Operating Instructions
Connect your guitar to the INPUT jack of the Walking On The Moon (WOTM)
and the FLANGED OUT jack to your amp’s input. Plug in the included power
supply and insert its output plug into the WOTM’s power jack. Press the
footswitch to ensure the red LED is lit, the WOTM is now ready to play.
To get started, try the following setting:
COLOR: 12 o’clock 9 o’clock RANGE: RATE: 9 o’clock
POWER SUPPY REQUIREMENTS:
Voltage: Current: Polarity: 9VDC 40mA Center-Negative
This device comes equipped with an Electro-Harmonix 9.6DC-200 power supply. It requires 40mA at 9VDC
with a center negative plug. Use of the wrong adapter or a plug with the wrong polarity may damage the
device and void the warranty. Do not exceed 10.5VDC on the power plug. Power supplies rated for less
than 50mA will cause the device to act unreliably. The Walking On The Moon also accepts 9V batteries,
we recommend alkaline.
Congratulations on your purchase of the Andy Summers Walking
On The Moon Flanger/Filter Matrix! Over the past six decades,
Andy Summers has relied on anger effects to dene his signature
sound palate, enabling him to create the lush and shimmering
guitar tones that made Andy Summers famous all over the world
and especially beloved by guitar players.
- 2 -
1. COLOR Knob sets the intensity of the anger effect. As you turn COLOR
clockwise, the effect becomes more pronounced, producing that classic
whoosh effect angers are famous for.
Your WOTM has been set at the factory for maximum color capacity.
Turning COLOR up to maximum could cause self-oscillation to occur.
This is normal! The oscillation may be reduced by turning down the
COLOR knob one or two notches.
2. RANGE Knob allows you to set the lower limit of the anger sweep.
A fully counterclockwise setting, where the lower limit is just below the
higher limit, creates a narrow sweep effect. As you turn RANGE clock-
wise the anger sweeps down further into the bass region.
Controls and Connections
- 3 -
3. RATE Knob controls the speed of anger modulation. As you turn
RATE clockwise, the anger’s speed increases. Higher settings of RATE
give the effect a sound like vibrato.
4. FILTER MATRIX Switch when this switch is set to the right position,
labeled FILTER MATRIX, the modulation waveform is disconnected from
the anger circuit, freezing the anger and creating a matrix of lters.
Turn the RANGE knob to change the lters’ position and use COLOR to
adjust the depth of ltering. The RATE knob has no effect when set to
FILTER MATRIX mode. Proper manipulation of the RANGE and COLOR
knobs will enable you to simulate the sound of chimes being played in
unison with your instrument, as well as many other effects.
5. FOOTSWITCH and STATUS LED Use the footswitch to switch between
bypass and effect mode. The LED is off when WOTM is in true bypass
mode. When WOTM is active, the LED is lit.
6. INPUT Jack Audio input to WOTM.
7. FLANGED OUT Jack Main audio output from WOTM. All anging and
modulation effects will emanate from this jack.
8. DRY OUT Jack Secondary audio output from WOTM. DRY OUT is di-
rectly connected to the INPUT jack in all modes.
9. 9V Power Jack Attach the output plug from the included power supply
to the 9V power jack. WOTM draws 40mA at 9VDC on a center-negative
plug. Do not exceed 10.5VDC on the power jack.
To power WOTM from a 9V battery, you must remove the 4 screws holding
the bottom plate. Once the screws are removed, detach the bottom plate
and connect a 9V battery. Please do not touch the circuit board while the
bottom plate is off or you risk damaging a component.
Notes and Specications
t Audio input impedance at INPUT jack: 600kΩ
t Audio output impedance at FLANGED OUT jack: 5.5kΩ
t Current draw: 40mA at 9.0VDC
t Maximum Input Signal (before clipping): 0 dBu
t Maximum Output Signal: +4 dB
