Crestron CLS/CLSI-C6 & CLS/CLSI-C6M
iLux® Integrated Lighting System
Operations Guide
The specific patents that cover Crestron products are listed at patents.crestron.com.
Crestron, the Crestron logo, Cameo, Cresnet, Crestron Green Light, Crestron RoomView, Crestron Studio, Crestron Toolbox, iLux, and Isys are either
trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries. Somfy is either a trademark or registered
trademark of Somfy SAS in the United States and/or other countries. UL and the UL logo are either trademarks or registered trademarks of
Underwriters Laboratories, Inc. in the United States and/or other countries. Other trademarks, registered trademarks and trade names may be used in
this document to refer to either the entities clai disclaims any proprietary interest in the marks and ming the marks and names or their products. Crestron
names of others. Crestron is not responsible for errors in typography or photography.
This document was written by the Technical Publications department at Crestron.
©2013 Crestron Electronics, Inc.
Regulatory Compliance
This product is Listed to applicable UL Standards and requirements by Underwriters Laboratories Inc.
As of the date of manufacture, the CLS C6M have been tested and found - - - , -C6, CLS C6M, CLSI C6 and CLS
to comply with specifications for CE marking and standards per EMC and Radiocommunications
Compliance Labelling.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Industry Canada (IC) Compliance Statement
CAN ICES-3(B)/NMB 3(B)-
Crestron CLS/CLSI /CLSI-C6 & CLS -C6M iLux Integrated Lighting System
Operations Guide – G DOC. 6347 Contents
•
•
•
•• i
Contents
iLux Integrated Lighting System: CLS/CLSI- - 1C6 & CLS/CLSI C6M
Introduction 1...............................................................................................................................
Features and Functions ................................................................................................ 1
Specifications .............................................................................................................. 4
Physical Description .................................................................................................... 6
Setup ........................................................................................................................................ 11
Network Wiring ......................................................................................................... 11
Net ID ........................................................................................................................ 11
Installation ................................................................................................................. 11
Configuring the CLS- C6.......................................................................................................... 12
Configuring With Front Panel Controls .................................................................... 12
Configuring with iLux Designer................................................................................ 24
Console Command Settings ...................................................................................... 26
Replacing the Function Button Label ........................................................................ 27
Uploading and Upgrading ........................................................................................................ 29
Establishing Communication ..................................................................................... 29
Programs and Firmware ............................................................................................ 30
Operation ................................................................................................................................. 31
Standard Mode .......................................................................................................... 31
Button Types ............................................................................................................. 32
IR Receiver ................................................................................................................ 34
Occupancy Sensing ................................................................................................... 34
Override Mode .......................................................................................................... 34
Load Shedding (Demand Response) ......................................................................... 35
Building Management System Interface ................................................................... 35
Lights Mode .............................................................................................................. 36
Shades Mode ............................................................................................................. 37
Problem Solving ...................................................................................................................... 39
Troubleshooting ......................................................................................................... 39
Check Network Wiring .............................................................................................. 39
Reference Documents ................................................................................................ 40
Further Inquiries ........................................................................................................ 40
Future Updates .......................................................................................................... 41
Appendix A: Supported Devices ............................................................................................. 42
Keypads ..................................................................................................................... 42
Shade Controllers ...................................................................................................... 44
Touch Screens ........................................................................................................... 44
Joins ........................................................................................................................... 45
