TALKING PEDAL
VOWEL WAH WITH FUZZ
Congratulations on your purchase of the Electro-Harmonix TALKING PEDAL
from our ground-breaking NEXT STEP series! The has no TALKING PEDAL
moving parts: it does not use a potentiometer, optics or magnetism to sweep
its dual-bandpass analog filters. The result is a responsive pedal that allows
precise control over the throaty vocal effect of the TALKING PEDAL.
Additionally, a level controllable fuzz circuit is included to add extra growl to
your vowels.
GETTING STARTED
Plug your guitar into the INPUT jack; connect your amp to the OUTPUT jack.
Within seconds the EHX logo in the center of the pedal will light. Your
TALKING PEDAL is ready to go! as long as a plug is inserted Please note:
into the INPUT jack, a drain is placed on the 9V battery inside the TALKING
PEDAL. We recommend unplugging the INPUT jack when the TALKING
PEDAL is not in use to extend battery life.
FUZZ LEVEL Control
The fuzz in the TALKING PEDAL helps to accentuate the vocal effect,
bringing out a more distinct talking quality in the pedal. You do not need to
maximize the FUZZ LEVEL in order to hear a more talkative effect, a little can
go a long way.
The FUZZ LEVEL dial located on the INPUT side of the TALKING PEDAL is a
blend control for the fuzz circuit. As the numbers increase on the dial, the
volume of the fuzz effect increases. The maximum setting of 10 should yield
a bit of volume boost as compared to your bypass volume.
CALIBRATION
To ensure the TALKING PEDAL responds to its full sweep range, it may be
necessary to calibrate the sweep of the TALKING PEDAL when it is used on a
different surface since its last use. It is particularly important to calibrate if
the TALKING PEDAL is used on a slanted surface. We also recommend
calibrating the TALKING PEDAL during your first use of the pedal.
CALIBRATION PROCEDURE
1. Place the pedal on the surface where it will be used.
2. Ensure the TALKING PEDAL is sitting flat on the surface then press
and release the CALIBRATE button once; the EHX logo begins to
blink indicating the Toe position has been saved.
3. While the EHX logo continues to blink, rock the pedal all the way
back to the extreme Heel position and hold it there.
4. Press and release the CALIBRATE button once more.
5. The EHX logo will stop blinking to indicate that the Heel position has
been saved.
If you accidentally press the CALIBRATE button and the EHX logo blinks, do
not press CALIBRATE again. After approximately 7 seconds, the TALKING
PEDAL will stop blinking and ignore the button press.
ENTERING/EXITING BYPASS
Toggle between and effect mode by tipping the TALKING buffered bypass
PEDAL forward, in the toe direction, past the flat position of the TALKING
PEDAL. You do not need to tip the TALKING PEDAL all the way forward;
25% of the total forward travel will do it. The TALKING PEDAL needs to
return to its flat position before you can toggle between bypass and effect
mode again.
When the TALKING PEDAL is in effect mode, the EHX logo in the center of
the pedal will light up. In bypass mode, the logo does not light.
POWER
Plugging into the INPUT jack activates power from the internal 9 Volt
battery. The input cable should be removed when the unit is not in use to
avoid running down the battery. If an AC Adapter is used, the TALKING
PEDAL will be powered up as long as the AC Adapter is correctly plugged in.
The TALKING PEDAL’s power jack is located on the same side as the
OUTPUT jack. A 9 Volt AC Adapter capable of delivering at least 25mA of
current at 9VDC is required to power the TALKING PEDAL. The inner ring of
the 9 Volt AC Adapter must be negative, the outer ring positive. The optional
9V power supply from Electro-Harmonix is 9.6DC-200BI (same as used by
Boss® & Ibanez®) 9.6 Volts DC/200mA. The unit’s battery may be left in or
taken out when the AC Adapter is in use. The actual current draw of the
TALKING PEDAL is 12mA.
CHANGING THE BATTERY
1. Locate the battery door at the front of the TALKING PEDAL, under
the Toe area of the top plate.
2. Remove the large black screw that holds the battery door to the
case, most coins or larger slotted screwdrivers can be used to
remove this screw.
3. Connect your new 9V battery to the wired battery connector.
4. Insert the 9V battery into the battery holder clip on the battery door
so that the wired connector is on the same side as the hole in the
battery door.
5. Place the battery door back into its window in the case of the
TALKING PEDAL
6. Re-install the screw.
NOTES AND SPECIFICATIONS
TALKING PEDAL has buffered bypass.
•  The input impedance presented at the INPUT Jack is 1M .
•  The output impedance at the OUTPUT Jack is 1k .
The current draw of the TALKING PEDAL is 12mA.
