Seite 1/4
ADI-101
Highlite International B.V. Vestastraat 2 6468 EX Kerkrade the Netherlands – – – –
Ordercode: D1946
MANUAL
ENGLISH
Active Direct Inject Box
1
ADI-101 Active Direct Inject Box
D1946
Warning
Every person involved with the installation, operation and maintenance of this system has to:
ï‚· be qualified
ï‚· follow the instructions of this manual
Description
The ADI-101 is created to help professionals who haven’t got the time for interference. It will protect your
system for ground loops, potential hum and buzz. Due to the solide metal body and rubber feet, it is very
road-proof.
ï‚· Roadproof housing with rubber feet
ï‚· Low distortion
ï‚· 9V power supply ore 18-48V phantom power
ï‚· Ground lift
ï‚· -20 and -40dB Attenuation switch
Overview
Pad function: Off / -20 dB / -40 dB
Unbalanced input 1/4" TRS socket,
Balanced input XLR socket
Link signal
Power LED (9V battery LED blinks, +48V phantom power LED is lit continuously) – –
Power Switch
Ground lift switch.
Balanced XLR output connector.
9V Battery compartment
CAUTION!
Keep this device away from rain and moisture!
2
ADI-101 Active Direct Inject Box
D1946
Connection Example
