Seite 1/2
1.
2.
3.
4.
5.
6.
7.
LANC port
Reducer bushing/adapter **
Allen keys
3/8”-16 Mounting screw
Built-in LP-E6 battery bracket*
Shutter trigger port
3/8”-16 Mounting port
You can use your SliderONE on a tripod
or ïŹ‚at surface.
Place the SliderONE on your tripod and
rotate until it is tight.
SliderONE has 3/8”-16 screw on top for
your tripod head. Place your tripod head
or your edelkrone FlexTILT Head on
SliderONE and rotate until it is tight.
Attach your camera to your tripod head.
Now, you are ready to slide.
Reducer busing is attached to the
3/8”-16 mounting port. If your tripod has
3/8”-16 mounting screw, you need to
dettach the 3/8”-16 reducer bushing by
turning it counter clockwise.
1.
2.
3.
4.
1
2
4
1
4
2
3
TABLE OF CONTENTS
WHAT’S IN THE BOX & THE BASICS
MOUNTING YOUR SLIDERONE ON A TRIPOD
USING WITH FLEXTILT HEAD
ADJUSTMENTS
START USING
1.
2.
3.
4.
5.
1. WHAT’S IN THE BOX & THE BASICS
A detailed video explaining the mounting process can be found at:
http://edel.kr/so
2. MOUNTING SLIDERONE ON A TRIPOD
The FlexTILT Head is recommended
as a tripod head solution for the
SliderONE.
With the FlexTILT Head 2,
you can easily:
-Adjust the center of gravity,
-Pan/tilt, and
-Change the height of the camera.
3. USING WITH FLEXTILT HEAD
A detailed video explaining how to operate the SliderONE can be found from :
manuals.edelkrone.com
A detailed video explaining how to use the FlexTILT Head with SliderONE
can be found at: http://edel.kr/so
7
6
3
5
*The battery bracket is located in different places in SliderONE v2
& SliderONE PRO v2.
**Reducer busing (6) is attached to the 3/8”-16 mounting port (4)
There are adjustment screws on the SliderONE. If you think there is a play
on the carriage (1), use the indicated screws for adjustment. To do that, push
from the sides of the carriage (2) and thighten the screws.
4. ADJUSTMENTS 5. START USING
Download the edelkrone App to your mobile device from the App Store or
Google Play. Links can be found at www.edelkrone.com/products/sliderone-v2.
There are no on/off buttons on SliderONE. To turn on, attach the battery to the
SliderONE.
SliderONE will start the calibration and detect the limits of the slider.
edelkrone App will automatically pair with your SliderONE.
You are now ready to use your SliderONE!
1.
2.
3.
4.
5.
Battery is not included.
Make sure your mobile device’s Bluetooth connection is on.
Always start using with a fully charged battery.
A detailed video explaining the application usage details can be found at:
http://edel.kr/so
A detailed video explaining how to adjust your SliderONE details can be
found at: http://edel.kr/so
USER’S MANUAL
SLIDERONE &
SLIDERONE PRO
Before operating your edelkrone,
please watch the user’s manual video from the link below
http://edel.kr/so
1
2
DISPOSAL OF THE PRODUCT & WARNINGS
For more information and tips about your SliderONE, please watch the user’s
manual videos at: http://edel.kr/so
Should the product become damaged beyond repair, or if you wish to
dispose of it, it must be disposed separately from the municipal waste
stream via designated collection facilities appointed by the government or
the local authorities. Observe the regulations of your area and country that
relate to the disposal of electronic products.
* Keep your electronic Motion Control Unit away from all sorts of liquids.
* Do not attempt to disassemble or modify any internal parts of your Motion Control Unit. If the
device appears to be malfunctioning, discontinue use immediately and contact support for
qualiïŹed service.
* Never force a different type of connector into a port.
* Never use or store your Motion Control Unit in areas subject to extreme temperatures, or high
levels of vibration.
* Environmental factors may affect your Motion Control Unit’s performance. Keep your product
away from environmental hazards such as dust or heavy resonance. Do not use chemical
materials to clean your product.
* Avoid dropping or causing physical damage to your Motion Control Unit.
* Do not place heavy objects on top of your Motion Control Unit.
**edelkrone cannot be held responsible for damage caused by improper use or
modiïŹcation of the product.
