IMPORTANT INSTRUCTIONS -
OPERATING MANUAL
SAVE THESE INSTRUCTIONS
www.airkinglimited.com
A210952014 Rev. Q 1-23 1 of 8
Exhaust Fan with Light
Models: LEDAK100D, LED100DH
READ AND SAVE THESE INSTRUCTIONS
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN
THE PRODUCT DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY
INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL
INJURY AND/OR PROPERTY DAMAGE!
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
GENERAL SAFETY INFORMATION
When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electric shock and
injury to person, including the following:
WARNING: TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK AND INJURY TO PERSON,
OBSERVE THE FOLLOWING:
a) Use this unit only in the manner intended by the manufacturer. If you have
questions, contact the manufacturer.
b) Before servicing or cleaning the unit, switch power off at service
panel and lock the service disconnecting means to prevent power
from being switched on accidentally. When the service disconnecting
means cannot be locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
WARNING: TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK AND INJURY TO PERSON,
OBSERVE THE FOLLOWING:
a) Installation work and electrical wiring must be done by qualified
person(s) in accordance with all applicable codes and standards,
including fire-related construction.
b) Sufficient air is needed for proper combustion and exhausting of
gases through the flue (chimney) of fuel burning equipment to prevent
back drafting. Follow the heating equipment manufacturer’s guideline
and safety standards such as those published by the National Fire
Protection Association (NFPA) and the American Society for Heating,
Refrigeration, and Air Conditioning Engineers (ASHRAE), and the local
code authorities.
c) When cutting or drilling into wall or ceiling, do not damage electrical
wiring and other hidden utilities.
CAUTION: FOR GENERAL VENTILATING USE ONLY.
DO NOT USE TO EXHAUST HAZARDOUS OR EXPLOSIVE
MATERIALS AND VAPORS.
d) Ducted fans must always be vented to the outdoors.
e) This unit must be grounded.
f) To avoid motor bearing damage and noisy and/or unbalanced impellers,
keep drywall spray, construction dust, etc. off power unit.
WARNING: IF FAN IS INTENDED FOR CONTINUOUS
OPERATION DO NOT POWER FAN UNTIL ALL CONSTRUCTION HAS
BEEN COMPLETED. THE FAN WILL DRAW IN AIRBORNE DUST THAT COULD
IMPAIR OPERATION AND REDUCE THE LIFE OF THE MOTOR. USAGE OF
FAN DURING CONSTRUCTION PROCESS WILL VOID ALL WARRANTIES.
g) Read all instructions before installing or using exhaust fan.
h) If this unit is to be installed over a tub or shower, it must be marked
as appropriate for the application and be connected to a GFCI (Ground
Fault Circuit Interrupter) – protected branch circuit.
i) Do not install in a ceiling with thermal insulation value greater than R40.
WARNING: TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, DO NOT USE THIS FAN WITH
ANY SOLID-STATE SPEED CONTROL DEVICE.
WARNING: DO NOT USE IN KITCHENS.
WARNING: THE DUCTING FROM THIS FAN TO THE
OUTSIDE OF THE BUILDING HAS A STRONG EFFECT ON THE
AIR FLOW, NOISE AND ENERGY USE OF THE FAN. USE THE SHORTEST,
STRAIGHTEST DUCT ROUTING POSSIBLE FOR BEST PERFORMANCE,
AND AVOID INSTALLING THE FAN WITH SMALLER DUCTS THAN
RECOMMENDED. INSULATION AROUND THE DUCTS CAN REDUCE
ENERGY LOSS AND INHIBIT MOLD GROWTH. FANS INSTALLED WITH
EXISTING DUCTS MAY NOT ACHIEVE THEIR RATED AIRFLOW.
INSTALLATION INSTRUCTIONS
CAUTION:
MAKE SURE POWER IS SWITCHED OFF AT SERVICE
PANEL BEFORE STARTING INSTALLATION.
SECTION 1
Preparing the Exhaust Fan
1. Unpack fan from the carton and confirm that all pieces are present. In addition to the exhaust
fan you should have:
1 - Grill 4 - Mounting Rails
1 - Light Assembly 1 - Lamp
1 - Damper Assembly (attached) 1 - Instruction/Safety Sheet
2. Choose the location for your fan. To ensure the best air and sound performance, it is
recommended that the length of ducting and the number of elbows be kept to a minimum, the
radius of each elbow be as large as possible for the installation, and that insulated hard ducting
be used. This fan will require at least 8" of clearance in the
ceiling or wall, and will mount through drywall up to 3/4"
thick. The fan mounts between 16" or 24" on center joists
using the 4 provided mounting rails.
3. Using a straight-blade screw driver remove the electrical
knockout from the housing (Figure 1).
4. No additional vibration deadening materials are needed
for this fan.
SECTION 2
New Construction
1. Install the rails into the
mounting channel on
the housing. Center the
mounting channel in the
slots on the housing, then
from inside the housing
tighten the mounting
channel screws so the
channel is securely in place.
Position the housing next to
the joist. Line up housing so
that it will be flush with the
finished ceiling. Secure the
ends of the rails with screws or nails (not
included) to the joists and slide the housing
into the final position (Figure 2).
SECTION 3
