Seite 1/8

IMPORTANT INSTRUCTIONS -

OPERATING MANUAL

SAVE THESE INSTRUCTIONS

www.airkinglimited.com

210572021 Rev. U 11-18 1 of 8

Exhaust Fan

BFQ, BFQW Series

READ AND SAVE THESE INSTRUCTIONS

READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN

THE PRODUCT DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY

INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL

INJURY AND/OR PROPERTY DAMAGE!

RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.

GENERAL SAFETY INFORMATION

When using electrical appliances, basic precautions should

always be followed to reduce the risk of ﬁre, electric shock and

injury to person, including the following:

WARNING: TO REDUCE THE RISK

OF FIRE, ELECTRIC SHOCK AND INJURY TO

PERSON, OBSERVE THE FOLLOWING:

a) Use this unit only in the manner intended by the manufacturer.If you have

questions, contact the manufacturer.

b) Before servicing or cleaning the unit, switch power off at service

panel and lock the service disconnecting means to prevent power

from being switched on accidentally. When the service disconnecting

means cannot be locked, securely fasten a prominent warning

device, such as a tag, to the service panel.

WARNING: TO REDUCE THE RISK

OF FIRE, ELECTRIC SHOCK AND INJURY TO

PERSON, OBSERVE THE FOLLOWING:

a) Installation work and electrical wiring must be done by qualiﬁed

person(s) in accordance with all applicable codes and standards,

including ﬁre-related construction.

b) Sufﬁcient air is needed for proper combustion and exhausting of

gases through the ﬂue (chimney) of fuel burning equipment to prevent

back drafting. Follow the heating equipment manufacturer’s guideline

and safety standards such as those published by the National Fire

Protection Association (NFPA) and the American Society for Heating,

Refrigeration, and Air Conditioning Engineers (ASHRAE), and the local

code authorities.

c) When cutting or drilling into wall or ceiling, do not damage electrical

wiring and other hidden utilities.

CAUTION: FOR GENERAL VENTILATING USE ONLY.

DO NOT USE TO EXHAUST HAZARDOUS OR EXPLOSIVE

MATERIALS AND VAPORS.

d) Ducted fans must always be vented to the outdoors.

e) This unit must be grounded.

f) To avoid motor bearing damage and noisy and/or unbalanced impellers,

keep drywall spray, construction dust, etc. off power unit.

g) Read all instructions before installing or using exhaust fan.

WARNING: TO REDUCE THE RISK OF FIRE,

ELECTRIC SHOCK, DO NOT USE THIS FAN WITH

ANY SOLID-STATE SPEED CONTROL DEVICE.

a) If this unit is to be installed over a tub or shower, it must be

marked as appropriate for the application and be connected to a

GFCI (Ground Fault Circuit Interrupter) – protected branch circuit.

b) Do not install wall mounted fans inside the shower area.

WARNING: DO NOT USE IN KITCHENS.

WARNING: THE DUCTING FROM THIS FAN TO THE

OUTSIDE OF THE BUILDING HAS A STRONG EFFECT

ON THE AIR FLOW, NOISE AND ENERGY USE OF THE FAN. USE

THE SHORTEST, STRAIGHTEST DUCT ROUTING POSSIBLE FOR

BEST PERFORMANCE, AND AVOID INSTALLING THE FAN WITH

SMALLER DUCTS THAN RECOMMENDED. INSULATION AROUND

THE DUCTS CAN REDUCE ENERGY LOSS AND INHIBIT MOLD

GROWTH. FANS INSTALLED WITH EXISTING DUCTS MAY NOT

ACHIEVE THEIR RATED AIRFLOW.

INSTALLATION INSTRUCTIONS

CAUTION: MAKE SURE POWER IS SWITCHED OFF AT

SERVICE PANEL BEFORE STARTING INSTALLATION.

SECTION 1

Preparing the Exhaust Fan

1. Unpack fan from the carton and conﬁrm that all pieces are present. In addition to the

exhaust fan you should have:

1 - Grill 1 - Hardware Bag

1 - Damper Assembly (attached) 1 - Electrical Connector

1 - Mounting Bracket 3 - Wire Nuts

1 - Instruction/Safety Sheet

2. Remove the wire compartment cover and store in the carton until needed so it does not

get damaged or lost (Figure 1).

