Seite 1/9
1
BTX8
Instruction Manual
11 Walters Drive, Osborne Park WA 6017
Ph: 1300 716 188
www.holmanindustries.com.au
iPhone
iGardener
D
E
S
I
G
N
E
D
&
E
N
G
I
N
E
E
R
E
D
A
U
S
T
R
A
L
I
A
N
2
WELCOME TO HOLMAN iGARDENERTM
Holman presents to you the Smart Control gardener range. We have an ever increasing range
of garden watering and irrigation control equipment that are controllable via your smartphone
in both iOS and Android formats.
iGardenerTM watering control products allow you to use your smartphone to control
all the programming and interface functions on your tap timers or irrigation controllers.
Download the app at no cost and you will soon have total control of your garden watering.
Introduction
The Holman iGardenerTM app allows you to control up to 8 controllers or tap timers. You are able to fully
control upto 8 zones on the BTX8. Each zone can be individually scheduled to suit the exact watering
schedule necessary for that zone.
Scheduling for each zone features 7 day watering, interval days, odd days and even days with the option
of setting your run time in hours and minutes with up to 3 start times per day.
The BTX8 also features cycle scheduling, which allows a run time and delay time. For example, you could
schedule a short burst of water to run for 1 minute every 20 minutes for 3 hours. The cycle feature is great
for the Holman GreenWall and for operating misting systems.
SIMPLE SETUP
Downloading the App 3
Renaming your Controller 4
Unpairing the Controller 4
Manual Operation of the Controller 5
Manual Operation Via the App 5
Locking the Controller 5
Troubleshooting 6
Device Compatibility 6
BTX8 Features 6
OPERATING THE IRRIGATION APP
Key Functions 7
7 Day Watering Schedule 8
Interval Days Watering Schedule 8
Odd Days (-31) Watering Schedule 9
Even Days Watering Schedule 9
Cycle Watering Schedule 10
Syncing Start Times 10
Saving your Schedule 11
CONTROLLER INSTALLATION
Mounting the Controller 12
Electrical Hook-up 12
Field Wiring Connections 12
Power Supply Connections 12
Pump Start Relay Connection
(Water Supply by Pump System) 13
Single Phase Pump Installation 13
Master Valve Installation
(Water Supply o Mains Water) 13
Zone Valve Installation 13
Pump Protection (System Test) 14
Servicing the Controller 14
Fault Finding Guide 15
WARRANTY 16
Contents
4
Renaming your Controller
You can rename your controller to distinguish it from other controllers you may have installed.
For example, you may have a controller operating the garden and lawns at the front of your house
and a separate controller for the backyard.
Enter your new name
and press Save.
Select Select Options. Change
Device Name.
Unpairing the Controller
To connect the controller to a new smartphone you will rst need to unpair it from the device it is currently
paired to.
VIA THE APP
Slide the menu bar to the left and press Delete.
This will remove your device from the controller
allowing it to be paired with another device.
MANUALLY
Turn the dial to the position on the Run & Lock
controller. Press and hold the button for Start
15 seconds. The controller is now unpaired.
WARNING: Disconnecting the power and removing the battery will reset all watering schedules.
To re-connect to the controller via the app, you will need to return the dial to Run & Connect.
