Wireless Weather Station
WS6812 | Quick Setup Guide
The Wireless Weather Station features manual set time, date, time alarm,
Outdoor/Indoor temperature alerts, and moon phase. Monitor temperature
and humidity, track temperature trends and set customizable temperature
alerts all in one convenient device. Wireless transmission range of over --
300 feet (90 meters) in open air, from transmitter to weather station.
SETUP INSTRUCTIONS STEP BY STEP
STEP 1:
Remove battery cover from the weather station. Slide tab down and pull
out to remove the battery cover.
Insert 2 NEW AA batteries (not included) into the back
of the weather station. Observe the correct polarity
(see marking inside the battery compartment).
The weather station will light up and show,
indoor temperature, humidity and time.
Do Not Mix Old and New Batteries
Do Not Mix Alkaline, Standard, Lithium or Rechargeable Batteries
STEP 2:
Ensure that the transmitter is within 10 feet of the Weather Station.
To remove battery cover from transmitter, slide the battery
cover down and lift off the front of the transmitter.
Insert 2 NEW AA batteries (not included) into the transmitter.
Observe the correct polarity.
Within 3 minutes the weather station will show readings in the
outdoor temperature area on the LCD.
Allow the weather station and the transmitter to stay Note:
within 10 feet of each other for the first 15 minutes of set up.
TRANSMITTER SIGNAL STRENGTH
After the batteries are inserted, the weather station will search for the
outdoor temperature/humidity transmitter for 3 minutes.
The antenna symbol will flash during reception, and temperature
display will be dashes “---“.
The antenna symbol will roll during signal synchronization. sc
If synchronization fails once, the antenna will lose one bar.
If synchronization fails twice, the antenna will lose two bars.
If reception continuously fails to receive 5 times, the antenna symbol will
be shown as .
The antenna will show full display with successful RF (radio
frequency) reception.
TROUBLESHOOTING
If the outdoor data are not displayed after three minutes,
hold the SENSOR button on the weather station for three
seconds to search for outdoor transmitter .
Next, press the TX button on the outdoor transmitter to send signal.
If it still does not receive the outdoor data, remove batteries from both
the weather station and the transmitter for 15 minutes then repeat the
setup instructions from step 1.
The maximum transmitting range in open air is over 300-feet (90
meters). Obstacles such as walls, windows, stucco, concrete, and large
metal objects can reduce the range.
TIME/DATE
The TIME/DATE button will move through the program
menu and confirm settings.
Use the UP ARROW button to increase a value.
Use the DOWN ARROW button to decrease a value.
SET TIME AND DATE
Hold the TIME/DATE button for three seconds to enter time set mode.
YEAR: The will flash. Use the ARROW buttons to choose the year, Year
and press the TIME/DATE button to confirm and move to the month.
MONTH: The will flash, use the ARROW buttons to choose the Month
month, and press the TIME/DATE button to confirm and move to the
date.
DATE: The Date will flash. U the ARROW buttons to choose the date, se
and press the TIME/DATE button to confirm and move to 12/24 hour
time format.
12/24-HOUR: The time format will flash. Use the ARROW buttons to
choose 12-hour or 24-hour time format and press the TIME/DATE button
to confirm and move to language.
LANGUAGE : The language will flash. Use the ARROW buttons to select
the language for weekday display (French, Italian, Dutch, Spanish,
Danish, English or German - refer to the table hereunder) and press the
TIME/DATE button to confirm and move to hour.
HOUR: The will flash. Use the ARROW buttons to choose the Hour
hour, and press the TIME/DATE button to confirm and move to minutes.
MINUTES: The will flash. Use the ARROW buttons to choose Minutes
the minutes, and press the TIME/DATE button to confirm and move to
Fahrenheit/Celsius.
FAHRENHEIT/CELSIUS: will flash. Use the ARROW buttons °F or °C
button to select Fahrenheit or Celsius. Press and release the
TIME/DATE button to confirm and exit the program menu.
Note: When no buttons are pressed for ten seconds, the weather station
will save the last change and default back to normal time and
temperature display mode.
TIME ALARM
The TIME ALARM button moves through the alarm setting
mode and confirms the final setting.
Use the UP ARROW button to increase a value.
Use the DOWN ARROW button to decrease a value.
SET TIME ALARM
From normal time and temperature display mode, press and release the
TIME ALARM button once to show alarm time. Hold the TIME ALARM
button for three seconds to enter alarm set mode.
HOUR: The will flash. Use the ARROW buttons to set the hour, Hour
and press TIME ALARM button to confirm and switch to minutes .
MINUTES: The will flash. U the ARROW buttons to set the Minutes se
minutes, and press TIME ALARM button to confirm.
Press the TIME/DATE button to return to normal mode
LOW BATTERY
When this low battery icon appears in the indoor reading section,
replace the batteries in the weather station.
When this low battery icon appears in the outdoor readings section,
replace the batteries in the outdoor transmitter.
