I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalaciĂłn
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
XBM1U
XBM1UP
Extra Large Bolt Down Video Wall
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
XBM1U/XBM1UP
XBM1U/XBM1UP Installation Instructions
2
DISCLAIMER
Milestone AV Technologies and its affiliated corporations and
subsidiaries (collectively “Milestone”), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all components are
properly assembled and installed using the instructions
provided.
WARNING: Failure to provide adequate structural strength
for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component.
WARNING: Do NOT stack multiple accessories on the
same display wall!
WARNING: Do NOT install XBM1U/XBM1UP mounts to
any surface other than concrete! Concrete flooring must be at
least 4" in thickness and NOT be covered with any other type
of flooring material. Concrete anchors must be installed
directly into concrete surface.
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
each display and attached accessories mounted to the
XBM1U/XBM1UP mount does not exceed 250 lbs (113.4 kg).
NOTE: The UL Listed XBM1U/XMB1UP video walls may be
used with the Listed video wall extension accessory
FCABX36 with the FCABX36 being used in place of the
existing height extension.
WARNING: Use this mounting system only for its intended
use as described in these instructions. Do not use
attachments not recommended by the manufacturer.
WARNING: Never operate this mounting system if it is
damaged. Return the mounting system to a service center for
examination and repair.
NOTE: Refer to UL Listed accessories manuals for installation
instructions.
NOTE: The XBM1U/XBM1UP video walls have no user
serviceable parts.
WARNING: Do not use this product outdoors.
--SAVE THESE INSTRUCTIONS-
Installation Instructions XBM1U/XBM1UP
3
DIMENSIONS
21.23
539. 2
17.00
431. 8
33.00
838.2
250 LBS
XBM1U
31.50
800.0
MAX MOUNTING
PATTERN HEIGHT
36.00
914.4
21.23
539.2
250 LBS
XBM1UP
