Seite 1/2
8. USB-C data input port
Connect your phone to the hip dac 3 with a Lightning to USB
Camera Adapter (Apple) or USB-C to USB-C cable (Android).
When using other audio sources, please connect with a USB
cable. This USB-C port is intended for data transfe r only.
Tip: Fo r App le iOS a nd Android d evices, please u se ba ttery power on the hip dac 3,
otherwise you may receive error messages from your device.
Note: For use with PC it is necessary to d ownload drivers.
Tip: Fo r the required driver a nd all the latest firmware updates please refer to our
website: www.ifi-audio.com/download-hub/
9. USB-C (5V) battery charge input
For charging only. It will take ~3 hours for a high-powered USB
charger to fully charge hip dac 3. Use the enclosed USB 'Type A'
to 'Type C' cable, smart charger or a regular charger up to 6.3V.
10. LED for Battery Status
LED Status
White* > 75%
Green* 25% >
Red* 10% >
Red (flashing) 10% ≤
*B attery LED will flash when it is charging
ifi-audio.com Ver1.0
31 2 5 64
4. ON/OFF and Analogue Volume Control
The analogue volume control in hip dac 3 is superior to any digital
volume control.
Warning: Due to the hig h power of hip dac 3, always start off at a low volume level
so that there is no risk of damage to your headphones and your hearing. iFi audio is
not responsible for any hearing or equip ment da mage from misu se.
Power ON. Power OFF.
Tip: hip dac 3 will continue to use battery power even if the USB cable is connected
afterwards.
Tip: Fo r con nection to Apple devices, Apple Lightning to USB Camera Adapter is
required. For connecti on to Android devices, USB-C to USB -C cab le and
appropriate OS support are required.
For m ore information, please refer to www.ifi-aud io. com
5. Balanced 4.4mm headphone output
Connect balanced 4.4mm headphones.
6. S-Balanced 3.5mm headphone output
Connect 3.5mm headphones.
7. iEMatch switch
iEMatch reduces the output level, so that even the most
sensitive In-Ear-Monitors (IEMs) can be matched to the hip dac 3.
= 3.5mm he adphones
= of f
= 4.4mm he adphone
Tip: The hip da c 3 or the hea dphone w ill not be damaged if the i EMatch swit ch is adju sted inco rrectl y,
but the atte nuation level will not b e correct.
98 10
OFF
1. PowerMatch (on/off)
PowerMatch enables hip dac 3 to match headphones' impedance
and sensitivity in order to generate their highest operational
efficiency.
Tip: Fo r in-ear-moni tors (earbuds) try Powe rMatch off. For headphones try PowerMatch on,
When on, the gain increa ses by 10dB. If your IEMs a re very sensitive, tr y using the iEMatc h
feature (item 7 ).
2. XBass (on/off)
Many headphones lack the correct bass response. XBass is an
analogue circuit designed to 'add back' the lost bass response for a
more accurate reproduction of the original music.
3. Audio Format LED (kHz)
The LED colour scheme indicates the audio format and sampling
frequency received by hip dac 3 from the music source.
LED Mode
Yellow PCM 44.1/48kHz
White PCM 88.2/96/176.4/192/352.8/384kHz
Cyan DSD 64/128
Red DSD 256
Green MQA
Blue MQA Studio
Magenta Original Sample Rate*
*MQB
Warning: Installing GTO enabled firmware may res ult in the LED's on this device no longer
changing in accordan ce with th e above table
7
iE Ma tc h
of f
3. 5
4. 4
SPECIFICATIONS
Inp ut: USB-C
Formats supported : DSD256 / 11.3MHz
PCM 384kHz
full MQA Decoder
DAC: Bit-Perfect DSD & DXD DAC b y Burr Brown
Head phone Outputs:
Balanced 4.4mm
S-BAL 3.5mm
Power Output:
Balanced 400mW @ 32 ; 6.3V @ 600
Ω Ω
S-BAL 280mW @ 32 ; 3.2V @ 600Ω Ω
Output Impedance:
Balanced ≤1 , With iEMatch engaged: ≤4.5Ω Ω
S-BAL ≤1 , With iEMatch engaged: ≤4.5ΩΩ
SNR :
Balanced ≥109dB(A) @ 0dBFS
S-BAL ≥103dB(A) @ 0dBFS
DNR:
Balanced ≥109dB(A)
S-BAL ≥103dB(A
THD + N:
Balanced <0.006X% (360mW/2.0V @ 600Ω)
S-BAL <0.01% (100mW/1.27V @ 16Ω)
Frequency Response: 20Hz - 45kHz (-3dB)
Power Consumption: <2W idle, 4W max
Battery : Lithium-polymer 2200mAh approx.
8 hours
Power System: Charging via USB-C,BC V1.2 compliant up
to 1000mA charging current
Dimensions: 102 x 70 x 14 mm (4.0" x 2.8" x 0.6")
Net weight: 135 g (0.30 lbs)
Limited Warranty: 12 months*
*12 months typical or as permitted/required by local reseller laws.
**Specifications are subject to change witho ut notice.
