Seite 1/1
1. USB ‘A’ Audio( ) connector
This transmits the USB audio data. Connect it to a
USB port on the computer.
2. USB ‘A’ Power( ) connector
This transmits the USB power. Connect it to a USB
port on the computer.
Tip: For maximum performance, use with the iUSB3.0;
connect the Audio connector( ) to the USB output
port labelled ‘ ‘ ; connect the Power connector
( ) to the USB output port labelled ‘ ‘.
3. USB ’B’ connector
Connect this to the input of the USB DAC/Sound
card/Interface card etc.
Tip: The Gemini3.0 USB cable uses the iFi FINAL USB
connector. Made of aluminium alloy, the additional
shielding and rigidity has taken USB cable design to a
whole new level that adheres rigidly to the 90 ohms
impedance requirement.
4. RF Silencers – Fixed
All USB cables, due to their inherent nature,
inevitably pickup AND radiate radio
frequencies that negatively impact the
sonic performance.
To address this, there are three sets of RF Silencers
on the Gemini3.0 Dual-Headed USB cable.The two
Silencers at each end are most effective when
located as close to the respective USB connector as
possible.
Note: The custom-designed metal oxide ceramic RF
Silencers offer different permeabilities. Compared to
generic filters this atypical approach is incredibly
effective; over the widest frequency range.
5. Centre RF Silencer
Feel free to adjust this third RF Silencer by sliding it
along the cable as different setups may require
different adjustments to attain the optimal sonic
performance .
Tip: To start with, set the three RF Silencers to
the 'Golden Ratio', with the shorter section
closer to the USB 'B' connector (item 3 above).
USB (Data)
Construction: Minimu inductance parallel
construction
Conductors: 24 and 28AWG
Conductor material: Heavy OFHC continuous cast
copper silver matrix
Insulation: HD Polyethylene
Shielding: Quadruple-shields
Impedance: 90Ohms
AC spark insulation : 1500V
Connectors: iFi 'FINAL' USB connectors
Insulation resistance: 100Mohm
Tensile strength: 1500PSI
USB (Power)
Construction: Minimum inductance parallel
construction
Conductors: 12AWG
Conductor material: Heavy OFHC continuous cast
copper
Insulation: Linear Polyethelyne (LPE) insulation
Current Rating: 30A
Lengths/Weights: 0.7m / 150g (0.33 lbs)
1.5m / 170g (0.37 lbs)
Warranty period: 12months
Specifications
•
ifi-audio.com Ver1.1
warranty
In order to activate the warranty for this iFi
product, you must register with the iFi
website.
Component :
Serial no:
Terms & Conditions
ifi-audio.com
iFi guarantees that this iF i pr o du ct shall be free from defects in
materials and wo rkm an ship for a period of 1 year for parts and labour.
The war ranty period begins at th e date of retail sale by an authorized
iFi distributor/dealer and is subject to the follow ing r equirements and
understandin gs:
• It is the responsibility of the buyer within 30 d ays from the original
sale, to register an d activate th e p roduct warranty with the iFi
website.
• The original invo ice mu st b e p roduced for authentication prior to
any warranty claim.
• The iFi pro duct must not have been modified in any manner
whatsoever, or the warranty will imm ediately become void.
• The iFi war ranty is only valid in the country of origin al sale.
• The product must not have been stored in a hum id environment;
nor subjected to w eather, water, or saltwater spray.
• iFi shall not, under an y circumstances, be liable for any
incidental or consequential damages arising from the loss of property
or other damage or losses due to the failure of an iFi product. iFi is not
liable for loss of use or inconvenien ce caused by the failu re of an iFi
product. iFi is not liable for damage caused to other audio
components because of the failur e o f an iFi product.
• During the warranty period, iFi will repair th e product to
working order, or, at iFi's option, replace the d ef ective module with a
sim ilar available product.
• All repairs performe d after expiry of the warranty period will be
charged to the owner an d will carr y a 180-day warranty on parts and
labou r. The custom er is responsible for ship ping the un it to the iFi
dis tr ibutor in the or iginal packaging. This includes the payment of any
shipp ing charges and re lated taxes.
• Should any warranty issue s ar ise, the decision of iFi is full and
fin al.
3
3
3
3
21 35 44
5
3
3
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
65.00 mm
271.00 mm