POSITION THE WEATHER STATION
Choose a location for the weather station that is within range 00 feet,9(3 0
meters) of the outdoor transmitter. The weather station has a build in base
stand to sit on a table or desk.
Choose a location 6 feet or more from electronics such as
cordless phones, gaming systems, televisions, microwaves,
routers, baby monitors, etc., which can prevent signal
reception.
Be aware of electrical wires and plumbing within a wall.
Best reception is achieved when the front or the back of the
weather station is facing the outdoor transmitter. This allows
a larger portion of the antenna to receive a signal.
POSITION THE WIRELESS OUTDOOR TRANSMITTER
Once the weather station shows the outdoor temperature/humidity, place it
and the transmitter in the desired locations and wait approximately one hour
before permanently mounting the transmitter to ensure that there is proper
reception. The transmitter should be mounted vertically, in a shaded,
protected area, at least 6 feet from the ground to avoid damage and ensure
accurate readings. The transmitter is water resistant, not waterproof and
should not be placed anywhere it will become submerged in water or
subject to standing water or snow.
Choose a location for the transmitter that is within range of
the Weather station and under an overhang for accuracy.
The maximum transmitting range in open air is over 3 -feet 00
(90 meters).
Option 1:
Install one mounting screw (not included) into a wall
leaving approximately ½ of an inch (12.7mm) extended.
Place the transmitter onto the screw, using the hanging
hole on the backside.
Gently pull the transmitter down to lock the screw into
place .
Option 2:
Insert the mounting screw (not included) through the front of the
transmitter and into the wall.
Tighten the screw to snug (do not over tighten).
To achieve a true temperature/humidity reading, mount where direct
sunlight cannot reach the outdoor transmitter. Mount the outdoor
transmitter on a North-facing wall or in any well shaded area. Under an
eave or deck rail work well. The maximum transmitting range in open air is
over 3 -feet (90 meters). Obstacles such as walls, windows, stucco, 00
concrete, and large metal objects can reduce the range. Place the
transmitter at least 6 feet in the air to improve signal transmission.
CARE AND MAINTENANCE
Do Not Mix Old and New Batteries
Do Not Mix Alkaline, Standard, Lithium or Rechargeable Batteries
Do not expose the weather station to extreme temperatures, vibration or
shock.
Keep weather station dry.
Clean weather station with a soft damp cloth. Do not use solvents or
scouring agents.
The weather station is not a toy. Keep it out of reach of children.
The weather station is not to be used for medical purpose or for public
information; it is for home use only.
The specifications of this weather station may change without prior notice.
Improper use or unauthorized opening of housing will void the warranty.
If the weather station does not work properly, change the batteries.
SPECIFICATION
Indoor:
Temperature Range: +32°F to +122°F (0°C to 50°C)
Interval: About every 30 seconds
Outdoor:
Temperature Range: -40°F to 140°F (-40°C to 60°C)
Distance: Over 300 ft. (90 meters)
RF 433MHz (open air)
Interval: About every 50 seconds
Power:
Weather Station 2-AA, IEC, LR6 batteries (not included) :
Transmitter: 2-AA, IEC, LR6 batteries (not included)
Battery Life:
Transmitter
Battery Life: Battery life is over 12 months when
using reputable Alkaline battery brands.
Weather Station
Battery Life: Battery life is over months when 12
using reputable Alkaline battery brands.
Dimensions:
Weather Station: 5.40” L x 1.68” W x 4.40” H
(137.2 mm L x 42.8 mm W x 111.8 mm H)
Transmitter 1.57" L x 0.79" W x 5.12" H :
(40 x 20 x 130 mm)
LIABILITY DISCLAIMER
The electrical and electronic wastes contain hazardous substances.
Disposal of electronic waste in wild country and/or in unauthorized
grounds strongly damages the environment.
Please contact your local or/and regional authorities to retrieve the
addresses of legal dumping grounds with selective collection.
All electronic instruments must from now on be recycled. User shall take
an active part in the reuse, recycling and recovery of the electrical and
electronic waste.
The unrestricted disposal of electronic waste may do harm on public
health and the quality of environment.
As stated on the gift box and labeled on the product, reading the “User
manual” is highly recommended for the benefit of the user. This product
must however not be thrown in general rubbish collection points.
The manufacturer and supplier cannot accept any responsibility for any
incorrect readings and any consequences that occur should an inaccurate
reading take place.
This product is designed for use in the home only as indication of the
temperature.
This product is not to be used for medical purposes or for public
information.
The specifications of this product may change without prior notice.
This product is not a toy. Keep out of the reach of children.
No part of this manual may be reproduced without written authorization of
the manufacture r.
R&TTE Directive 1999/5/EC
Summary of the Declaration of Conformity : We hereby declare that this
wireless transmission device does comply with the essential
requirements of R&TTE Directive 1999/5/EC.
