Seite 1/4
FRANKE USER INSTRUCTIONS AND
GUARANTEE FOR MIXERS
FRANKE ACTIVE
TA 7010 SWIVEL
Instruction code: IISTROZ913/3T5PER#C08528 Rev 06/2012.
Australian Approvals
• This mixer complies to Australian and New Zealand Standards AS/NZS 6400.
• The mixer has 4 Star water efficiency rating under the WELS Scheme with water
consumption of 7.5 liters per minute.
15 YEAR WARRANTY
Fifteen (15) year warranty applies to replacement ceramic cartridge, î™ve (5) years parts and labour starting from date of purchase of
product. After î™ve (5) years, a further additional ten (10) years replacement ceramic cartridge warranty is applicable. This extended part-only
warranty is non-transferable and applies only to the original purchaser. The guarantee only applies if the mixer is installed with pressure
limiting valves.
Any faults caused by defective production will be replaced free-of-charge during the guarantee period.
Any such faults will be replaced, at the sole discretion of Franke, either by repairing faulty components or by replacing the whole product
with the same or an equivalent model where the balance of the warranty period from the original date of purchase will take eect. The
Company is not liable for damage caused by: a) improper or unsuitable use and/or maintenance - b) transport - c) knocks, tampering,
incorrect repairs and repairs made by unauthorised technicians - d) normal wear of components (non-return valve, membrane, etc.) and/or
the use of non-original spare parts - e) non-compliance with the technical instructions - f) freezing and/or impurities in the water pipes.
The guarantee only applies if a document proving the date of purchase is produced.
The guarantee covers all the countries where Franke products are sold, either directly or through an authorised distributor.
The guarantee does not cover product assembly or disassembly charges, visits and calls of specialised technicians, costs borne by the
customer due to the unavailability and/or non-use of the product.
Any imperfections in the î™nishes or in the natural materials used should not be considered as faults but a typical characteristic of these
crafted products.
In the case of various accessible visible components and products requiring only minor rectiî™cation under guarantee, Franke reserves the
right to supply these on a “parts only” basis to the customer. Such articles may include accessories, aerators, hand sprays, hoses, handles,
levers, î™xings, washers and dress î™ttings, etc.
IMPORTANT INFORMATION
Flush out pipe work prior to connecting your new mixer.
All mixers to be installed with isolating stop cocks.
Tap must be installed with pressure limiting valves.
Mixer should be installed by a qualiî™ed plumber.
This mixer is designed for domestic use only.
Failure to comply will void all warranty.
Franke has a service network in all metropolitan areas and most regional areas. Where the warranty claim has been made outside a radius of
50km from any store where the product can be purchased, the customer is responsible for the cost of delivery to the nearest service agent
or the travel cost for a technician to travel to a location outside the 50km radius, unless agreed otherwise with the company.
Should you ever need to make a warranty related enquiry about your Franke product, simply call (03) 9700 9100 to speak with our friendly
customer service consultants. We suggest you have the following information close at hand to make the process as easy as possible:
1. Model number of your tap
2. A copy of your original purchase receipt
3. Address details of where the tap is installed
Alternatively, you may email, fax or post a service request to the details provided below.
Any associated or ancillary costs to be incurred by you as a result of replacement or repair of Franke taps under this guarantee shall, in all
cases, be previously approved by PR Kitchen Systems Pty Ltd. Please note: The beneî™ts provided under this warranty are additional to other
rights and remedies available to the customer under the Australian Customer Law.
YOUR STATUTORY RIGHTS
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or a refund
for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
PR Kitchen Systems Pty Ltd
83 Bangholme Road, Dandenong South VIC 3175
Ph (03) 9700 9100
Fax (03) 9700 9191
For further information on Franke kitchen
sinks, taps, waste management systems and
accessories visit our website or contact us for
your nearest retailer.
www.franke.com.au
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Franke care instructions.
• Periodically clean the aerator filter;
• Install filter valves under the sink and periodically clean the filters;
• DO NOT USE DETERGENTS, SOLVENTS, CHEMICAL AGENTS, ABRASIVE
SPONGES, WIRE WOOL OR ALCOHOL, ETC., which would irreparably damage
the surface of the product and ruin its appearance, sheen and matt finishes;
• CLEAN WITH SOAPY WATER AND DRY WITH A SOFT CLOTH;
• Dry the product after use if the water is very hard or aggressive, as it may
leave deposits which would damage the surface;
• Do not install the tap when the water pressure exceeds 500 kpa (in this case
pressure limiting valves are required);
• Rinse the water pipes before installing the tap.
Technical Information
• Maximum hot temperature 80° (Recommended 65°)
• Maximum operating pressure 75 psi / 500 kpa
• Minimum operating pressure 7.25 psi / 50 kpa
• Ceramic cartridge
C
- Close the water.
- Connect the flexibles 9 (red hot water, blue cold water) to the body 1.
- Place the washer 2 over the sink hole.
- Introduce the body 1 into the sink hole with the tie rod 3 in the front side.
- Introduce the washer 4 under the sink.
- Place the fixing plate 5 under the sink.
- Introduce the shaped washer 6 in the tie rod 3.
- Introduce the fixing plate 7 in the tie rod 3.
- Tighten the whole by screwing the fixing nut 8 on the tie rod 3.
- Connect the flexibles 9 to the water supply-pipes or to filter taps (not included in the packaging).
- Open the water.
Franke installation instructions.
Chrome Handle
1988807
Cartridge
1988154
Chrome
Handle
1988807
Tap body
Rubber seal
Fixing thread
Under sink washer
Fixing plate
Shaped washer
Fixing plate
Brass fixing nut
Flexible hose
1
2
3
4
5
6
7
8
9
Aerator
1499
Flexible Hose
203/54
