IMPORTANT INSTRUCTIONS -
OPERATING MANUAL
SAVE THESE INSTRUCTIONS
www.airkinglimited.com
6727919 Rev. H 4-20 1 of 12
Exhaust Fan
Models: BFQL50, BFQL70, BFQL120
READ AND SAVE THESE INSTRUCTIONS
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN
THE PRODUCT DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY
INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL
INJURY AND/OR PROPERTY DAMAGE!
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
GENERAL SAFETY INFORMATION
When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electric shock and
injury to person, including the following:
WARNING: TO REDUCE THE RISK
OF FIRE, ELECTRIC SHOCK AND INJURY TO
PERSON, OBSERVE THE FOLLOWING:
a) Use this unit only in the manner intended by the manufacturer.If you have
questions, contact the manufacturer.
b) Before servicing or cleaning the unit, switch power off at service
panel and lock the service disconnecting means to prevent power
from being switched on accidentally. When the service disconnecting
means cannot be locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
WARNING: TO REDUCE THE RISK
OF FIRE, ELECTRIC SHOCK AND INJURY TO
PERSON, OBSERVE THE FOLLOWING:
a) Installation work and electrical wiring must be done by qualified
person(s) in accordance with all applicable codes and standards,
including fire-related construction.
b) Sufficient air is needed for proper combustion and exhausting of
gases through the flue (chimney) of fuel burning equipment to prevent
back drafting. Follow the heating equipment manufacturer’s guideline
and safety standards such as those published by the National Fire
Protection Association (NFPA) and the American Society for Heating,
Refrigeration, and Air Conditioning Engineers (ASHRAE), and the local
code authorities.
c) When cutting or drilling into wall or ceiling, do not damage electrical
wiring and other hidden utilities.
CAUTION: FOR GENERAL VENTILATING USE ONLY.
DO NOT USE TO EXHAUST HAZARDOUS OR EXPLOSIVE
MATERIALS AND VAPORS.
d) Ducted fans must always be vented to the outdoors.
e) If this unit is to be installed over a tub or shower, it must be marked
as appropriate for the application and be connected to a GFCI (Ground
Fault Circuit Interrupter) – protected branch circuit.
f) This unit must be grounded.
g) To avoid motor bearing damage and noisy and/or unbalanced impellers,
keep drywall spray, construction dust, etc. off power unit.
h) Read all instructions before installing or using exhaust fan.
i) Suitable for use with electronic speed control device.
WARNING: DO NOT USE IN KITCHENS.
WARNING: THE DUCTING FROM THIS FAN TO THE
OUTSIDE OF THE BUILDING HAS A STRONG EFFECT
ON THE AIR FLOW, NOISE AND ENERGY USE OF THE FAN. USE
THE SHORTEST, STRAIGHTEST DUCT ROUTING POSSIBLE FOR
BEST PERFORMANCE, AND AVOID INSTALLING THE FAN WITH
SMALLER DUCTS THAN RECOMMENDED. INSULATION AROUND
THE DUCTS CAN REDUCE ENERGY LOSS AND INHIBIT MOLD
GROWTH. FANS INSTALLED WITH EXISTING DUCTS MAY NOT
ACHIEVE THEIR RATED AIRFLOW.
INSTALLATION INSTRUCTIONS
CAUTION: MAKE SURE POWER IS SWITCHED OFF
AT SERVICE PANEL BEFORE STARTING INSTALLATION.
SECTION 1
Preparing the Exhaust Fan
1. Unpack fan from the carton and confirm that all pieces are present. In
addition to the exhaust fan you should have:
1 - Grill with Light Lens
1 - Damper Assembly (attached)
1 - Mounting Bracket
1 - LampLED
1 - Hardware Bag
1 - Electrical Connector
4 - Wire Nuts
1 - Instruction/Safety Sheet
2. Remove the wire compartment cover and store in the carton until
needed so it does not get damaged or lost (Figure 1).
3. Choose the location for your fan. To ensure the best air and sound
performance, it is recommended that the length of ducting and the
number of elbows be kept to a minimum, the radius of each elbow be
as large as possible for the installation, and that insulated hard ducting
be used. Larger duct sizes will reduce noise
and airflow restrictions.
4. Select the most convenient electrical
knockout and remove using a straight-
blade screw driver (Figure 2).
5. No additional vibration deadening materials
are needed for this fan.
SECTION 2
New Construction
1. Using the gauge on the mounting bracket, line up the bracket on the
joist so the bottom of the fan will be flush with the finished ceiling.
Nail or screw the bracket in place securely (Figure 3).
2. Snap the fan body into the bracket The fan can be (Figure 4).
snapped into position with the duct collar facing to the left or the right
depending which is most convenient.
www.airkinglimited.com
6727919 Rev. H 4-20 2 of 12
SECTION 3
Existing Construction
1. Position housing against the joist or stud and trace an outline of the
housing onto the ceiling/wall material. Set housing aside and cut
opening, being careful not to cut or damage any electrical or other
hidden utilities (Figure 5).
2. Line up the bracket on the joist so the bottom of the fan will be flush
with the finished ceiling. Nail or screw the snap-in bracket in place
securely (Figure 3).
3. Snap the fan body into the bracket The fan can be (Figure 4).
snapped into position with the duct collar facing to the left or the right