Appendix B: Console Commands ............................................................................................ 52
Appendix C: RS 232 Commands- ............................................................................................ 56
Command Format ...................................................................................................... 56
Adding C2N- - IO Device to CLS C6 .......................................................................... 60
Echo Control Command ............................................................................................ 60
Light Zone Commands .............................................................................................. 60
Shade Group Commands ........................................................................................... 63
Scene Commands ...................................................................................................... 64
iLux Integrated Lighting System Crestron - -CLS/CLSI C6 & CLS/CLSI C6M
ii
•
•
•
•• Contents Operations Guide – DOC. 6347
Room Combining Commands ................................................................................... 67
Override Commands .................................................................................................. 67
Load Shed Commands ............................................................................................... 68
Occupancy Commands .............................................................................................. 68
Photocell Commands ................................................................................................. 69
Version Command ..................................................................................................... 69
Appendix D: Factory Default Values ...................................................................................... 70
Appendix E: Button Functions ................................................................................................ 72
Appendix F: Room Combining ................................................................................................ 81
Appendix G: RC5 Code Expansion ......................................................................................... 84
Return and Warranty Policies .................................................................................................. 86
Merchandise Returns / Repair Service ...................................................................... 86
Crestron Limited Warranty ........................................................................................ 86
Crestron CLS/CLSI CLS/CLSI-C6 & -C6M iLux Integrated Lighting System
Operations Guide iLux Integrated Lighting System: CLS– G DOC. 6347 /CLSI C6 & CLS/CLSI- -C6M •
•
•
•• 1
iLux Integrated Lighting System:
CLS CLS//CLSI- C6 & CLSI-C6M
Introduction
The CLS/CLSI- -C6 and CLS/CLSI C6M iLux® units are complete, integrated
wall- mounted lighting systems that can function as standalone devices or as part of a
Crestron® solution total control system network. The units are intended for
installation in boardrooms, auditoriums, home theaters, or anywhere versatile and
cost- -effective control of lighting and shades are required. The CLS C6 and
CLS-C6M are designed for 120 C6 and CLSIVac -installations; the CLSI -C6M are
designed for 230 Vac S-installations. All units are identical, except that the CL C6M
and CLSI- -C6M units include a built in motion sensor. For simplicity in this with
guide, the term - "CLS C6" is used except where noted.
Features and Functions
(Continued on following page)
• Wall- mounted integrated lighting and shade control
• Six channels of dimming or switching
• Six groups of shade or drapery control
• Linkable for up to 54 lighting channels and 54 shade groups
• Up to 16 user-settable scenes
• Seven configurable rocker buttons with customizable label strip
• Large ON and OFF buttons
• Flip-up front cover reveals setup controls and programming port
• Six bar graphs show lighting levels and shade positions
• Easy setup from front panel or iLux Designer software
• Built- - in motion sensor (CLS/CLSI C6M)
• Optional IR remote
• Supports multipoint control using up to 16 keypads
• Supports touch screen control using up to two touch screens
• Supports external occupancy sensors
• Supports room combining of up to 36 partitions
• Supports integration with building management systems (BMS)
• Master air-gap relay | 230 Vac version available
• Integrates with 2-Series control systems via Cresnet
®
iLux Integrated Lighting System Crestron - -CLS/CLSI C6 & CLS/CLSI C6M
6 •
•
•
•• iLux Integrated Lighting System: CLS- - C6/C6M & CLSI C6/C6M Operations Guide – G DOC. 6347
CLS-C6 Specifications (Continued)
SPECIFICATION DETAILS
Available Accessories
(Continued)
- - CLS EXP DIM iLux Dimmer Expansion Module
- - CLS EXP DIMFDB
iLux 3-Wire Fluorescent Dimmer Expansion
Module
- - CLS EXP DIMFLV
iLux 0 V Fluorescent Dimmer Expansion –10
Module
- - CLS EXP DIMU iLux Universal Dimmer Expansion Module
- CLS IRHT8 iLux IR Handheld Remote
- CNPWS 75 Cresnet Power Supply
- GLS LOL Crestron Green Light Photocell , Open-Loop
-SIM GLS Sensor Integration Module
- TPS 6L Isys
®
5.7 in Wall Mount Touch Screen
1. For a list of compatible ballasts, visit www.crestron.com/lightingcompatibility.
2. Larger loads and additional load types can also be supported using Crestron CLS-EXP Series expansion
modules (sold separately).
Physical Description
All controls and indicators for the CLS C6RF are located on the front of the unit. -
The front panel also contains a mini phone jack -under the flip up cover, used for
programming functions, and an IR port for control via an IR remote device. All other
ports and connectors are located on the rear panel. Refer to the “Connectors,
Controls, and Indicators table ” on page 8 for details.
CLS- C6 Physical View
iLux Integrated Lighting System Crestron - -CLS/CLSI C6 & CLS/CLSI C6M
10
•
•
•
•• iLux Integrated Lighting System: CLS Operations Guide - - C6/C6M & CLSI C6/C6M – G DOC. 6347
Connectors, Controls, and Indicators (Continued)
# CONNECTORS *,
CONTROLS, AND
INDICATORS
DESCRIPTION
16 1– 6 LOAD LOAD Use these terminals to connect the CLS-C6
dimmer channel outputs to the appropriate
lighting loads.