Existing Construction
1. Set housing in position between the joist
and trace an outline onto the ceiling
material Set housing aside and (Figure 3).
cut opening, being careful not to cut or
damage any electrical or other hidden utilities. Install the rails into the mounting channel on the
housing. Center the mounting channel in the slots on the housing, then from inside the housing
tighten the mounting channel screws so the channel is securely in place. Position the housing
in the previously cut hole so that it is flush with the finished ceiling. Secure the ends of the rails
to the joists (Figure 2).
SECTION 4
Ducting
NOTE: 4" OR LARGER RIGID DUCT IS RECOMMENDED FOR BEST PERFORMANCE.
CAUTION: ALL DUCTING MUST COMPLY WITH LOCAL AND NATIONAL
BUILDING CODES.
NOTE: The ducting from this fan to the outside of the building has a strong effect on the air
flow, noise and energy use of the fan. Use the shortest, straightest duct routing possible for best
performance, and avoid installing the fan with smaller ducts than recommended. Insulation around
the ducts can reduce energy loss and inhibit mold growth. Fans installed with existing ducts may not
achieve their rated air flow.
1. Connect the ducting to the
fan’s duct collar (Figure 4).
Secure in place using tape
or screw clamp. Always
duct the fan to the outside
through a wall or roof cap.
It is recommended that
low restriction termination
fittings be used.
2. Ensure duct joints and exterior penetrations are sealed with caulk or other similar material
to create an air-tight path to minimize building heat loss or gain and to reduce the potential
for condensation. Place/wrap insulation around duct and/or fan in order to minimize possible
condensation buildup within the duct, as well as building heat loss or gain .(Figure 5)
www.airkinglimited.com
A210952014 Rev. Q 1-23 2 of 8
SECTION 5
Wiring
CAUTION: MAKE SURE POWER IS SWITCHED OFF AT SERVICE
PANEL BEFORE STARTING INSTALLATION.
CAUTION: ALL ELECTRICAL CONNECTIONS MUST BE MADE
IN ACCORDANCE WITH LOCAL CODES, ORDINANCES, OR NATIONAL
ELECTRICAL CODE. IF YOU ARE UNFAMILIAR WITH METHODS OF INSTALLING ELECTRICAL
WIRING, SECURE THE SERVICES OF A QUALIFIED ELECTRICIAN.
NOTE: This unit includes a side access
panel for wiring that does not require
the removal of the fan’s blower
assembly. If you choose to wire the
unit from the inside, you will need
to remove the blower assembly and
internal wiring compartment. Both
methods are equally effective.
1a. External Wire Compartment:
Remove the wire compartment
cover screw and place cover in a
secure place .(Figure 6)
1b. Internal Wire Compartment:
Remove the screws holding the
blower assembly in place and
lift assembly out of housing
(Figure 7). Remove the wire
compartment cover screw and
place the cover in a secure place
(Figure 8).
NOTE: If the fan motor plug is
connected to the fan housing
receptacle, unplug so the blower
assembly can be completely removed.
2. Continuous Ventilation: For two speed
fans wired for continuous ventilation,
connect the White wires of the fan to
the White (Neutral) wire from the power
source. Connect the ground wire from
the house to the green wire from the
fan housing. Connect the Black wire
of the fan to the Black wire (Hot) from
the power source. Using a properly
grounded standard toggle switch
(not included), connect the Black
wire from the supply to one side of
the switch. Connect the Red wire
(light) from the fan housing to the
other side of the switch. Using a
second properly grounded standard
duplex toggle switch, connect the
Hot Yellow wire from the fan to the
input of the switch Connect the
second Yellow wire from the fan
to the output side of the switch.
Closing the switch will change from
normal to high speed (Figure 9).
Figure 8
Screw
Wire
Compartment
Cover
NOTE: Wire compartment
configuration will be
dependent on model.
Figure 5
Insulation*
(place around and
over Fan Housing
Fan Housing
Power Cable*
Seal gaps
around Housing
Round
Duct*
Seal duct joints
with tape
Round
Elbows*
Wall Cap*
Roof Cap*
(with built-in
damper)
Keep duct
runs short
*Purchase separately
or
Figure 2
Housing
Joist
Mounting Rails
Figure 3
Joist
Figure 1
Ducting
Duct
Collar
Figure 4
Figure 6
Screw
Wire
Compartment
Cover
Screw
Plug
Venturi
Figure 7
Figure 9 Supply from house
Black
Yellow
Ground
(Green or Bare)
Fan
Black
Green
Yellow
Black
Red
Neutral (White)
Neutral (White)
By others
Switch
(by others)
Switch
(by others)
3. Intermittent Ventilation: For two speed fans wired for intermittent ventilation with a standard
duplex toggle switch (not included), connect the White wires of the fan to the White (Neutral)
wire from the power source. Connect the ground wire from the fan to the ground wire from
the power source. Properly ground the switches. Connect the black wire from the supply to
one side of the top switch. Connect the black wire from the fan to the other side of the top
switch, Connect 1 yellow wire from the fan to each side of the bottom switch. The top switch
turns the fan On & Off, the bottom
