Seite 1/3
S E M B L A N C E
M O D U L A R S Y S T E M
TWO PERSON ASSEMBLYB D I U S A . C O M
OFFICE DRAWER MODULES
15030 &15031
COMPONENT
ASSEMBLY
INSTRUCTIONS
2
BEFORE STEP 3
(PAGE 18):
Pull the Top Drawer as far out as it will go.
Locate the finger latch in the rail of the
slide on each side of the Drawer. Lift the
Left Latch up and press the Right Latch
down simultaneously and slide the Top
Drawer the rest of the way out. (Be careful
of grease residue on drawer slides)
Refer to the Cabinet Assembly section (page 17) in the Main
Instruction Booklet for proper installation of the Two-Drawer Files
while implementing and replacing the following steps.
3
AFTER STEP 5
(PAGE 19):
Pull the slide rails in the Cabinet Body out
slightly. Carefully bring the Top Drawer up
to the exposed slide rails, fitting the rails
of the Top Drawer into the Cabinet Body
slides. Once engaged, continue to push
the Drawer to its closed position. (It will
seem difficult to push closed, but once
you close the Drawer, it will revert back to
an easily gliding drawer).
Users who wish to use legal-length files
may install provided Legal File Folder
Stretchers by dropping into place near
front and back of file drawers.
REPLACES STEP 4 (PAGE 19)
IN MAIN ASSEMBLY
INSTRUCTIONS:
Slide the File Drawer all the way open
to access the through holes that attach
the Cabinet Body to the Panel with the
Screws (K).
