aperture Stop 1.4
0 5 2010 15
Y'[mm]
0
20
40
60
80
100
Aperture Stop 5.6
[%]
0 5 2010 15
Y'[mm]
0
20
40
60
80
100[%] Aperture Stop 2.8
MTF graphs
The MTF is indicated both at full aperture and at
f/5.6 at long taking distances (infinity). Shown
is the contrast in percentage for 5, 10, 20 and
40 lp/mm accross the height of the 35 mm film
format, for tangential (dotted line) and sagittal
(solid line) structures, in white light. The 5 and
10 lp/mm will give an indication regarding the
contrast ratio for large object structures.The
20 and 40 lp/mm records the resolution of finer
and finest object structures.
tangential structures
sagittal structures
_ _ _ _ _ _ _ _