switch changes speed between high
and low. Using a second properly
grounded standard toggle switch,
connect the Black wire from the
supply to one side of the switch.
Connect the Red wire (light) from the
fan housing to the other side of the
switch (Figure 10).
NOTE: The fan’s receptacle wires might
need to be pulled outside compartment
for connection. Only pull the three loose
wires outside of compartment. Additional
wires will be present.
4. Carefully tuck wires back inside wire compartment and replace wire compartment cover
securing with the screw that was removed earlier.
SECTION 6
Completing the Installation
1. Use a sealant appropriate for contact with the building materials present and for the
temperature requirements of the installation to prevent air leakage from unconditioned spaces
is recommended. If gaps between unit housing and ceiling are great, additional material
(backing rod, ceiling material) may be required.
NOTE: This fan is rated for direct insulation contact (Type IC) and it is recommended that this fan be
completely covered by insulation in order to reduce heat loss or gain to unconditioned space.
2. If the fan’s blower assembly was removed during the wiring process, reinstall the blower by
reversing the directions in in .Step 1b Section 5 Wiring
3. Plug the fan’s 5 pin quick
connect motor cord into the
receptacle on the side of the
wiring compartment cover and
the light’s 2 pin quick connect
into the receptacle on the top
of the wiring compartment
cover. These cords will only fit
one way into the receptacles
(Figure 11).
4. Install the included lamp into
the lamp holder by inserting
the base of the lamp into
the holder and turning the
lamp body clockwise until
the lamp is firmly seated
in the lamp holder - do not
overtighten (Figure 12).
5. Install the reflector onto the
grill by placing the slots
on the side of the reflector
over the lens clips near the
center of the grill. While
squeezing the middle of
the reflector, slide it so that
the plastic notches rest
under the lens clips and
the reflector feels secure
(Figure 13).
www.airkinglimited.com
A210952014 Rev. Q 1-23 3 of 8
6. Install the grill (with reflector) by
squeezing the two ends of the springs
together and installing them up into the
slots on the fan’s housing. Push the grill
up into position (Figure 14).
7. Restore power and test your installation.
SECTION 7
Setting the Humidistat
This fan may be equipped with a humidity sensor that automatically turns the fan on when humidity
is above set point and off when humidity is at or below set point. If the fan is operating too long or not
enough, first check to see the humidity sensor set point. In cases where the ambient humidity level of
the room rises higher than the preset level, the fan will turn on even if the room is not occupied. This
helps prevent conditions that lead to mold growth.
CAUTION: MAKE SURE POWER IS SWITCHED OFF AT SERVICE
PANEL BEFORE SERVICING THE UNIT.
1. To set the desired humidity level of the room, remove the grill and locate the dehumidistat dial
located on the wire compartment cover.
2. Set the dial to the relative humidity you want the fan to maintain usually between 50 & 80%.
Moist climates will require higher settings than dry climates. When the humidity level of the
room is below this setting the fan will remain off. When the humidity level rises about this
setting the fan will turn on and run until the humidity level falls below this setting.
3. Reinstall the grill and restore power.
SECTION 8
Use and Care
CAUTION: MAKE SURE POWER IS SWITCHED OFF AT SERVICE
PANEL BEFORE STARTING INSTALLATION.
1. Cleaning the Grill: Remove grill and dislodge reflector from grill by sliding the reflector
notches from beneath the lens clips on grill. Use a mild detergent, such as dishwashing liquid,
to clean then dry with a soft cloth. NEVER USE ANY ABRASIVE PADS OR SCOURING POWDERS.
Completely dry grill before reinstalling. Clean reflector using a dry cloth. Refer to instructions
in , to reinstall reflector and grill.Section 6 Completing the Installation
2. Cleaning the Fan Assembly: Wipe all parts with a dry cloth or gently vacuum the fan. NEVER
IMMERSE ELECTRICAL PARTS IN WATER.
CAUTION: ALLOW BULBS TO COOL BEFORE REPLACING.
3. Changing the Lamp: Disconnect power to the unit. Remove grill by pulling downward on grill
and squeezing grill springs together to release from housing . Remove Reflector (Figure 13)
from grill by sliding the reflector notches from beneath the lens clips on grill. (Figure 12).
Unscrew and remove old bulb and replace with Air King PN 5S1299727 or other ENERGY STAR
certified LED Max 18 Watt, A19, E26 (Medium) base lamp.
Figure 11
NOTE: Wire compartment
configuration will be
dependent on model.
Figure 12
Lamp Lamp Holder
Socket
NOTE: LED lamp shown
Slot
Clip
Figure 13
Figure 14
Figure 10 Supply from house
Yellow
Ground
(Green or Bare)
Fan
Green
Yellow
Red
Neutral (White)
Neutral (White)
By others
BlackBlack
Switch
(by others)
Black Switch
(by others)