17 HOT, NEUTRAL,
(Ground)
Use these terminals to connect the unit to the
120 -V (CLS C6/M) or 230 V (CLSI-C6/M)
power source.
18 CONTROL SYSTEM
G Z Y 24
Use this 4-pin terminal block to connect the
CLS-C6, using standard Cresnet wiring, to a
2-Series control system network. In this
configuration, the CLS-C6 acts as a standard
Cresnet slave device. (The CLS C6 does not -
draw power from Cresnet.).
19 LOCAL DEVICES
G Z Y 24
Use this 4-pin terminal block to connect the
CLS-C6, using standard Cresnet wiring, to
local devices. In this configuration, the
CLS-C6 acts as the Cresnet Master.
* Interface connectors for CONTROL SYSTEM and LOCAL DEVICES ports are provided with the
unit.
iLux Integrated Lighting System Crestron - -CLS/CLSI C6 & CLS/CLSI C6M
12
•
•
•
•• iLux Integrated Lighting System: CLS Operations Guide - - C6/C6M & CLSI C6/C6M – G DOC. 6347
Configuring the CLS- C6
The overall configuration of the CLS-C6 can be accomplished in two ways: using the
front panel controls or using the supplied iLux Designer application software, which
can be downloaded from the Crestron Web site.
Configuring via the front panel controls is not as extensive as what can be done using
the iLux Designer but permits basic functional setup without having to use a PC.
In addition, some aspects of the CLS-C6’s operation can be modified only via certain
Crestron Toolbox console commands. Refer to “Console Command Settings” on
page 26 for details. Refer also to “Appendix B: Console Commands” on page 52 for
details on all applicable console commands.
NOTE: Toolbox does not distinguish between the CLS C6/C6M and CLSI- -C6/C6M
devices. All report as CLS units.
Configuring With Front Panel Controls
Temporary c hanges can be made to accommodate a particular circumstance or
change scene presets and replace the originals, as described below. To make more
extensive changes in the configuration of the CLS ing the iLux -C6 without us
Designer software refer to, "Setup Mode on page 13" .
Temporary Changes and Adjustments
Temporary changes adjustments to the lighting levels or shade presets can be and
accomplished as discussed in “Lights Mode” on page 36 and “Shades Mode” on
page 37.
Changing Scene Presets
The CLS-C6 scene settings can be modified via the front panel controls without
having to use a PC. Changes to the lighting load levels and shade presets for one or
more scenes can be accomplished as follows:
NOTE: The iLux Designer or SIMPL Windows programs can lock a scene to
prevent it from being changed using the front panel controls. If an adjustment is
made to a scene that is incorrect, “Er” is displayed for 3 seconds. The scene remains
in its existing state.
1. modified In Standard mode, press the function button of the scene to be and
hold it for 5 seconds. Make sure press the center of the butto ton so both
sides make contact.
2. The 2- s digit display first count down as the lighting loads fade to their
preset levels for that scene; it then begins “ .” flashing between Sc and the
scene number; the Lights LED illuminates and the Save and Cancel LEDs
flash.
3. Use the six function buttons to adjust the levels of the lighting loads for that
scene. Press the left side of the buttons to lower the lighting loads; press the
right side of the buttons to raise the lighting loads.
4. If there should be a certain lighting load to be unaffected by that scene
recall, press and hold the center of the button (so both sides make contact)
for 3 seconds. The top and bottom two LEDs of the associated bar graph
Scene Presets with Daylight
Harvesting
If a photocell is present, Scenes 1
through 8 (plus the On scene)
automatically utilize daylight
harvesting. When this automatic
behavior is enabled, the top bar
graph LED for that load blinks.
NOTE: When editing scenes with
photocell-controlled loads, photocell
output is temporarily disabled.