3. Choose the location for your fan. To ensure the best

air and sound performance, it is recommended that

the length of ducting and the number of elbows be

kept to a minimum, the radius of each elbow be as

large as possible for the installation, and that insulated

hard ducting be used. Larger duct sizes will reduce

noise and airﬂow restrictions.

4. Select the most convenient electrical

knockout and remove using a straight-

blade screw driver (Figure 2).

5. No additional vibration deadening materials are

needed for this fan.

SECTION 2

New Construction - BFQ Models

1. Using the gauge on the mounting bracket, line up the bracket on the joist so the bottom

of the fan will be ﬂush with the ﬁnished ceiling. Nail or screw the bracket in place

securely (Figure 3).

WARNING: PROPER INSTALLATION REQUIRES A MINIMUM OF 4

SCREWS LOCATED IN HOLES CLOSEST TO DRYWALL.

2. Snap the fan body into the

bracket The fan can (Figure 4).

be snapped into position with the

duct collar facing to the left or the

right depending which is most

convenient.

www.airkinglimited.com

210572021 Rev. U 11-18 2 of 8

New Construction - BFQW Models (Oval Duct)

1. Using the gauge on the bracket, line up the bracket on the side of a wall stud such that

the bottom of the fan will be ﬂush with the ﬁnished wall. The bracket should sit one

drywall thickness forward on the stud (Figure 5).

NOTE: For proper damper operation, the duct

adaptor must be facing up towards the ceiling.

NOTE: ½” minimum thickness drywall must be used for

wall mount applications.

2. Nail or screw the bracket in place securely.

3. Snap the fan body into the bracket, making

sure the duct collar is pointing upwards

towards the ceiling (Figure 6).

SECTION 3

Existing Construction - BFQ Models

1. Position housing against the joist

or stud and trace an outline of

the housing onto the ceiling/wall

material. Set housing aside and cut

opening, being careful not to cut

or damage any electrical or other

hidden utilities (Figure 7).

2. Line up the bracket on the joist so

the bottom of the fan will be ﬂush

with the ﬁnished ceiling. Nail or

screw the snap-in bracket in place

securely (Figure 3).

3. Snap the fan body into the bracket The fan can be snapped into position (Figure 4).

with the duct collar facing to the left or the right depending which is most convenient.

Existing Construction - BFQW Models (Oval Duct)

1. Remove a section of the wall material large enough for you to ﬁt the fan housing into as

well as gain access to the top plate, and have enough space to connect the ducting. This

will typically be across two studs and approximately 24" starting at the top of the wall.

2. Follow the instructions in - to Section 2 New Constructions - BFQW Models (Oval Duct)

complete the installation.

NOTE: Wall installation into existing construction will require you to patch the wall material

around the unit.

SECTION 4

Ducting

NOTE: 4" OR LARGER RIGID DUCT IS RECOMMENDED FOR BEST PERFORMANCE.

CAUTION: ALL DUCTING MUST COMPLY WITH LOCAL AND NATIONAL

BUILDING CODES.

1. Connect the ducting to the fan’s duct

collar Secure in place (Figure 8).

using tape or screw clamp. Always

duct the fan to the outside through a

wall or roof cap. It is recommended

that low restriction termination

ﬁttings be used.

NOTE: For oval duct connection, squeeze

standard 4" round rigid ducting to form

an oval shape then follow instructions in

Step 1.

Figure 2

Figure 4

Figure 1

Figure 6

Figure 3

Figure 5

Drywall Wall Stud

Figure 7

Round duct

collar shown

Figure 8

2. Ensure duct joints and exterior penetrations are sealed with caulk or other similar

material to create an air-tight path to minimize building heat loss or gain and to reduce

the potential for condensation. Place/wrap insulation around duct and/or fan to in order

to minimize possible condensation buildup within the duct, as well as building heat loss

or gain (Figure 9).

SECTION 5

Wiring

CAUTION: MAKE SURE POWER IS SWITCHED OFF AT

SERVICE PANEL BEFORE STARTING INSTALLATION.