Produktspezifikationen

Marke: Air King
Kategorie: Dunstabzugshaube
Modell: LEDAK80

Brauchst du Hilfe?

Wenn Sie Hilfe mit Air King LEDAK80 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Dunstabzugshaube Air King

Air King

Air King FRAK80H Bedienungsanleitung

6 September 2024
Air King

Air King LIN46md-900 Bedienungsanleitung

6 September 2024
Air King

Air King FRAS70 Bedienungsanleitung

6 September 2024
Air King

Air King AK100LS6 Bedienungsanleitung

6 September 2024
Air King

Air King BFQ50 Bedienungsanleitung

6 September 2024
Air King

Air King BFC90H Bedienungsanleitung

6 September 2024
Air King

Air King BFQL70 Bedienungsanleitung

6 September 2024
Air King

Air King LIN34md-900 Bedienungsanleitung

6 September 2024
Air King

Air King LIN34m-900 Bedienungsanleitung

6 September 2024
Air King

Air King LIN34m-600 Bedienungsanleitung

6 September 2024

Bedienungsanleitung Dunstabzugshaube

Neueste Bedienungsanleitung für -Kategorien-

Pelgrim

Pelgrim ISW990 Bedienungsanleitung

16 Oktober 2024
Amana

Amana UVL6048JSS Bedienungsanleitung

16 Oktober 2024
Maytag

Maytag UVL6048JSS Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS46GTW Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS46GW Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS46GB Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS46B Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS45X Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS45W Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS45B Bedienungsanleitung

16 Oktober 2024