Produktspezifikationen
| Marke: | La Crosse Technology |
| Kategorie: | Wetterstation |
| Modell: | WS6812 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit La Crosse Technology WS6812 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Wetterstation La Crosse Technology
8 Oktober 2024
30 September 2024
29 September 2024
23 September 2024
22 September 2024
13 September 2024
12 September 2024
12 September 2024
11 September 2024
11 September 2024
Bedienungsanleitung Wetterstation
- Wetterstation Clatronic
- Wetterstation Hama
- Wetterstation Lexibook
- Wetterstation Nedis
- Wetterstation Tchibo
- Wetterstation Clas Ohlson
- Wetterstation Cotech
- Wetterstation Profile
- Wetterstation Adler
- Wetterstation Camry
- Wetterstation Velleman
- Wetterstation ADE
- Wetterstation Alecto
- Wetterstation Auriol
- Wetterstation Beurer
- Wetterstation Bresser
- Wetterstation Cresta
- Wetterstation Day
- Wetterstation Denver
- Wetterstation Dexford
- Wetterstation Durabase
- Wetterstation ECG
- Wetterstation EMOS
- Wetterstation Eurochron
- Wetterstation Gira
- Wetterstation HomeMatic
- Wetterstation Irox
- Wetterstation Jacob Jensen
- Wetterstation Kemot
- Wetterstation König
- Wetterstation MarQuant
- Wetterstation Mebus
- Wetterstation Medisana
- Wetterstation Mesko
- Wetterstation National Geographic
- Wetterstation Prologue
- Wetterstation Renkforce
- Wetterstation Sempre
- Wetterstation Techno Line
- Wetterstation Technoline
- Wetterstation Telefunken
- Wetterstation TFA
- Wetterstation ThinkGizmos
- Wetterstation Thomson
- Wetterstation Trevi
- Wetterstation Ventus
- Wetterstation Weinberger
- Wetterstation Ytora
- Wetterstation Trotec
- Wetterstation Blaupunkt
- Wetterstation Braun
- Wetterstation Rocktrail
- Wetterstation Daewoo
- Wetterstation Pyle
- Wetterstation Muse
- Wetterstation Avidsen
- Wetterstation Elro
- Wetterstation GoGEN
- Wetterstation Hyundai
- Wetterstation Orion
- Wetterstation Livoo
- Wetterstation Perel
- Wetterstation Soehnle
- Wetterstation Balance
- Wetterstation Fysic
- Wetterstation Sencor
- Wetterstation Krontaler
- Wetterstation Honeywell
- Wetterstation MINOX
- Wetterstation Lowrance
- Wetterstation Globaltronics
- Wetterstation ELV
- Wetterstation Guardo
- Wetterstation Unitec
- Wetterstation Netatmo
- Wetterstation Ascot
- Wetterstation Theben
- Wetterstation Brandson
- Wetterstation Tanita
- Wetterstation JUNG
- Wetterstation Johnson
- Wetterstation OBH Nordica
- Wetterstation Optex
- Wetterstation Davis
- Wetterstation Levenhuk
- Wetterstation Vitek
- Wetterstation Prestigio
- Wetterstation EQ-3
- Wetterstation EVE
- Wetterstation Extech
- Wetterstation Daikin
- Wetterstation Fluke
- Wetterstation Oregon Scientific
- Wetterstation Homematic IP
- Wetterstation EQ3
- Wetterstation Elgato
- Wetterstation Digi-tech
- Wetterstation DMV Electronics
- Wetterstation Ea2 LABS
- Wetterstation EMOS SELECT
- Wetterstation Garni
- Wetterstation Hesdo
- Wetterstation Inovalley
- Wetterstation IT
- Wetterstation Kaindle
- Wetterstation La Crosse
- Wetterstation Meade
- Wetterstation Nasa
- Wetterstation Nor-tec
- Wetterstation Otio
- Wetterstation Paget Trading
- Wetterstation PCE Instruments
- Wetterstation Saphir
- Wetterstation Saxon
- Wetterstation Taylor
- Wetterstation Thierry Mugler
- Wetterstation UPM
- Wetterstation Uzoli
- Wetterstation Waldbeck
- Wetterstation Xeecom ApS
- Wetterstation TFA Dostmann
- Wetterstation Vimar
- Wetterstation PeakTech
- Wetterstation AcuRite
- Wetterstation Ease Electronicz
- Wetterstation Chauvin Arnoux
- Wetterstation YONO
- Wetterstation Brigmton
- Wetterstation Chacon
- Wetterstation Baldr
- Wetterstation Garin
- Wetterstation ChiliTec
- Wetterstation Global Water
- Wetterstation Greisinger
- Wetterstation Marathon
- Wetterstation Majestic
- Wetterstation Gewiss
- Wetterstation ClimeMET
- Wetterstation Buienradar
- Wetterstation Balance Meteo
- Wetterstation Rebel
- Wetterstation JDC
- Wetterstation Greenure
- Wetterstation Browin
- Wetterstation Setti+
- Wetterstation Bearware
Neueste Bedienungsanleitung für -Kategorien-
15 Oktober 2024
5 Oktober 2024
3 Oktober 2024
2 Oktober 2024
29 September 2024
24 September 2024
24 September 2024
22 September 2024
22 September 2024
21 September 2024
