7. USB3.0 'Type A' data input port
For data transfer only. Connect your phone to the hip dac Gold with a
Lightning to a USB Camera Adapter (Apple) or USB On-The-Go (OTG)
cable (Android). When using other audio sources, please connect with a
USB cable.
Tip: It is preferable to use a USB 3.0 over using a USB 2.0 port on the PC.
Note: For use with PC it is necessary to download drivers.
Tip: The hip dac Gold comes with a pre-installed firmware optimised for MQA. This version
also handles up to PCM384/DSD256.
Tip: For all latest firmware updates please refer to our website here: www.ifi-
audio.com/download-hub/
8. USB-C (5V) battery charge input
For charging only. It will take ~3 hours for a high-powered USB charger
to fully charge hip dac Gold. Use the enclosed USB 'Type A' to 'Type C'
cable, smart charger or a regular charger up to 6.3V.
9. LED for Battery Status
LED Status
White* > 75%
Green* 25% >
Red* 10% >
Red (flashing) 10% ≤
*Battery LED will flash when it is charging
Specifications
Digital Input: USB 3.0 type 'A' (USB2.0 compatible)
Formats suppor ted: DSD256 / 11.3MHz
PCM 384kHz
MQA Decoder
DAC: Bit-Perfect DSD & DXD DAC by Burr Brown
Headphone Outputs:
Balanced 4.4mm
S-BAL 3.5mm
Power Output:
Balanced 400mW @ 32 ; 6.3V @ 600Ω Ω
UnBAL 280mW @ 32Ω; 3.2V @ 600Ω
Battery: Lithium-polymer 2200mAh approx. 8 hours
Power System: Charging via USB-C, BC V1.2 compliant up to
1000mA charging current and 6.3 volts
Power (max): <2W idle, 4W max
Dimensions: 102 x 70 x 14 mm (4.0" x 2.8" x 0.6")
Net weight: 135 g (0.30 lbs)
Limited Warranty: 12 months*
*12 months typical or as permitted/required by loca l rese ller
**Specifications are subject to change without notice.
ifi-audio.com Ver1.0
31 2 5 64
87 9
OFF
1. PowerMatch (on/off )
PowerMatch enables hip dac Gold to match headphones’ impedance
and sensitivity in order to generate their highest operational efficiency.
Tip: For in-e ar-monitors (earbud s) try PowerMatch off. For headphone s try Powe rMatch on, When
on, the gain increases by 10dB.
2. XBass (on/off)
Many headphones lack the correct bass response. XBass is an
analogue circuit designed to 'add back' the lost bass response for a
more accurate reproduction of the original music.
3. Audio Format LED (kHz)
The LED colour scheme indicates the audio format and sampling
frequency received by hip dac Gold from the music source.
LED Mode
Yellow PCM 44.1/48kHz
White PCM 88.2/96/176.4/192/352.8/384kHz
Cyan DSD 64/128
Red DSD 256
Green MQA
Blue MQA Studio
Magenta Original Sample Rate*
*MQB
Warning: Installing GTO enabled firmware may result in the LED's on this device no longer
changing in accordance with the a bo ve table
4. ON/OFF and Analogue Volume Control
The analogue volume control in the hip dac Gold is audibly superior to
any digital volume control.
Warning: Due to the high power of hip dac Gold, always start off at a low volume level so
that there is no risk of damage to your headphones and your hearing. iFi audio is not
responsible for any hearing or equipment damage from misuse.
Power ON. Power OFF.
Tip: The hip dac Gold will continue to run from battery power even if the USB cable is
connected afterwards.
Tip: For connection to Apple devices, an Apple Lightning to USB Camera Adapter is
required. For connection to Android devices, USB On-The-Go (OTG) cable and
appropriate OS support are required.
For more information, please refer to www.ifi-audio.com
5. Balanced 4.4mm headphone output
Connect balanced 4.4mm headphones.
6. S-Balanced 3.5mm headphone output
Connect 3.5mm headphones.
