Seite 1/15
I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Dynamic Height Adjustable Video Cart
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
MPD1U/LPD1U
MPD1U/LPD1U Installation Instructions
2
DISCLAIMER
Milestone AV Technologies and its affiliated corporations and
subsidiaries (collectively “Milestone”), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.
DEFINITIONS
MOUNTING SYSTEM: A MOUNTING SYSTEM is the
primary Chief product to which an accessory and/or component
is attached.
ACCESSORY: AN ACCESSORY is the secondary Chief
product which is attached to a primary Chief product, and may
have a component attached or setting on it.
COMPONENT: A COMPONENT is an audiovisual item
designed to be attached or resting on an accessory or mounting
system such as a video camera, CPU, screen, display,
projector, etc.
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all mounting systems/
accessories are properly assembled and installed using the
instructions provided.
WARNING: Failure to provide adequate structural strength
for this mounting system can result in serious personal injury
or damage to equipment! It is the installer’s responsibility to
make sure the structure to which this mounting system is
attached can support five times the combined weight of all
equipment. Reinforce the structure as required before
installing the mounting system.
WARNING: Use this mounting system only for its intended
use as described in these instructions. Do not use
attachments not recommended by the manufacturer.
WARNING: Never operate this mounting system if it is
damaged. Return the mounting system to a service center for
examination and repair.
WARNING: Do not use this product outdoors.
WARNING: RISK OF INJURY TO PERSONS! Do not
place video equipment such as televisions or computer
monitors on cart legs.
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all accessories and components attached to the MPD1U/
LPD1U head assembly up to (and including) the display falls
within the specific weight range listed in the table below. Use
with heavier televisions may result in instability causing tip
over resulting in death or serious injury! The height
adjustable feature of this cart will not function properly if the
weight is not within the ranges listed below.
MODEL Minimum Weight
Allowed
Max Weight
Allowed
MPD1U 67 lbs
(30.4 kg)
130 lbs
(58.9 kg)
LPD1U 122 lbs
(55.4 kg)
180 lbs
(82 kg)
Installation Instructions MPD1U/LPD1U
3
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all accessories and components installed to the component
bracket (G) does not exceed 10 lbs (4.54 kg). The combined
weight of all accessories and components installed to the
lower bracket (CPU’s, etc.) cannot exceed 20 lbs (9.07 kg).
Exceeding the weight capacity may result in damage to the
equipment or components! See Figure below for reference.
WARNING: RISK OF SERIOUS INJURY OR DEATH!
Placing a remote control or toy on the cart may encourage a
child to climb onto the cart causing the cart to tip over onto
the child. DO NOT place remote controls or toys on the cart!
WARNING: RISK OF SERIOUS INJURY OR DEATH!
Relocating audio and/or video equipment to the cart may
result in the cart collapsing or overturning onto a child. DO
NOT relocate audio and/or video equipment to the cart!
NOTE: The MPD1U/LPD1U cart has no user serviceable parts.
NOTE: The MPD1U/LPD1U cart can support screen sizes up
to a maximum of 100" wide.
NOTE: The MPD1U/LPD1U cart is intended for Institutional
Use.
--SAVE THESE INSTRUCTIONS--
MPD1U - 67 - 130 lbs (30.4 - 58.9 kg)
10 lbs (4.54 kg)
20 lbs (9.07 kg)
LPD1U - 122 - 180 lbs (55.4 - 82 kg)