When the scene is recalled,
photocell control resumes and light
levels may change. To reduce the
possibility of unintended scene
behavior caused by photocell
reaction to sunlight, edit scenes at
night.
iLux Integrated Lighting System Crestron - -CLS/CLSI C6 & CLS/CLSI C6M
14
•
•
•
•• iLux Integrated Lighting System: CLS Operations Guide - - C6/C6M & CLSI C6/C6M – G DOC. 6347
Setup MnemonicsOption
2-DIGIT
DISPLAY
DESCRIPTION
Sc
Scene Programming
Ld
Setup lighting
L
oa
d
types
LE
Setup lighting load Low- End limits
HE
Setup lighting load High-End limits
Lo
Setup Lockout mode
bF b Futton unctions (i.e., recall scene, toggle
scene, shades control, etc.)
ud
Set function of up/down button
oc
Setup occupancy sensing
Ad
Run Auto- discovery
AS
A
ssign
S
hade groups
id
Set the Cresnet of this unitid
Ph
Photocell test
Pc
P Chotocell alibration
PL
Setup Photocell lower Limit
Pr
Setup Photocell response time
Fd
Restore efaultFactory d
Er
Error
• Press the or buttons to scroll through this list of available setup options.
Once the desired setup option appears in the display, use the various buttons
on the CLS-C6 to make adjustments, as described on the following pages.
• Once any adjustment is made, Setup mode is locked into that particular
option (this is indicated by lighting the period at the end of the mnemonic).
Once locked in an option, the buttons no longer scroll through the and
options; setup must be exited before choosing another option.
When the adjustments are complete, press to store the changes permanentlySave and
exit Setup mode or press Cancel to exit Setup Tmode without saving the changes. he
unit reverts to Standard mode.
Scene Programming (Sc)
This setup option allows the user to adjust the scene parameters. This is another way
to accomplish scene changes as discussed in “Changing Scene Presets” on page 12.
This method also allows settings to be changed for scenes greater than cene 6.S
Note that scenes can be turned off in addition to being recalled. When a scene is
turned off, only the lighting loads are turned off. If the scene contains any shades,
they are not affected. The fade time for turning the scene lights off is the same as for
recalling the scene. Therefore, no additional parameters need to be set to define the
off behavior.
Select the scene to be changed using the u dp/ own button. through the While cycling
list of scenes, the lights and shades do not change and the bar graphs are off.
Set the lighting loads and shade positions for the scenes as discussed in “Changing
Scene Presets” on page 12. As the scenes are set, note the following:
• When a lighting load reaches the HE (high-end) limit, the lights stop. The
2- s -digit display continue to rise. If lights reach the LE (low end) limit, the
2- s digit display continue to go down but lights stay at the LE limit until
they reach O — ff at which point they turn off. If the scene setting is saved
Scene Presets with Daylight
Harvesting
If a photocell is present, Scenes 1
through 8 (plus the On scene)
automatically utilize daylight
harvesting. When this automatic
behavior is enabled, the top bar
graph LED for that load blinks.
NOTE: When editing scenes with
photocell-controlled loads, photocell
output is temporarily disabled.
When the scene is recalled,
photocell control resumes and light
levels may change. To reduce the
possibility of unintended scene
behavior caused by photocell
reaction to sunlight, edit scenes at
night.
Produktspezifikationen
Marke: | Crestron |
Kategorie: | Regler |
Modell: | iLux CLSI-C6MB |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Crestron iLux CLSI-C6MB benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Regler Crestron
21 August 2024
21 August 2024
21 August 2024
21 August 2024
21 August 2024
20 August 2024
20 August 2024