CAUTION: ALL ELECTRICAL CONNECTIONS MUST BE

MADE IN ACCORDANCE WITH LOCAL CODES, ORDINANCES, OR

NATIONAL ELECTRICAL CODE. IF YOU ARE UNFAMILIAR WITH METHODS OF INSTALLING

ELECTRICAL WIRING, SECURE THE SERVICES OF A QUALIFIED ELECTRICIAN.

1. Run wiring from an approved wall switch carrying the appropriate rating. One neutral

(white), one ground (green or bare copper), and one hot (black lead connected to

the switch). Secure the electrical wires to the housing with an approved electrical

connector. Make sure you leave enough wiring in the box to make the connection to the

fan’s receptacle.

2. From where you have access to inside the fan’s junction box, connect the White wire

from the house to the White wire from the fan’s receptacle. Connect the Black wire from

the wall switch to the Black wire from the fan’s receptacle. Connect the ground wire

from the house to the Green wire from the fan’s receptacle . Use approved (Figure 10)

methods for all connections.

www.airkinglimited.com

210572021 Rev. U 11-18 3 of 8

SECTION 6

Completing the Installation

1. Use a sealant appropriate for contact with the building materials present and for the

temperature requirements of the installation to prevent air leakage from unconditioned

spaces is recommended. If gaps between unit housing and ceiling are great, additional

material (backing rod, ceiling material) may be required.

NOTE: This fan is rated for direct insulation contact (Type IC) and it is recommended that this fan

be completely covered by insulation in order to reduce heat loss or gain to unconditioned space.

2. Reinstall the fan’s wire compartment cover. Rotate the blower wheel by hand to

ensure it spins freely. Plug the fan’s quick connect motor cord into the receptacle.

This cord will only ﬁt one way into the receptacle (Figure 11).

NOTE: If using this fan to meet ASHRAE 62.2 requirements, locate the label inside the fan

housing and ﬁll in the appropriate information.

3. Install the grill by squeezing the two ends of the springs together and installing them up

into the slots of the fan’s housing. Push the grill up into position (Figure 12).

4. Restore power and test your installation.

SECTION 7

Use and Care

CAUTION: MAKE SURE POWER IS SWITCHED OFF AT

SERVICE PANEL BEFORE SERVICING THE UNIT.

1. Cleaning the Grill: Remove grill and use a mild detergent, such as dishwashing liquid,

and dry with a soft cloth. NEVER USE ANY ABRASIVE PADS OR SCOURING POWDERS.

Completely dry grill before reinstalling. Refer to instructions in Section 6 Finishing the

Installation, to reinstall grill.

2. Cleaning the Fan Assembly: Unplug the motor cord from receptacle. Wipe all parts

with a dry cloth or gently vacuum the fan. NEVER IMMERSE ELECTRICAL PARTS IN

WATER. Plug the motor cord back in and restore power.

Figure 9

Insulation*

(place around and

over Fan Housing

Fan Housing

Power Cable*

Seal gaps

around Housing

Round

Duct*

Seal duct joints

with tape

Round

Elbows*

Wall Cap*

Roof Cap*

(with built-in

damper)

Keep duct

runs short

*Purchase separately

Figure 10

Supply from house

Black

Neutral (White)

Ground (Green or Bare)

Fan

Neutral (White)

Green

Black

By others

Figure 11

Figure 12

Troubleshooting Guide

Trouble Probable Cause Suggested Remedy

1. Fan does not operate when the switch is on. 1a. A fuse may be blown or a circuit tripped. 1a. Replace fuse or reset circuit breaker.

1b. Connector plug from motor is not plugged in. 1b. Turn off power to unit. Remove Grill and plug motor into receptacle

in housing. Restore power to unit.

1c. Wiring is not connected properly. 1c. Turn off power to unit. Check that all wires are connected.

1d Motor has stopped operating. 1d. Replace motor.

2. Fan is operating, but air moves slower than normal. 2. Obstruction in the exhaust ducting. 2. Check for any obstructions in the ducting. The most common are bird

nests in the roof cap or wall cap where the fan exhausts to the outside.
