MULTILINGUAL
USER MANUAL
EN DE ESFR PTNL IT
Printed in China
Ver: PIR-926-UM-ML-V1.0
PIR-926
Solar-Powered Dual-Tech
Motion Detector
© Chuango. All Rights Reserved.
EN EN
Introduction
PIR-926 is a solar-powered motion detector utilizing a single
passive infrared element and microwave technology. It consists of
digital dual-core fuzzy logic infrared control chip and intelligent
analysis which could effectively identify interference signals from
body movement signals so as to reduce false alarms. The detector
is battery powered and kept re-charging by the solar panel to
save energy. Unique housing material and structure improve its
waterproof level for outdoor use. Only after being connected
successfully with alarm system, the detector can work normally.
Features
1. Accurate detection
■It has microwave and infrared dual detections to prevent false
alarms.
■It consists of digital dual-core fuzzy logic infrared control chip and
intelligent analysis which could effectively identify interference
signals from body movement signals.
■With automatic temperature compensation and anti-air turbulence
technology, it easily adapts to environmental changes.
2. Outdoor use
It adopts ABS and anti-UV materials for outdoor use with IP65
rating.
3. Energy saving
■Rechargeable by solar power.
■Energy saving mode to reduce battery charging times, and
extending battery life.
Product Overview
Solar Panel
LED Indicator
Detection Lens
Detector Installation Bracket
Base
Fixing Screw
LED Indication
LED Status Meaning
Red and orange LEDs ash
continuously for 1 min Self-testing
Red LED ashes once Infrared is triggered
Orange LED ashes once Microwave is triggered
Red and orange LEDs ash once
at the same time
Both infrared and microwave
are triggered, the detector
sends alarm signal.
Red LED ash 3 times every
12 seconds
Low battery. Please install on
place with sufcient sunlight
EN EN
PCB Layout
① LED On/Off
② Working Mode
Setting
â‘€ Tamper Switch
⑱ Battery
â‘„ Zone Mode Setting
④ Microwave Sensitive Adjustment
3.7 V 18650
1. LED options: ON/OFF (default setting is ON).
2. Working mode options: 10S=Test mode, 5MIN=Power saving mode
(default setting is test mode).
3. Battery: One piece of 18650 rechargeable lithium battery.
4. Microwave sensitivity adjustment options: HIGH, MEDIUM, LOW.
(default setting is medium).
5. Tamper switch: In working state, if the housing is opened, detector
will send alarm signal.
6. Zone mode options: Normal zone (Arm Zone), home zone, 24-H
zone (default setting is normal zone).
You can change the zone mode of this detector as follows:
Open the rear cover of the detector, change the array of jumpers to
the corresponding position as below:
Normal zone (Arm Zone): In arm or home arm state, the detector
set at normal zone will trigger an alarm once intrusion is detected.
Home zone: In home arm state, the detector set at home zone is
disarmed.
24-H zone: The detector set at 24-H zone will trigger an alarm once
intrusion is detected, no matter the system is armed or disarmed.
Detection Scope
Top view
Side view
2m 4m 6m 8
m
0m
0m
2m
11 0 °
Working Mode Selection
After the battery is loaded, the detector enters into 1 min self-
testing with the red and orange LEDs ashing continuously, and
then it starts to work according to the pre-set working mode.
5 MIN
10 S
5 MIN
10 S
Testing Mode Power Saving Mode
(Arm Zone)
