Thank you for choosing the Module. Heritage Audio is dedicated to bringing you ´the sound of yesterday for 8173
tomorrow´. We specialize in capturing that unique, enticing sound that everybody has fallen in love with. For years
engineers, producers and musicians have been yearning for that classic vibe. Usually the only option is to search for
old, used original equipment that is almost always in a questionable state of operation. This brings with it a whole lot of
other issues, making the experience less than desirable. Not to mention the very high prices asked for this equipment,
which makes them virtually unobtainable for the great majority. Now it´s possible to obtain that same sound with a
brand new piece that will give you all the problem-free, heavy-duty use you´ll need for years of music making history.
Peter Rodriguez
CEO!
Heritage Audio - Madrid, Spain
INTRODUCTION
© 2023 Heritage Audio S.L. is the sole owner of the copyright of all information and drawings contained in this manual which are not to be copied o
reproduced by any means or disclosed in part or whole to any third party without written permission.
Heritage Audio reserves the right to alter specifications without notice. The information in this manual has been carefully checked and is believed to
be accurate at the time of publication. However, no responsibility is taken by us for inaccuracies, errors or omissions nor any liability assumed for any
loss or damage resulting either directly or indirectly from use of the information contained within it.
8173 MODULE
DESCRIPTION
The best 80 Series sculpting tool
Leverage your 80 Series´s investment with the Heritage Audio 8173.!
The 8173 module is a Heritage Audio unique design, which has been engineered to fill input module slots in the
restoration process of vintage 80 Series sound mixing consoles. It is also compatible with the Heritage Audio FRAME 8 "
and RACK 2 powered enclosures, and with any other rack, console or enclosure that follows the same mechanical and
electrical protocol.
Don’t settle with the same old song, the 8173 offers what the vintage modules do plus more
The 8173 has a Class A Mic preamp with 80 dB of gain to make sure you´re never lacking for more. This gives you "
more than enough even for demanding ribbon mics and older dynamic mics, which are often low output. With the 8173 "
your mic collection has never sounded better. "
There is also a Class A line-level amplifier with 10 dB of additional gain as well as -20 dB for when you need to reduce a
very high signal coming into the unit before EQing it. Both the Mic preamp and the Line amplifier have their own "
separate exclusive Carnhill transformers to guarantee solid, professional results. "
""""""" """"""""""""""""""""""""""""""""""""""""""""
The 8173 is a 73-sized module, adding the 81 mid bands to the 73 classic design, creating an equalizer that is really
hard to beat. It features a Baxandall type high shelf band, but with the addition of a high frequency selector switch
offering 3 different frequencies instead of the fixed one at 12 kHz. There are also two Mid peak bands (Hi & Low) with
10 selectable frequencies to choose from each in addition to the OFF position that removes the filter from the signal
path. Then you have a Low Shelf band, also of the Baxandall type, with 4 selectable frequencies available for some "
incredible low end shaping. The result is a 4-band tone monster that combines the best features of the vintage modules "
in a smart and tasteful way, at a price lower than most current offerings. And not to be overlooked, the 8173 has a "
Class A High Pass Filter with 3 frequencies to choose from to make you can clean up the very low end allowing more
room to achieve the sound you want. "
Vintage connoisseurs and plug-in users already know how cool the 81 mid bands are for sculpting sounds in a musical
way. This level of flexibility has never been present in a 73 style module and will certainly make finding that elusive
sound much easier.
To get the desired results it´s necessary to use the right components
Special care has been taken in sourcing the correct components that not only ensure that performance will be as close
to a 1970´s unit as possible, but also gives your top-class studio the look and feel it deserves to help enhance the
overall experience.
Custom polystyrene and film capacitors have been developed to closely match the Siemens styroflex and Mullard
Mustard types of the late 60s and early 70s. This attention to detail is reflected in the unit´s performance and is "
appreciated by the end user.
Carnhill input transformers are hand wound at its Oxford factory exclusively for Heritage Audio, enclosed in vintage
correct green metal cases for the ultimate in detail nailing. The vintage character is indeed guaranteed and you won´t
find them in any other brand´s products.
The Heritage Audio 8173 is entirely handmade and hand wired by only our most experienced technicians in our facilities
in Madrid, Spain, employing the same wiring and soldering techniques of the 70s. All its circuitry is conveniently held on
5 plug-in cards.
3
