HikDashcam C8PRO
User Manual
1 2 34 5
A Legal Statement A Legal Statement
©2021 Hangzhou HikAuto Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instructions for using and managing the Product.
Pictures, charts, images and all other information hereinafter are for
description and explanation only. The information contained in the
Manual is subject to change, without notice, due to firmware updates
or other reasons.
Trademarks
•and other Hikvision's trademarks and logos
are the properties of Hikvision in various jurisdictions.
•Other trademarks and logos mentioned are the properties of
their respective owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS
MANUAL AND THE PRODUCT DESCRIBED, WITH ITS HARDWARE,
SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH ALL
FAULTS AND ERRORS”. HIKAUTO MAKES NO WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,
SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE
USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT
WILL HIKAUTO BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS,
DAMAGES FOR LOSS OF BUSINESS
PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION
OF SYSTEMS, OR LOSS OF DOCUMENTATION, WHETHER BASED ON
BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKAUTO HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR
INHERENT SECURITY RISKS, AND HIKAUTO SHALL NOT TAKE ANY
RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR
OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER,
HIKAUTO WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL
APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR ENSURING
THAT YOUR USE CONFORMS TO THE APPLICABLE LAW. ESPECIALLY,
YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT
DOES NOT INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING
WITHOUT LIMITATION, RIGHTS OF PUBLICITY, INTELLECTUAL
PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED
END-USES, INCLUDING THE DEVELOPMENT OR PRODUCTION OF
WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY
ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE OR
UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS
ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
FCC Information
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
residential environment. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized
European standards listed under the RE Directive
2014/53/EU, the EMC Directive 2014/30/EU, the LVD Directive
2014/35/EU, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon
the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol, which may include
lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For
proper recycling, return the battery to your supplier or to a designated
collection point. For more information see: www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards
requirements.
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
B Regulatory Information B Regulatory Information
The equipment should be installed and operated with a minimum
distance 20 cm between the radiator and your body.
B Regulatory Information C Safety Instruction
(2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radioexempts de licence. L'exploitation
est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Under Industry Canada regulations, this radio transmitter may
only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce
potential radio interference to other users, the antenna type and
its gain should be so chosen that the equivalent isotropically
radiated power (e.i.r.p.) is not more than that necessary for
successful communication.
Conformément à la réglementation d'Industrie Canada, le présent
émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou
inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le
but de réduire les risques de brouillage radioélectrique à
l'intention des autres utilisateurs, il faut choisir le type d'antenne
et son gain de sorte que la puissance isotrope rayonnée
équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à
l'établissement d'une communication satisfaisante.
This equipment should be installed and operated with a minimum
distance 20cm between the radiator and your body.
Cet équipement doit être installé et utilisé à une distance
minimale de 20 cm entre le radiateur et votre corps.
The temperature range for normal use of this product is -20
°C
~ 70
°C
.
Please do not use the recorder in high temperature, low temperature,
or high humidity environments; Avoid splashing this product with
water or exposing it to environments with high rain or dust density.
This product will be upgraded irregularly, and some features may
differ slightly from this manual. Please refer to the actual features of
the product for details.
-Battery is replaced by an incorrect type.
-Dispose of used batteries according to the instructions.
-Do not replace battery with an incorrect type.
-Do not disposal battery into fire or a hot oven, or mechanically
crushing or cutting of a battery, that can result in an explosion.
-Do not leaving battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of
flammable liquid or gas.
-Do not leaving battery subjected to extremely low air pressure that
may result in an explosion or the leakage of flammable liquid or gas.
-Do not used in low air pressure at high altitude condition.
-Do not used in high or low extreme temperatures.
UD25481B-A
E Parts Introduction F Installation G Mobile Phone Connection H Basic Description
7 8
I Troublshooting
9
I Troubleshooting
10 11 12
Model
Aperture
Pixel
Max. Resolution
Angle
Screen
Storage
G-Sensor
Wi-Fi
Sound Recording
Power Supply
Power Consumption
Operating Temperature and Humidity
Installation Type
Dimensions (L × W × H)
Weight
Max. Frame Rate
AE-DC8222-C8PRO
F1.55
3.5 K
3000*1688 P
Horizontal: 126°, Diagonal: 151°, Vertical: 66°
2.4”
TF Card, 32 GB to 256 GB
Built-in, collision triggered recording and recording lock
Yes
Yes
5 VDC, 2 A
Approx. 5 W
-20 °C to 70 °C (-4 F to 158 F). Humidity 95% or less.