depending which is most convenient.
SECTION 4
Ducting
NOTE: 4" OR LARGER RIGID DUCT IS RECOMMENDED FOR BEST
PERFORMANCE.
CAUTION: ALL DUCTING MUST COMPLY WITH LOCAL
AND NATIONAL BUILDING CODES.
1. Connect the ducting to the fan’s duct collar Secure in place (Figure 6).
using tape or screw clamp. Always duct the fan to the outside through
a wall or roof cap. It is recommended that low restriction termination
fittings be used.
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
Figure 1
2. Ensure duct joints and exterior penetrations are sealed with caulk or
other similar material to create an air-tight path to minimize building
heat loss or gain and to reduce the potential for condensation. Place/
wrap insulation around duct and/or fan to in order to minimize
possible condensation buildup within the duct, as well as building heat
loss or gain (Figure 7).
SECTION 5
Wiring
CAUTION: MAKE SURE POWER IS SWITCHED OFF
AT SERVICE PANEL BEFORE STARTING INSTALLATION.
CAUTION: ALL ELECTRICAL CONNECTIONS
MUST BE MADE IN ACCORDANCE WITH LOCAL
CODES, ORDINANCES, OR NATIONAL ELECTRICAL CODE. IF YOU ARE
UNFAMILIAR WITH METHODS OF INSTALLING ELECTRICAL WIRING,
SECURE THE SERVICES OF A QUALIFIED ELECTRICIAN.
1. Wiring Fan/Light Independently: Run wiring from an approved wall
switch carrying the appropriate rating. One neutral (white), one ground
(green or bare copper), and two hot (black lead connected to the switch).
Secure the electrical wires to the housing with an approved electrical
connector. Make sure you leave enough wiring in the box to make the
connection to the fan’s receptacle.
1a. From where you have access to inside the fan’s junction box, connect
the one white wire from the house to both the white wire from the
fan’s light receptacle and the white wire from the fan’s exhaust
receptacle. Connect the first black wire from the wall switch to the
black wire from the fan’s light receptacle. Connect the second black
wire from the switch to the fan’s exhaust receptacle. Connect
the ground wire from the house to the green wire from the fan’s
receptacle (Figure 8). Use approved methods for all connections.
www.airkinglimited.com
6727919 Rev. H 4-20 3 of 12
2. Wiring Fan/Light together: Run wiring from an approved wall switch
carrying the appropriate rating. One neutral (white), one ground (green
or bare copper), and one hot (black lead connected to the switch).
Secure the electrical wires to the housing with an approved electrical
connector. Make sure you leave enough wiring in the box to make the
connection to the fan’s receptacle.
2a. From where you have access to inside the fan’s junction box, connect
the one white wire from the house to both the white wire from the
fan’s light receptacle and the white wire from the fan’s exhaust
receptacle. Connect the black wire from the wall switch to both the
black wire from the fan’s light receptacle and the black wire from the
fan’s exhaust receptacle. Connect the ground wire from the house to
the green wire from the fan’s receptacle Use approved (Figure 9).
methods for all connections.
SECTION 6
Completing the Installation
1. Use a sealant appropriate for contact with the building materials
present and for the temperature requirements of the installation to
prevent air leakage from unconditioned spaces is recommended. If
gaps between unit housing and ceiling are great, additional material
(backing rod, ceiling material) may be required.
NOTE: This fan is rated for direct insulation contact (Type IC) and it is
recommended that this fan be completely covered by insulation in order to
reduce heat loss or gain to unconditioned space.
2. Reinstall the fan’s wire compartment cover. Rotate the blower wheel
by hand to ensure it spins freely. Plug the fan’s quick connect motor
cord into the receptacle. This cord will only fit one way into the
receptacle (Figure 10).
NOTE: If using this fan to meet ASHRAE 62.2 requirements, locate the label
inside the fan housing and fill in the appropriate information.
3. Install the grill/lens/light reflector, by first removing the lens from the
grill (there are two tabs on either side that hold the lens in place).
Then remove the acorn nut and the lock washer which are installed
on the reflector mounting bolt in the fan housing. Adjust the height
of the reflector mounting bolt so that the grill will be tight up against
the finished ceiling and less than 1/4” of the reflector mounting bolt
protrudes through the reflector. Secure the reflector bolt’s position by
tightening the factory installed nut against the motor clip (Figure 11).
Figure 10
Figure 7
Insulation*
(place around and
over Fan Housing
Fan Housing
Power Cable*
Seal gaps
around Housing
Round
Duct*
Seal duct joints
with tape
Round
Elbows*
Wall Cap*
Roof Cap*
(with built-in
damper)
Keep duct
runs short
*Purchase separately
or
Figure 8
Supply from house
Black
Neutral (White)
Ground (Green or Bare)
Fan
Neutral (White)
Green
Black
By others
Red Black
Neutral (White)
Figure 9
Supply from house
Black
Neutral (White)
Ground (Green or Bare)
Fan
Neutral (White)
Green
Black
By others
Red
Neutral (White)

