DO GUIDE
2. Remove the buttons as desired.
HR-100/HR-150
Handheld Remote, 34/50 Button
DO Change the Buttons and the Cover
The HR-100 and HR-150 ship with all of the buttons installed (four on the HR-100 and eight on
the HR-150). Both remotes can be used with none of the buttons installed or two of the buttons
installed. The HR-150 can also be used with four or six buttons installed. Both remotes ship with
alternate button covers.
To change the buttons and the cover, use the following procedure:
1. Gently separate the button cover from the remote.
DO Check the Box
QTY PRODUCT PART NUM.
2 Batteries, AAA Alkaline, x2 2041725
1 Keycaps, 100 4521158
Items for HR-100 Only
1 Cover, Button, Removable, 2-Button 4520730
1 Cover, Button, Removable, No Button 4520731
Items for HR-150 Only
1 Cover, Button, Removable, 6-Button 4520696
1 Cover, Button, Removable, 4-Button 4520697
1 Cover, Button, Removable, 2-Button 4520761
1 Cover, Button, Removable, No Button 4520695
Separate the button cover here.
DO GUIDE DOC. 7656B (2040909) 05.16
Specicat ions subject t o change without notice.
3. Gently snap the appropriate new button cover into place. DO Acquire the Remote
Before an HR-100 or HR-150 can be used with a Crestron® control system, it must rst be
acquired by an inNET EX® Wireless Gateway or a control system with a built-in inNET EX
gateway (all sold separately).
1. Press the button on the gateway to enter Acquire mode.ACQUIRE
2. On the HR-100 or HR-150, press the button four times, holding it down Backlight
on the fourth press (press, press, press, press+hold). After a few seconds, the backlight
ashes, indicating the remote is now in Acquire mode. The remote is automatically
acquired by the gateway within two minutes. When the remote has joined the network, the
backlight turns on for ve seconds.
3. When the process is complete, press the ACQUIRE button on the gateway to exit Acquire
mode.
DO Learn More
Visit the website for additional information and the latest rmware updates. To learn
more about this product, use a QR reader application on your mobile device to scan
the QR images.
Crestron Electronics
15 Volvo Drive, Rockleigh, NJ 07647
888.CRESTRON | www.crestron.com
As of the date of manufacture, the product has been tested and found to comply with specications for CE marking.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Cautio n: Changes or modications not expressly approved by the manufacturer responsible for compliance could void the user’s
authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Industry Canada (IC) Compliance Statement
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and
its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication.
Industrie Canada (IC) Déclaration de conformité
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Conformément à la réglementation d’Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d’un type et
d’un gain maximal (ou inférieur) approuvé pour l’émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l’intention des autres utilisateurs, il faut choisir le type d’antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l’intensité nécessaire à l’établissement d’une communication satisfaisante.
Crest ron product development sof t ware is licensed to Crest ron dealers and Crest ron Service Providers (CSPs) under a limited non-exclusive, non-t ransferable Soft ware Development Tools
Licens e Agreement. Crestron product operating system soft ware is licensed to Crest ron dealers, CSPs, and end-users under a separate End-User License Agreement . Both of these Agreements
can be found on the Crest ron website at w ww.crest ron.com/legal/sof t ware_license_ agreement.
The specic patents t hat cover Crestron products are listed at . The product warrant y can be found at .http://www.crestron.com/legal/patents www.crestron.com/warranty
Cert ain Crestron products cont ain open source soft ware. For specic information, please visit . www.crestron.com/opensource
Crest ron, the Crestron logo, inNET EX, and t he inNET EX logo are either t rademarks or registered trademarks of Crestron Electronics, Inc. in th e United States and/or other count ries. Ot her
trademarks, registered t rademarks, and trade names may be used in this document to ref er to either the entities claiming the marks and names or their products. Crestron disclaims any
proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or phot ography.
This document was writ ten by the Technical Publicat ions depart ment at Crest ron.
©2016 Crestron Electronics, Inc.
