Seite 1/8
CSM-series
Compact Mixers with USB Player
Item ref: 170.871 UK
170.872 UK
170.873 UK
User Manual
Version 1.1
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
CSM-series User Manual
Introduction
Thank you for choosing a Citronic CSM-series mixer as part of your professional sound system. This
product has been developed to provide a wide range of facilities for professional and reliable sound
reinforcement. Please read and keep th nual to achieve the best results from your purchase and avoid is ma
damage through misuse.
SAFETY SYMBOL AND MESSAGE CONVENTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC
ELECTRIQUE NE PAS
OUVRIR
This symbol indicates that d erous voltage constituting a risk of ang
electric shock is present within this unit
This symbol indicates that there are important operating and
maintenance instructions in the literature accompanying this unit.
Warning
To prevent the risk of fir or electric shock, do not expose any components to rain or moisture. If liquids e
enter the housing, stop using immediately, allow the unit to dry out and have checked by qualified it
personnel before further use. Avoid impact, extreme pressure or heavy vibration to the case.
No user serviceable parts inside Do not open the case refer all servicing to qualified service personnel. – –
Safety
• Use the 5Vdc power adaptor supplied or equivalent.
• Avoid ingress of water or particles into any part of the hou ng. If liquids are spilled on si
the console, stop using immediately, allow the unit to dry out and have checked by
qualified personnel before further use
Placement
• Keep the console out of direct sunlight and away from heat sources.
• Do not place hea jects on top of the control surface vy ob
• Allow adequate space for airflow and keep the console away from damp or dust .
Cleaning
• Use a soft cloth with a neutral detergent to clean the housing as required.
• A soft brush can be used to clear debris from be controls without damaging them tween
• Do not use solvents for cleaning the unit.
CSM-series User Manual
Console layout
Each CSM compact mixing console has a bank of
mono input channels which can accept a balanced
microphone input or switchable line/instrument
input. There is also a stereo input for playback
devices or line level instruments.
All preamps have studio grade, low noise
architecture for the cleanest possible path
throughout the signal chain. Console layout is set
out in distinct sections to simplify operation.
The following pages of this manual are divided up
into these stages to explain the details and function
of each control.
Channel inputs
Channel inputs are provided as XLR or 6.3mm jack on combo sockets.
If an XLR is plugged in, this will be con cte as low impedance (microphone) level. If a 6.3mm plug is ne d
used, this will be connected as either line or instrument level (switchable)
The connections for these inputs are assigned as follows.
Mic / Line / Instrument input
1. Combo input Connect a balanced microphone via XLR connection or a line level
or instrument input via 6.3mm plug. An unbalanced XLR can be
connected provided that +48V phantom power is not used.
Wired as follows.
Balanced
Pin 1 = Ground
Pin 2 = Signal +
Pin 3 = Signal –
Unbalanced
Pin 1 = Ground
Pin 2 = Signal +
Pin 3 = Ground
2. IMPED switch Press this button in to set the input impedance to instrument level or leave the button
in the up position for a line level input. (instrument level is usually for pickups, ch su
as those on a guitar. Electronic keyboards usually produce a line level output)
3. +48V phantom Press this button in to enable +48V phantom power to the XLR and the LED indicator
will light. This provides power to some condenser microphones and DI boxes.
Do not use with unbalanced XLR connectors. This does not affect any jack inputs.