Produktspezifikationen

Marke: Air King
Kategorie: Dunstabzugshaube
Modell: BFQL50

Brauchst du Hilfe?

Wenn Sie Hilfe mit Air King BFQL50 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Dunstabzugshaube Air King

Air King

Air King FRAK80H Bedienungsanleitung

6 September 2024
Air King

Air King LIN46md-900 Bedienungsanleitung

6 September 2024
Air King

Air King FRAS70 Bedienungsanleitung

6 September 2024
Air King

Air King AK100LS6 Bedienungsanleitung

6 September 2024
Air King

Air King BFQ50 Bedienungsanleitung

6 September 2024
Air King

Air King BFC90H Bedienungsanleitung

6 September 2024
Air King

Air King BFQL70 Bedienungsanleitung

6 September 2024
Air King

Air King LIN34md-900 Bedienungsanleitung

6 September 2024
Air King

Air King LIN34m-900 Bedienungsanleitung

6 September 2024
Air King

Air King LIN34m-600 Bedienungsanleitung

6 September 2024

Bedienungsanleitung Dunstabzugshaube

Neueste Bedienungsanleitung für -Kategorien-

Pelgrim

Pelgrim ISW990 Bedienungsanleitung

16 Oktober 2024
Amana

Amana UVL6048JSS Bedienungsanleitung

16 Oktober 2024
Maytag

Maytag UVL6048JSS Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS46GTW Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS46GW Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS46GB Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS46B Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS45X Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS45W Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia CHS45B Bedienungsanleitung

16 Oktober 2024
