Seite 1/10
LARGE CASE FOR RD6006
JT- -RD6006 Case02
1. GENERAL INFORMATION
Dear customer,
Thank you for purchasing our product. In the following, we will show you
which things should be noted during the use.
Should you encounter any unexpected problems, do not hesitate to
contact us.
This case is available in two versions, version A and B. These versions
dier by a lead out of the temperature sensor, which only version B -
features.
This case is made for an additional power supply which allows
you to connect this lab power supply directly to alternating
current.
For your own safety, this product may only be
installed by a qualified electrician! Working on
electric devices / systems implies the hazard of
electric shocks which may cause serious injuries or
even death!
!
2. ASSEMBLY OF VERSION A
This case is made for the JT RD6006 / JT RD6006P and the corresponding - -
power supply JT RD6006 NT. Both products are not included in the scope - -
of delivery.
1. First of all, unscrew the eight screws from the outside and open up
the case.
2. Screw the feet onto the case with the black screws.
3. N into the
c below.
4. Now, mount the power supply into the case. Therefore, you have to
screw it from the bottom of the case with the big silver screws.
5. Now, screw the fan control next to the Power Supply with the
remaining black screws and connect the fan to the connector
provided for this purpose.
6. This is followed by the wiring. You start by wiring the switch. First,
connect the short brown cable (phase) to the switch and the
bottom connection of the power connector. From the switch,
connect another brown cable to the screw terminal of the power
supply unit (marked as L). The blue cable is connected from the
middle connection of the power connector to the N connection of
the power supply unit. The yellow green cable is connected from -
the top pin of the power connector to the earth terminal of the
power supply unit (marked as ).