General
105 × 49 × 39mm (4.1ʺ × 1.9ʺ × 1.5ʺ)
Approx. 152 g (0.34 lb.)
1080 P @ 80 fps
Scan QR Code
<
·
·
·
··
·
·
·
··
·
·
·
··
·
·
·
··
·
·
·
··
·
·
·
··
·
·
·
··
·
·
·
··
·
·
·
··
·
·
·
··
·
·
·
··
·
·
·
··
·
·
·
··
·
·
·
··
·
·
·
·
·
·
Specifications
1
Clean the windshield and
paste the electrostatic film
onto it.
Avoid introducing air bubble.
DO NOT paste the film
repeatedly.
Paste the device onto the
electrostatic film and route
cable to the disaster box for
power supply.
Connect the charger as
the figure above.
Adjust the angle to the
target direction.
Scan the QR code to download and
install HikDashcam app.
Add the dashcam to the app.
a. Run the HikDashcam app.
b. Tap Wi-Fi Connection.
c. In Wi-Fi list, select the Wi-Fi SSID
of the target dashcam and enter
Wi-Fi password to build
connection.
•You can set the parameters of the
dashcam.
•For iOS, you need to go to Wi-Fi
settings of your phone to connect
to the Wi-Fi of dashcam.
Edit the dashcam password to
activate it to avoid abnormal
recording after connecting to Wi-Fi.
1
Dashcam Wi-Fi default parameters:
•Wi-Fi SSID: HIKVISION-C8PRO-XXXX
(XXXX refers to the last four
characters of verification code.)
•Wi-Fi password: 1234567890
(please edit password after logging in
for the first time.)
Start Up
Connect the power cord to the car battery.
Device starts recording automatically once the car started.
Trouble Solution SolutionTrouble
The dashcam drops
easily.
Starting the dashcam
failed.
The dashcam powers
off easily.
Recording is
abnormal and
indicator is unlit.
Recording is blurred.
Recording is mute.
Dashcam reboots
itself.
Clean the windshield before installation.
Check whether the vehicle is started and power
supply is normal.
Check whether the car charger is tightly connected.
Restore to defaults: hold the button until theRESET
startup music is heard.
Make sure the power cord is in good condition.
Make sure the power cord is tightly connected to the
according interfaces.
Make sure that the dashcam started up successfully.
Check whether the TF card is inserted.
Check the status of TF card, e.g. its format, its lifespan.
Change TF card if it is not well.
Make sure the protective film is peeled off.
Check whether the windshield or the lens of dashcam
is blurred.
Set audio settings on the device or turn on sound
recording in HikDashcam app.
Check whether the car charger is equipped with power
supply interface of 5 VDC, ≥ 2 A.
The mobile phone
cannot display
recordings.
It may be relevant with the player or system of the
phone. Please connect TF card to your computer and
display the recordings.
TF card is not
detected when you
connect dashcam to
computer with the
supplied power cord.
Dashcam does not support data transmission and the
supplied power cord is only for charging.
If you need to transfer data, please connect TF card
to your computer.
Wi-Fi connection
takes a long time.
It may be caused by the interferrence of the
surrounding Wi-Fi signals. Please use the dashcam in
an environment of less interferrence.
Shut down unnecessary programs in your phone to
release some resources for HikDashcam app and
reconnect Wi-Fi.
Dashcam Wi-Fi
password is forgotten.
The default password is 1234567890. If you have
revisied the password, regain the password by the
following steps.
1. Hold the button on dashcam until the startupRESET
music is heard and the dashcam is restored to
defaults.
2. Go to Wi-Fi Connection interface in HikDashcam
app.
3. Select Wi-Fi SSID and log in with default password
1234567890.
1
2
3
·Check whether the car charger is tightly connected.
·Check whether the 3M tape is tightly sticked to the
electrostatic film before the installation.
·Turn on sound through the the audio control function
of the dashcam.
·
·
Mobile phone cannot
connect to dashcam.
Make sure HikDashcam app is installed.
Please restart the dashcam to the app.
No GPS signal. ·
·
Check whether the GPS function is enabled.
Normally, the GPS function is enabled by default.
Make sure the device is not in the places of weak
signal or no signal, such as underground garage.
·Make sure there is no metal around the device
·
because metal will interfere with GPS signal.
Make sure the location where the device is installed is
not pastd with radiation protection film. The film will
interfere with GPS signal.
