operator’s manual rev. 1973/2.0
quadruple
envelope
generator
Model of 1973
Thank you for purchasing this Xaoc Devices
product. Zadar is a powerful, four-channel en-
velope, modulation, and transient generator,
in a compact yet very complete, feature-rich
package. It is capable of synthesizing a vast
palette of envelope shapes starting from hun-
dreds of shapes stored in the memory. These
starting shapes are not mere wavetables, but
ξ”ξ‚Žξ‚‡ξ‚šξ‚‹ξ‚„ξ‚Žξ‚‡ξ€ƒ ξ‚˜ξ‚‡ξ‚…ξ‚–ξ‚‘ξ‚”ξ‚•ξ€ƒ ξ‚–ξ‚Šξ‚ƒξ‚–ξ€ƒ   ξ‚•ξ‚–ξ‚”ξ‚‡ξ‚–ξ‚…ξ‚Šξ‚‡ξ‚†ξ€ƒ ξˆ‹ξ‚ˆξ‚”ξ‚‘ξ‚ξ€ƒ
a fraction of a millisecond to half an hour),
ξ”ξ‚Žξ‚‹ξ‚’ξ‚’ξ‚‡ξ‚†ξ‡‘ξ€ƒ   ξ‚†ξ‚‡ξ‚Žξ‚ƒξ‚›ξ‚‡ξ‚†ξ‡‘ξ€ƒ ξ‚•ξ‚Šξ‚—ξ‚ˆξ”ξ‚Žξ‚‡ξ‚†ξ‡‘ξ€ƒ
repeated, and amplitude modulated in real
time. A set of freely assignable CV inputs allows
for external control of most parameters. Each
channel can work independently or combined
with other channels within one of the chaining
and looping algorithms. Operating Zadar is
quick and immediate, thanks to its accessible
interface and crisp OLED display. The main
screen displays all parameters together with
the currently selected shape. Entering the sim-
ple 3-page menu (4 pages with Nin expander
installed) is needed only for advanced settings.
The module requires 10hp worth of free space in
the eurorack cabinet. The ribbon type power ca-
ble must be plugged into the bus board, paying
close attention to polarity orientation. The red
stripe indicates the negative 12V rail and should
align with the dot, or marks –12V red stripe
on both the unit and the bus board. The module
itself is secured against reversed power connec-
ξ‚–ξ‚‹ξ‚‘ξ‚ξ‡‘ξ€ƒξ‚Šξ‚‘ξ‚™ξ‚‡ξ‚˜ξ‚‡ξ‚”ξ€ƒξ‚”ξ‚‡ξ‚˜ξ‚‡ξ‚”ξ‚•ξ‚‹ξ‚ξ‚‰ξ€ƒξ‚–ξ‚Šξ‚‡ξ€ƒξ·ξΌξ‡¦ξ‚’ξ‚‹ξ‚ξ€ƒξ‚Šξ‚‡ξ‚ƒξ‚†ξ‚‡ξ‚”ξ€ƒmay
cause serious damage to other components
of your system by short-circuiting the +12V and
+5V power rails. The module should be fastened
by mounting the supplied screws before pow-
ering up. To better understand the device, we
strongly advise the user to read through the en-
tire manual before using the module.
Each shape is a vector curve comprising 3 to
1000 breakpoints, and each segment interpo-
lates between those breakpoints in real time.
This method allows the shapes to be scaled
from a fraction of a millisecond to half an hour,
without any stepping artifacts that would oth-
erwise be caused by undersampling. Similar to
vector graphics, these synthesized envelopes
 ξ‚‹ξ‚ξ”ξ‚‹ξ‚ξ‚‹ξ‚–ξ‚‡ξ‚Žξ‚›ξ€ƒ ξ‚•ξ‚…ξ‚ƒξ‚Žξ‚ƒξ‚„ξ‚Žξ‚‡ξ€ƒ  ξ‚–ξ‚Šξ‚‡ξ‚”ξ‚‡ξ‚ˆξ‚‘ξ‚”ξ‚‡ξ€ƒ ξ‚Šξ‚ƒξ‚˜ξ‚‡ξ€ƒ -
ξ”ξ‚‹ξ‚ξ‚‹ξ‚–ξ‚‡ξ€ƒξ‚”ξ‚‡ξ‚•ξ‚‘ξ‚Žξ‚—ξ‚–ξ‚‹ξ‚‘ξ‚ξ‡€ξ€ƒξ€—ξ‚Šξ‚‹ξ‚•ξ€ƒξ”ξ‚Žξ‚‡ξ‚šξ‚‹ξ‚„ξ‚Žξ‚‡ξ€ƒξ‚ƒξ‚’ξ‚’ξ‚”ξ‚‘ξ‚ƒξ‚…ξ‚Šξ€ƒξ‚ƒξ‚Žξ‚Žξ‚‘ξ‚™ξ‚•ξ€ƒ
shapes to be smooth when you want them to be
smooth and sharp when you want them to be
sharp β€” regardless of time scale.
ξ€šξ‚‹ξ‚–ξ‚Šξ‚‹ξ‚ξ€ƒξ‚–ξ‚Šξ‚‡ξ€ƒξΈξ‡€ξΆξ€ƒξ”ξ‚‹ξ‚”ξ‚ξ‚™ξ‚ƒξ‚”ξ‚‡ξ€ƒξ‚”ξ‚‡ξ‚˜ξ‚‹ξ‚•ξ‚‹ξ‚‘ξ‚ξ‡‘ξ€ƒξ‚–ξ‚Šξ‚‡ξ‚”ξ‚‡ξ€ƒξ‚ƒξ‚”ξ‚‡ξ€ƒξΈξ½ξΆξ€ƒ
different shapes organized into 27 banks of 10
shapes. They have been carefully designed to
suit a wide range of use, from essential synth en-
velopes to complex transients, from modulation
cycles to rhythmic patterns, from quasi-random
modulations to perfectly regular functions, from
natural envelopes extracted from a variety of
acoustic and electronic instruments to fractal
abstractions and sequences. Several renowned
artists have been invited to contribute extra
β€œsignature” shape banks (see the separate chart
for a graphical representation of each shape).
The essential feature of Zadar is that the vector
ξ‚•ξ‚Šξ‚ƒξ‚’ξ‚‡ξ‚•ξ€ƒξ‚…ξ‚ƒξ‚ξ€ƒξ‚„ξ‚‡ξ€ƒξ‚‡ξ‚ƒξ‚•ξ‚‹ξ‚Žξ‚›ξ€ƒξ‚ξ‚‘ξ‚†ξ‚‹ξ”ξ‚‹ξ‚‡ξ‚†ξ€ƒξ‚ƒξ‚ξ‚†ξ€ƒξ‚ξ‚‘ξ‚†ξ‚—ξ‚Žξ‚ƒξ‚–ξ‚‡ξ‚†ξ€ƒξ‚‹ξ‚ξ€ƒ
a variety of ways β€” in fact, some have been de-
liberately designed to be deformed. Many of the
complex shapes are intended for long, evolving
envelopes (for example bank x), while others
may serve better as snappy transients or reso-
nator exciters (like bank u).
module
explained
front panel
overview
fig. 1: interface
