Seite 1/3
POS 02
POS 02
POS Mount
INSTALATION MANUAL / INSTRUKCJA MONTAŻU
WARNING:
Please read this manual before the installation to ensure proper assembly.
The assembly should be carried out in accordance with this manual by at least
two persons with proper qualifications in assembly. EDBAK Company shall not be
liable for any material or property damage or bodily injury resulting from improper
assembly. Therefore, you should always follow the instructions:
- during the assembly, please follow the instructions carefully. Otherwise, it may
result in product damage or even personal injury;
- before the assembly you must ensure that under the surface of the wall where
the mount is to be fixed there are no power cables, water or sewage pipes or gas
installations;
- while fixing the screen on the mount, please ensure that the screws are of proper
length and diameter. In order to ensure the right length and diameter, you may use
the accompanying plastic pads. Use of improper screws may result in permanent
product damage. Extra caution should be given with movable elements in order to
prevent crushing or pressing your hands or fingers. This manual indicates such
elements.
The terms of the product guarantee are set forth in the guarantee card
OSTRZEŻENIE:
Przed rozpoczęciem montażu należy uważnie zapoznać się z instrukcją uchwytu
oraz ekranu w celu zapewnienia prawidłowego montażu.
Prace montażowe powinny wykonywać co najmniej dwie osoby posiadające kwalifi-
kacje w zakresie montażu zgodnie z niniejszą instrukcją.
Firma EDBAK nie bierze odpowiedzialności za straty materialne oraz uszkodzenia
mienia lub ciała, wynikające z nieprawidłowego montażu. Dlatego należy zawsze
przestrzegać:
- w trakcie montażu dokładnie przestrzegać załączonej do produktu instrukcji mon-
tażowej, w przeciwnym razie może to prowadzić do zniszczenia sprzętu, a nawet
uszkodzeń ciała,
- koniecznie przed montażem upewnić się, że pod powierzchnią ściany, na której
będzie mocowany uchwyt nie ma kabli elektrycznych, rur wodnokanalizacyjnych lub
instalacji gazowych,
- w trakcie montażu ekranu do uchwytu upewnić się, że użyte śruby dobrze do-
brane co do długości i średnicy. W celu idealnego dobrania długości śrub można
skorzystać z dołączonych podkładek plastikowych. Zastosowanie niewłaściwych
śrub grozi trwałym uszkodzeniem sprzętu,
- w miejscach wskazanych w instrukcji, w których ruchome elementy uchwytu
zachować szczególną ostrożność w celu uniknięcia przyciśnięcia, dłoni i palców.
Warunki gwarancji wg załączonej do produktu karty gwarancyjnej.
POS 02 POS 02
2.
3
ADIN 7991
M6x40
4
szt
BDIN 934 M6 4
szt
CDIN 125 6,4 4
szt
art list
Elementy do montażu POS 02
B
A
2
Checklist/Lista element w Assembly/Montaż
1.
Drill mounting holes in the top
Wykonać otwory montażowe 4 x
Assembly/Montaż
A (4x)
B (4x)
C (4x)
C
Installation tools /not included/
Narzędzia montażowe /niezałączone/
Assembling mount to the top
Montaż uchwytu do blatu
EN
PL
EN
PL
POS 02
54
3.
Assembly/Montaż
Pull the wires through the mounting space
Przeciągnąć przewody poprzez kanał montażowy
EDBAK Sp. z o.o.
Piotrowice 186, 23-107 Strzyżewice
Tel. +48 81 562 81 19
POS 02- POS Mount
Technical drawing/ Rysunek techniczny
EN
PL