20 August 2024
20 August 2024
20 August 2024
Bedienungsanleitung Regler
- Regler Samsung
- Regler Asus
- Regler Belkin
- Regler Gembird
- Regler Genius
- Regler Hama
- Regler HP
- Regler HyperX
- Regler Logitech
- Regler Microsoft
- Regler Nacon
- Regler Nedis
- Regler Niceboy
- Regler Saitek
- Regler Sony
- Regler SteelSeries
- Regler Sweex
- Regler T'nB
- Regler Targus
- Regler Trust
- Regler Bosch
- Regler Canon
- Regler Velleman
- Regler Hori
- Regler König
- Regler Thomson
- Regler Kenwood
- Regler Schneider
- Regler Pyle
- Regler Mitsubishi
- Regler Bose
- Regler Denon
- Regler Pioneer
- Regler JBL
- Regler One For All
- Regler Vivanco
- Regler BeamZ
- Regler Akai
- Regler Tascam
- Regler Zoom
- Regler Perel
- Regler Aruba
- Regler Lindy
- Regler Thrustmaster
- Regler TOA
- Regler MSI
- Regler Tripp Lite
- Regler Marshall
- Regler Razer
- Regler Honeywell
- Regler Marshall Electronics
- Regler SBS
- Regler DJI
- Regler Parrot
- Regler Reely
- Regler Zebra
- Regler Broan
- Regler Adj
- Regler Supermicro
- Regler Genesis
- Regler Thermaltake
- Regler Behringer
- Regler Mackie
- Regler Numark
- Regler Eurolite
- Regler Monoprice
- Regler Monacor
- Regler Huawei
- Regler JUNG
- Regler Hunter
- Regler Esperanza
- Regler Lumens
- Regler Korg
- Regler DataVideo
- Regler Manfrotto
- Regler Tracer
- Regler Cisco
- Regler Boss
- Regler Synology
- Regler Saramonic
- Regler Kramer
- Regler Irritrol
- Regler Jumbo
- Regler Vaddio
- Regler RCA
- Regler Datalogic
- Regler HQ Power
- Regler Nintendo
- Regler Kicker
- Regler Speed-Link
- Regler DBX
- Regler Draper
- Regler Hikvision
- Regler Radial Engineering
- Regler Rain Bird
- Regler Sven
- Regler PreSonus
- Regler ART
- Regler Senal
- Regler PDP
- Regler IK Multimedia
- Regler Krom
- Regler ASTRO Gaming
- Regler Gamesir
- Regler Fusion
- Regler GeoVision
- Regler Gossen Metrawatt
- Regler Icon
- Regler IHome
- Regler Media-tech
- Regler Naxa
- Regler PCE Instruments
- Regler Robitronic
- Regler Schaudt
- Regler SecurityMan
- Regler Steca
- Regler AMX
- Regler Universal Remote Control
- Regler Vizio
- Regler Siig
- Regler Intel
- Regler Zephyr
- Regler RGBlink
- Regler StarTech.com
- Regler Konix
- Regler Monster
- Regler Niles
- Regler Gefen
- Regler Polsen
- Regler Inovonics
- Regler Atlantis Land
- Regler Atlas Sound
- Regler Magnus
- Regler LSI
- Regler ATen
- Regler Morningstar
- Regler KanexPro
- Regler Lab Gruppen
- Regler SPL
- Regler SmartAVI
- Regler Natec
- Regler EtiamPro
- Regler Chauvet
- Regler Premier Mounts
- Regler Juniper
- Regler Phoenix Contact
- Regler Music Hall
- Regler Audac
- Regler OSD Audio
- Regler BZBGear
- Regler DreamGEAR
- Regler GOgroove
- Regler PowerA
- Regler Atlona
- Regler LYYT
- Regler Elite Screens
- Regler Bigben Interactive
- Regler Rolls
- Regler Sonifex
- Regler Leviton
- Regler Apricorn
- Regler 8BitDo
- Regler Alfatron
- Regler Highpoint
- Regler Steelplay
- Regler AViPAS
- Regler Auray
- Regler Vakoss
- Regler Areca
- Regler Savio
- Regler Heritage Audio
- Regler Tru Components
- Regler Ltech
- Regler CTA Digital
- Regler Canyon
- Regler MuxLab
- Regler Kanlux
- Regler EXSYS
- Regler Venom
- Regler Amer
- Regler ALC
- Regler LumenRadio
- Regler Moza
- Regler Axor
- Regler Valcom
- Regler AirTurn
- Regler Dangerous Music
- Regler Clarity
- Regler Softube
- Regler RiotPWR
- Regler IPEGA
- Regler Dadson
- Regler Blizzard Lighting
- Regler Heath Zenith
- Regler Re.corder
- Regler Mitzu
- Regler CoolerMaster
- Regler Dragonshock
- Regler MOGA
- Regler HuddleCamHD
- Regler PTZ Optics
- Regler Balam Rush
Neueste Bedienungsanleitung für -Kategorien-
16 Oktober 2024
16 Oktober 2024
5 Oktober 2024
4 Oktober 2024
3 Oktober 2024
1 Oktober 2024
Hori Force Feedback Truck Control System Bedienungsanleitung
1 Oktober 2024
30 September 2024
27 September 2024
