User's Manual
www.ZALMAN.com
※ To ensure safe and easy installation, Please read the following precautions.
Ver.180112
High Efciency Switching
Power Supply
ARX - Series
PLATINUM
1
Power Supply
AC Power Cord
Four Screws Five Cable Ties
User's Manual Cable Bag
1. Warnings and Safety Precautions
2. Components
▶ Opening the cover of the product while the power cord is plugged into an outlet
may cause electrocution or critical damage to the product.
▶ Handling the power cord with wet hands may cause electrocution.
▶ Inserting ngers or metallic objects into the cooling fan may cause injury or
electrocution.
▶ Operating the product in an extremely cold or hot environment can degrade
product performance and lifespan.
▶ Exposure to liquids may cause malfunction.
▶ Operation in a humid or non-ventilated environment may reduce product lifespan.
▶ Plugging the main power connector P1 into the motherboard while the product is
connected to the AC power source may cause damage to the motherboard.
▶ Make sure that the connectors are connected to their designated locations, and
that the connectors are not oriented in the wrong direction when connecting the
DC output connectors.
▶ Please use gloves to prevent injuries during installation.
▶ Product designs and specications may be revised without prior notication to
improve quality and performance.
Neglecting the following may cause serious injury or death.
Neglecting the following may cause minor injuries, degrade product
conditions or cause malfunction.
Caution
Warning
Disclaimer) Zalman Tech Co., Ltd. is not responsible for any damages due to external
causes, including but not limited to, improper use, problems with electrical
power, accident, neglect, alteration, repair, improper installation, or
improper testing.
English
2
3. Specications
1) ZM750-ARX Electrical & Physical Specications
AC Input Range Voltage 100~240VAC
±10%
Vout
Output Load Rating Combined
Power
Frequency 50Hz ~ 60㎐
±3 Imin Imax Ipeak
AC Input Current
100VAC
10-5A +3.3V 0.1A 25A
120W
750W
240VAC +5V 22A0.2A
PFC Type Active PFC 0.2A 62A 744W+12V
Power Factor Correction Max 99% -12V 0.0A 0.3A 3.6W
Inrush Current Limit
(@ Cold Start at 25℃)
100VAC
Max 50A +5VSB 0.0A 2.5A 12.5W
240VAC Ambient Temperature
Eciency Max 94% @ 230VAC, Typical load Operation 0 ~ +40℃
DC Output Voltage
Regulation
Vout Regulation Range
At
Full
Load
Storage -20 ~ +70℃
+3.3VDC +3.14 ~ +3.47V Ambient Humidity±5%
+5VDC ±5% +4.75 ~ +5.25V Operation 5% ~ 95% RH
+12VDC ±5% +11.4 ~ +12.6V Storage 5% ~ 95% RH
-12VDC -10.8 ~ -13.0V Dimensions 180(D) x 150(W) x 86(H)mm±10%
+5VSB +4.75 ~ +5.25V Weight 2.9kg±5%
DC Output Ripple
& Noise
Vout Standard Range
At
Full
Load
Protection Functions
+3.3VDC Over-Current Protection (OCP)50mV
+5VDC 50mV Over-Voltage Protection (OVP)
+12VDC 120mV Under-Voltage Protection (UVP)
-12VDC Short-Circuit Protection (SCP)120mV
+5VSB Over-Power Protection (OPP)50mV
Over-Temperature Protection (OTP)
2) ZM850-ARX Electrical & Physical Specications
AC Input Range Voltage 100~240VAC
±10%
Vout
Output Load Rating Combined
Power
Frequency 50Hz ~ 60㎐
±3 Imin I
max I
peak
AC Input Current
100VAC
11-5.5A +3.3V 0.1A 25A
120W
850W
240VAC +5V 22A0.2A
PFC Type Active PFC 0.2A 840W+12V 70A
Power Factor Correction Max 99% -12V 0.0A 0.3A 3.6W
Inrush Current Limit
(@ Cold Start at 25℃)
100VAC
Max 50A
+5VSB 0.0A 2.5A 12.5W
240VAC Ambient Temperature
Eciency Max 94% @ 230VAC, Typical load Operation 0 ~ +40℃
DC Output Voltage
Regulation
Vout Regulation Range
At
Full
Load
Storage -20 ~ +70℃
+3.3VDC +3.14 ~ +3.47V Ambient Humidity±5%
+5VDC ±5% +4.75 ~ +5.25V Operation 5% ~ 95% RH
+12VDC ±5% +11.4 ~ +12.6V Storage 5% ~ 95% RH
-12VDC -10.8 ~ -13.0V Dimensions 180(D) x 150(W) x 86(H)mm±10%
+5VSB +4.75 ~ +5.25V Weight 2.95kg±5%
DC Output Ripple
& Noise
Vout Standard Range
At
Full
Load
Protection Functions
+3.3VDC Over-Current Protection (OCP)50mV
+5VDC 50mV Over-Voltage Protection (OVP)
+12VDC 120mV Under-Voltage Protection (UVP)
-12VDC Short-Circuit Protection (SCP)120mV
+5VSB Over-Power Protection (OPP)50mV
Over-Temperature Protection (OTP)
English
