Datasheet MG-105/MG-108
The Zyxel 2.5 Gigabit Switch MG-105/MG-108 are the perfect candidates to
upgrade your network speed and performance, bringing you up to 2.5 times
faster experience than today’s Gigabit network. Unlike traditional gigabit
switches, our MG-105/MG-108 supports 2.5G for all its Ethernet ports which
can boost the entire network performance up to 2.5Gbps at once without
compromising to limited high-speed port availability. Out-of-the-box network
speed upgrade turns MG-105/MG-108 into an optimal solution for home or
small office users who needs more bandwidth for their network with demands
coming from online gaming activities, multimedia streaming services or
faster wireless network connectivity without the complex configuration.
Support 2.5GbE on all ports
Instantly upgrade speed up to
2.5 times
Increase home networking
speed without extra cabling
cost
Access Internet just plug-and-
play
Silent and stable operation
MG-105/MG-108
5 / 8-Port 2.5GbE Unmanaged Switch
2Datasheet MG-105/MG-108
Fanless design for true silent operation
MG-105 and MG-108 are built with fanless and sturdy
hardware design to ensure all-time silent and stable
operation. They are perfect for any home or business
environment.
Plug-and-play 2.5G connectivity for home
networking
Easily connect MG-105 or MG-108 to the latest
2.5Gcapable network devices and instantly enjoy
high performance networking and smoother home
entertainment experience with its simplified plug-and-play
technology.
Use your existing cables
Increasing new applications raise the demand for higher
network speed requirement. The Multi-Gigabit RJ-45 ports
not only provide more speed options for your network, but
it can increase your home networking speed from current
1Gbps to 2.5Gbps without additional cabling fee!
Benefits
Upgrade Network to Multi-Gig
This family is equipped with Switches for both five
(MG-105) and eight (MG-108) 2.5 Gigabit ports with
optimized performance for auto-negotiation with up
to Multi-Gigabit bandwidth (100M/1G/2.5G) and the
Switches provide up to 25/40 Gbps of switching capacity.
It is the ideal choice for LAN party, high performance
entertainment experience and efficient SOHO network.
5
x
2.5 Gigabit
Ports
8 x
2.5 Gigabit
Ports
For more product information, visit us on the web at www.zyxel.com
Copyright © 2021 Zyxel and/or its affiliates. All rights reserved.
All specifications are subject to change without notice.
Datasheet MG-105/MG-108
28/05/21
Application Diagram
System Specifications
Standard
• IEEE 802.3u 100BASE-TX Fast
Ethernet
• IEEE802.3ab 1000BASE-T
• IEEE 802.3bz 2.5GBASE-T
• IEEE 802.3x full duplex operation and
flow control
• IEEE 802.1p QoS
• IEEE 802.3 Nway auto-negotiation
Performance
• Switching capacity:
MG-105: 25 Gbps
MG-108: 40 Gbps
• Switching forwarding rate:
MG-105: 18.6 Mpps
MG-108: 29.8 Mpps
• MAC address table: 16 K
• Packet buffer: 12Mb
• Jumbo frame supports up to 12 KB
Features
• 100M, 1G and 2.5G ports for multi
speed
Fanless and quiet
Plug and Play, Easy use and Quick
Install
Desktop and Wall mount
Auto-MDI/MDIX in all ports
Hardware Specifications
Interface
• MG-105:
Five RJ-45 100/1000/2500 Mbps
Ethernet ports with auto MDI/MDIX
support
• MG-108:
Eight RJ-45 100/1000/2500 Mbps
Ethernet ports with auto MDI/MDIX
support
LED Indicator
• PWR: Power
• Per port: Link/Activity
Amber: 100/1000 Mbps
Green: 2.5 Gbps
Power Supply
AC-to-DC external power adapter
Input: 100 - 240V AC, 50/60 Hz
Output: 12V DC/1.5A
Power Consumption
MG-105: 9.34 watt max.
MG-108: 12.24 watt max.
Physical Specifications
• Item dimensions (WxDxH):
MG-105:
160 x 110 x 26 mm
(6.3” x 4.33” x 1.02”)
MG-108:
240 x 106 x 26 mm
(9.45” x 4.13” x 1.02”)
• Item weight:
MG-105: 460 g (1.01 lb.)
MG-108: 640 g (1.41 lb.)
• Packing dimensions (WxDxH):
MG-105:
215 x 133 x 79 mm
(8.46” x 5.24” x 3.11”)
MG-108:
256 x 132 x 78 mm
(10.08” x 5.2” x 3.07”)
• Packing weight:
MG-105: 919.6 g (2.03 lb.)
MG-108: 1,122 g (2.47 lb.)
Environmental Specifications
Operating Environment
Temperature:
0°C to 40°C (32°F to 104°F)
Humidity:
10% to 90% (Non-condensing)
Storage Environment
Temperature:
-40°C to 7C (-40°F to 158°F)
Humidity:
5% to 95% (non-condensing)
Certification
• CE, EAC, FCC, BSMI Class B
Package Contents
Switch
Power adapter
Quick Start Guide
Safety warning and DoC
Specifications
