Seite 1/41
NS-B40
NS-C40
NS-SWP40
SPEAKER PACKAGE
PACKAGE ENCEINTES
EnglishFrançaisDeutsch
NL
ES
IT
SV
DE
FR
EN
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
BRUKSANVISNING
MANUAL DE INSTRUCCIONES
GEBRUIKSAANWIJZING
MANUALE DI ISTRUZIONI
OWNER’S MANUAL
G
SvenskaItalianoEspañolNederlands
i En
English
Please read the following operating precautions before use. Yamaha will not be held responsible for any damage and/or injury
caused by not following the cautions below.
1. To assure the finest performance, please read this
manual carefully. Keep it in a safe place for future
reference.
2. Install the speakers in a cool, dry, clean place – away
from windows, sources of heat, sources of excessive
vibration, dust, moisture or cold. Avoid sources of
electrical humming (e.g., transformers and motors). To
prevent fire or electric shock, do not expose the
speakers to rain or water.
3. To prevent the enclosure from warping or discoloring,
do not expose the speakers to direct sunlight or
excessive humidity.
4. Avoid installing the speakers where foreign objects may
fall onto them and/or where they may be exposed to
liquid dripping or splashing.
5.
Do not place the following objects on top of the speakers:
– Other components, as they might damage or discolor
the surface of the speakers.
– Burning objects (e.g., candles), as they might cause
fire, damage to the speakers or personal injury.
– Containers of liquid, as they might spill and cause
electric shock to the user or damage to the speakers.
6. Do not place the speakers where they are liable to be
knocked over or struck by falling objects. Stable
placement will also ensure better sound performance.
7. Placing the speakers on the same shelf or rack as the
turntable can result in feedback.
8. Any time you note distortion, reduce the volume control
on your amplifier to lower setting. Never allow your
amplifier to be driven into “clipping”. Otherwise, the
speakers may be damaged.
9. When using an amplifier with a rated output power
higher than the nominal input power of the speakers,
care should be taken not to exceed the maximum input
of the speakers.
10. Do not attempt to clean the speakers with chemical
solvents as this might damage the finish. Use a clean,
dry cloth.
11. Do not attempt to modify or fix the speakers. Contact
qualified Yamaha service personnel when service is
needed. The cabinet should never be opened for any
reason.
12. Be sure to read the “Troubleshooting” section regarding
common operating errors before concluding that the
speakers are faulty.
13. Secure placement or installation is the owner’s
responsibility. Yamaha is not liable for accidents
caused by improper placement or installation of
speakers.
For NS-SWP40
1. Never put a hand or a foreign object into the port
located on the right side of this unit. When moving this
unit, do not hold the port, as it might cause personal
injury and/or damage to this unit.
2.
When using a humidifier, be sure to avoid condensation
inside this unit by allowing enough space around the
unit and avoiding excess humidification. Condensation
might cause fire, damage to the unit, and/or electric
shock.
3. Super-bass sound reproduced by this unit may cause a
turntable to generate audio feedback. In this case, move
the unit away from the turntable.
4. This unit may be damaged if certain sounds are
continuously output at high volume level. For example,
if 20 Hz–50 Hz sine waves from a test disc or bass
sounds from an electronic instrument, etc. are
continuously output, or if a turntable stylus touches the
surface of a disc, reduce the volume level to prevent the
unit from being damaged.
5. If you hear distorted noise (i.e., unnatural, intermittent
“rapping” or “hammering” sounds) from this unit,
reduce the volume level. Extremely loud movie
soundtrack low frequency, bass-heavy sounds, or
similarly loud popular music passages can damage this
unit.
6. Vibration generated by super-bass sound may distort
images on a TV. In this case, move the unit away from
the TV set.
Precautions
This unit’s speakers use magnets. Do not place items that
are sensitive to magnetism, such as CRT-type TVs,
clocks, credit cards, floppy disks, etc., on or beside this
unit.
Information for users on collection and disposal of old
equipment:
This symbol on the products, packaging, and/
or accompanying documents means that used
electrical and electronic products should not
be mixed with general household waste.
For proper treatment, recovery and recycling
of old products, please take them to applicable
collection points, in accordance with your
national legislation.
By disposing of these products correctly, you
will help to save valuable resources and
prevent any potential negative effects on
human health and the environment which
could otherwise arise from inappropriate
waste handling.
For more information about collection and
recycling of old products, please contact your
local municipality, your waste disposal service
or the point of sale where you purchased the
items.
For business users in the European Union:
If you wish to discard electrical and electronic
equipment, please contact your dealer or
supplier for further information.
Information on Disposal in other Countries
outside the European Union:
This symbol is only valid in the European
Union. If you wish to discard these items,
please contact your local authorities or dealer
and ask for the correct method of disposal.
1 En
Make sure the package contains the following items.
Before you connect the speakers and subwoofer, place
them in its respective location. This positioning is very
important as it affects the overall sound quality of the
system. Place the speakers in locations that will
optimize the sound quality at your listening position.
Refer to the illustration.
The position of the subwoofer is not as critical as the
position of the other speakers because sub-bass
sounds are not very directional. Refer to “Installing the
subwoofer” on page 2 for more information.
Note
• Placing the speakers too close to a CRT-type TV
may impair the picture color or cause a buzzing
noise. In this case, move the speakers at least 20 cm
(8") away from the TV. This is not an issue with LCD
and plasma TVs.
Contents
Package contents................................................1
Installation ...........................................................1
Installing the front, center, and surround
speakers ...........................................................2
Wall-mounting the speakers................................2
Installing the subwoofer.......................................2
Method of connection....................................... 3
Connection diagram.............................................3
Connecting the power cables ..............................4
Troubleshooting ................................................. 4
Specifications...................................................... 4
Package contents
Speaker cable 24.5 m (80 ft.) x1
(To be cut into 6 lengths for the
front, center, and surround
speakers and a subwoofer. Take
care to prevent injury when
preparing the cables.)
Non-skid pads (24 pcs.) x1
(For the front, center and surround
speakers. Including 4 spare non-skid pads.)
Subwoofer
(NS-SWP40) x1
Center speaker
(NS-C40) x1
Non-skid pads: When
placing the speakers on
a flat surface, affix the
included non-skid pads
to the corners of the
speaker undersides, as
shown. The pads will
prevent the speaker
from moving around.
Non-skid pad
Front and surround
speakers (NS-B40) x4
Installation
Center
Front
right
Subwoofer
Surround
left
Front
left
Surround
right
