PEDAL TIMPANI

TP3300 series

TP3323 / TP3326 / TP3329 / TP3332

Owner’s Manual

Before using your timpani for the first time be sure to carefully

read the instructions on pages 6 and 7.“Initial Preparation”

Thank you for purchasing Yamaha Timpani.

Please read through this manual carefully as it contains

important information about your instrument’s care.

Contents

Precautions 2 ...........................................................

Nomenclature & Lubrication 3 ................................

Transporting and Setting Up the Timpani 4 ...........

Setting up the Timpani 4 ....................................................

Adjusting Pedal Height 5 ...................................................

Transporting ...................................................................5

Initial Preparation 6 ..................................................

Adjusting the Pitch 8 ...............................................

Head Tuning ...................................................................8

Pedal Adjustment ...........................................................9

Tuning Indicator Adjustment .............................10

Adjusting the Pointer Position .......................................10

Replacing the Head ............................................11

English

Handling caution

• Whenoperatingthepedal,donottouchthehoop,head,

ortuningindicator.Fingersmaybecomecaughtor

pinchedresultingininjury.

Tuning Indicator

Tuning bolt Head Hoop

Brake

PRECAUTIONS

PLEASE READ CAREFULLY BEFORE PROCEEDING

Please keep this manual in a safe and handy place for future reference.

WARNING

Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from

damages or other hazards. These precautions include, but are not limited to, the following:

Handling caution

• Neverleanonorclimbontheinstrument.Itmayoverturn

resultingindamageorinjury.

• Becarefularoundtheinstrument.Bumpingintoitmay

resultininjuryorcauseittooverturn.Keepsmallchildren

awayfromtheinstrument.

• Neverplaceyourfingersorfootintothemovingparts

orthespaceunderthepedalorbase.Seriousinjurycan

resultiffingersorfeetbecomepinched.

Transporting/Setup

• Neverplacethetimpanionunstablesurfacessuchasan

unstableriserorslopedsurface.Thetimpanimaytipover

orfallresultingindamageorinjury.

• Alwayslaytheinstrumentonitssidebeforeadjustingleg

height,orunfolding/foldingupthepedal.Theinstrument

canmoveorfalloverresultingininjury.

CAUTION

Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage to

the instrument or other property. These precautions include, but are not limited to, the following:

• Whenrollingthetimpanionitscasters,gripitbyitsframe

andmoveitonlyonsmooth,flatsurfaces.

1. Donotmoveonsloping,rough,orgravelsurfaces.

2. Donotrunwiththetimpani.Itmaybedifficulttostop

theinstrumentwhichcancauseinjuryordamage.

• Ifthetimpanimustbecarried,dosowithtwoormore

persons,makesuretogripthetimpanibyitslugs.

• Exceptforwhenmovingtheinstrument,

alwaysengagebothcasterbrakes.

Notengagingthebrakescanresultin

theinstrumentfallingoverormoving

resultingininjury.

• Replacetornheadsassoonaspossible.Thetornedgeof

theheadissharpandcancuthandsorfingers.

• Donotputyourhandsinsideanyofthepartsofthe

timpani(insidethetuningindicator,base,frame,etc.)

• Donotusethemalletforanythingbesidesplayingthe

instrument.

Donotallowchildrenstrikeotherswiththemalletasit

cancauseinjuryorbecomedamaged.

Yamahacannotbeheldresponsiblefordamagecausedbyimproperuseormodificationstotheinstrument.

Nomenclature & Lubrication

Supplied Accessories

• Tuning Key .......................................... 1

• Mallets ...........................................1 set

• Key/Wrench Holder ............................ 1

• Hex Wrench ........................................ 1

Tuning Bolt

n Lubrication

Apply a high quality grease or lubricant to the moving

parts indicated by the arrows in the diagram on the right.

This should be done at least once a year, or as needed.

* A spray type lubricant is recommended.

* Do not touch the lubricated parts.

* Please use Yamaha care products for daily mainte-

nance.

Head Protector

Pointer Lock Nut

Hoop (Counter Hoop)

Head

Kettle Edge

Caster

Base

Pointer Adjustment Knob

Tuning Indicator

Kettle

Pedal

Pedal Leg

Sliding Leg

n Nomenclature

Leg Lock Bolt

Lug

Caution

Never place your fingers or foot into the moving parts or

the space under the pedal or base.

Serious injury can result if fingers or feet become pinched.

Spring Tension

Adjustment Bolt