1. Camera
2. Holder
3. Loudspeaker
6. Mini USB Interface
Access to GPS module
5. Camera Interface
7. Microphone
8. TF Card Slot
9. RESET Button
10. Screen
4. Power Supply Interface
When the car is off, device turns into parked monitoring mode and start to record
once the current scene changed or collision happened.
2
43
Recording
Recordings are divided to ordinary video and emergency video.
You can set the video voice on/off via System Settings or
Hikdashcam APP.
When recording with 60 fps, the device will actively shut down
adas and rear camera.
D Packing List
6
1
23
5
4
1.Dashcam × 1
2.Charger × 1
3. Power Cable × 1
4 . Electrostatic Film × 1
5 . User Manual × 1
Produktspezifikationen
| Marke: | Hikvision |
| Kategorie: | Dashcam |
| Modell: | AE-DC8222-C8PRO |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Hikvision AE-DC8222-C8PRO benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Dashcam Hikvision
5 September 2024
5 September 2024
5 September 2024
5 September 2024
5 September 2024
21 August 2024
10 August 2024
30 Juli 2024
Bedienungsanleitung Dashcam
- Dashcam Gembird
- Dashcam Genius
- Dashcam Hama
- Dashcam HP
- Dashcam Nedis
- Dashcam Niceboy
- Dashcam Philips
- Dashcam AEG
- Dashcam Dymond
- Dashcam Maginon
- Dashcam Technaxx
- Dashcam Denver
- Dashcam König
- Dashcam Trevi
- Dashcam Blaupunkt
- Dashcam Kenwood
- Dashcam Trebs
- Dashcam Dometic
- Dashcam Pyle
- Dashcam Salora
- Dashcam Aiptek
- Dashcam Caliber
- Dashcam Pioneer
- Dashcam JVC
- Dashcam Motorola
- Dashcam Xiaomi
- Dashcam Elro
- Dashcam Ferguson
- Dashcam Garmin
- Dashcam GOCLEVER
- Dashcam Lamax
- Dashcam Mio
- Dashcam Sencor
- Dashcam Waeco
- Dashcam Scosche
- Dashcam XOMAX
- Dashcam Guardo
- Dashcam Midland
- Dashcam Alpine
- Dashcam Minolta
- Dashcam Rollei
- Dashcam EUFAB
- Dashcam Pro User
- Dashcam Toyota
- Dashcam ADATA
- Dashcam Overmax
- Dashcam Monacor
- Dashcam Ednet
- Dashcam Osram
- Dashcam NextBase
- Dashcam Uniden
- Dashcam Clarion
- Dashcam Kogan
- Dashcam Jobo
- Dashcam Skytronic
- Dashcam Audiovox
- Dashcam Navitel
- Dashcam Navman
- Dashcam Cobra
- Dashcam CamOne
- Dashcam EVOLVEO
- Dashcam TrueCam
- Dashcam ION
- Dashcam DNT
- Dashcam Swann
- Dashcam Xblitz
- Dashcam Prestigio
- Dashcam Tracer
- Dashcam Boss
- Dashcam Mini
- Dashcam Hertz
- Dashcam Jensen
- Dashcam Transcend
- Dashcam DOD
- Dashcam Innovv
- Dashcam IRoad
- Dashcam Laser
- Dashcam Lidl
- Dashcam Media-tech
- Dashcam Naxa
- Dashcam Nordval
- Dashcam Roadeyes
- Dashcam Steren
- Dashcam Thinkware
- Dashcam Veho
- Dashcam NAV-TV
- Dashcam Metra
- Dashcam ModeCom
- Dashcam CRUX
- Dashcam Escort
- Dashcam Brigmton
- Dashcam Kaiser Baas
- Dashcam KJB Security Products
- Dashcam BlackVue
- Dashcam Valueline
- Dashcam Braun Phototechnik
- Dashcam BLOW
- Dashcam Boyo
- Dashcam Cowon
- Dashcam Rexing
- Dashcam Dashmate
- Dashcam EchoMaster
- Dashcam AZDome
- Dashcam Carmera
- Dashcam VIOFO
- Dashcam Mobileye
- Dashcam Kapture
- Dashcam ProUser
- Dashcam Nanocam+
- Dashcam Vicovation
- Dashcam Andatech
- Dashcam RIPOON
Neueste Bedienungsanleitung für -Kategorien-
16 Oktober 2024
15 Oktober 2024
9 Oktober 2024
4 Oktober 2024
3 Oktober 2024
30 September 2024
27 September 2024
27 September 2024
24 September 2024
22 September 2024
