7. USB3.0 'Type A' data input port
Connect your phone to hip dac2 with Lightning to USB Camera
Adapter (Apple) or USB On-The-Go (OTG) cable (Android). When
using other audio sources connect with a USB cable.
Tip: It is preferable to use a USB 3 .0 p ort over using a USB 2.0 port on the PC.
8. USB-C (5V) battery charge input
For charging only. It will take ~3 hours for a high-powered USB
charger to fully charge hip dac2. Use the enclosed USB 'Type A' to
'Type C' cable, smart charger or a regular charger up to 6.3V.
9. LED for Battery Status
LED Status
White* > 75%
Green* 25% >
Red* 10% >
Red (flashing) 10% ≤
*Battery LED w il l fl ash wh en it is charging
Note: For use with PC it is necessary to download drivers.
Tip: For all latest firmware updates please refer to our website here:
www.ifiaudio.com/downloads/
ifi-audio.com Ver1.0
31 2 5 64
4. ON/OFF and Analogue Volume Control
The analogue volume control in hip dac2 is superior to any digital
volume control.
Warning: Due to the hig h power of hip dac2, alway s start off at a l ow volume level so
that there is no risk of damage to your headpho nes an d your hea ring. iFi audio is not
responsible for any hearing or equipment dama ge from m isuse.
Power ON. Power OFF.
Tip: hip dac2 will continue to use battery power even if the USB cable is connected
afterwards.
Tip: Fo r con nection to Apple devices, Apple Lightning to USB Camera Adapter is
required. For connecti on to Android devices, USB O n-The-Go (OTG) cable and
appropriate OS support are required.
For m ore information, please refer to www.ifi-audio.com
5. Balanced 4.4mm headphone output
Connect balanced 4.4mm headphones.
6. S-Balanced 3.5mm headphone output
Connect 3.5mm headphones.
87 9
OFF
Specications
Digital Input: USB 3.0 type 'A' (USB2.0 compatible)
Formats supported:
DSD DSD256/128/64, Quad/Double/Single-Speed D SD
PCM 384/352.8/192/176.4/96/88.2/48/44.1kHz
DXD 384/352.8kHz
MQA 384/352.8kHz
DAC: Bit-Perfect DSD & DXD DA C by B ur r Bro wn
Headphone Outputs:
Balanced 4.4mm
S-Balanced(S-E) 3.5mm
Power O utput:
Balanced 400mW @ 32Ω; 6.3V @ 600Ω
S-Balanced(S-E) 280mW @ 32Ω; 3.2V @ 600Ω
Battery: Lithium-polymer 2200mAh approx. 8 hours
Power System: Charging via USB-C,
BC V1.2 compliant up to 1000mA charging current
Power (max): <2W idl e, 4W max
Dimensions: 102 x 70 x 14 mm
4.0" x 2.8" x 0.6"
Weight: 125 g (0.28 lbs)
War ranty perio d: 12 months
Specic ati ons are subj ect to change witho ut noti ce.
H
H
H
HH
a
a
a
aa
p
p
p
p p c
c
c
cc2
2
2
22
d
d
d
dd
1. PowerMatch (on/off )
PowerMatch enables hip dac2 to match headphones’ impedance and
sensitivity in order to generate their highest operational efficiency.
Tip: Fo r in-ear-moni tors (earbuds) try Powe rMatch off. For headp hones try PowerMatch on.
2. XBass (on/off)
Many headphones lack the correct bass response. XBass is an
analogue circuit designed to 'add back' the lost bass response for a
more accurate reproduction of the original music.
3. Audio Format LED (kHz)
The LED colour scheme indicates the audio format and sampling
frequency received by hip dac2 from the music source.
LED Mode
Yellow PCM 44.1/48kHz
White PCM 88.2/96/176.4/192/352.8/384kHz
Cyan DSD 64/128
Red DSD 256
Green MQA
Blue MQA Studio
Magenta Original Sample Rate*
*MQB
Warning: Installing GTO enabled firmware may res ult in the LED's on this device no longer
changing in accordan ce with th e above table
