Seite 1/6

utility micro

sequencer ii

Model of 1960

operator’s manual rev. 1960/2.0

Thank you for purchasing this Xaoc Devices

product. Tirana is a compact, expandable volt-

age source with a wide range of uses including

classic step sequencer, modulation source, volt-

age bank, and arpeggiator.

Tirana is equally suited to small and large sys-

tems alike, either as a single utility or chained

with more Tirana units. This is a second, vastly

improved revision to the original 2014 Tirana,

featuring an updated circuit and a new, more



The module requires 6hp worth of free space

in the eurorack cabinet. The ribbon type pow-

er cable must be plugged into the bus board,

paying close attention to polarity orientation.

The red stripe indicates the negative 12V rail

and is supposed to match a dot, or –12V red

stripe marks on both the unit and the bus

board. The module itself is secured against

reversed power connection, however revers-

ing the 16-pin header may cause serious

damage to other components of your system,

because it will short-circuit the +12V and +5V

power rails. The module should be fastened by

mounting the supplied screws before power-

ing up. To better understand the device, we

strongly advise the user to read through the

entire manual before using the module.

To operate, Tirana expects an external clock

source (up to 320Hz) in the clock input sock-

et . Patching any stable clock generator—

such as an LFO pulse or another sequencer’s

sync output—causes the sequence steps to

play sequentially in a loop. The value for each

step is adjustable by turning knobs 1-4 . By

default, the voltage set by the knob is unipolar

and within the 0V to 10V range. The jumper

on the back of the module allows for the

selection of bipolar voltages within –5 to +5V

range. Another jumper attenuates the volt-

age range to 0V to 5V and –2.5V to +2.5V re-

-

ages and gate/trigger impulses are available

at cv out and gate outputs.

       

pressing the corresponding button until its

light deactivates. Muting a step does not note:

remove the step from the sequence. The control

voltage remains present for the selected step,

and only the gate/trigger itself is muted.

Sequence direction can be changed by patch-

ing a trigger impulse into the directn input

socket . Sequence can be reset to step 1

by patching a trigger impulse into the reset

input . Sequence can be transposed (offset)

by patching a control voltage into the transp

input .

Hold step 1 and step 4 buttons simultane-

ously for 2 seconds to change whether the

gate output generates a gate or trigger im-

pulse. note: Dynamic gate width modulation

is possible because Tirana’s gate width directly

matches that of the external clock impulse.

Each step can be multiplied (repeated) up to

four times (resulting in up to 16 steps in the se-

quence). The note length is retained upon repeat.

Alternatively, each step can be divided to achieve

the popular ratcheting effect. The trigger/gate

impulse is generated 2, 3 or 4 times per note. To

program these events on a given step, enter the

step menu as follows:

module

explained

fig. 1

controls

overview

To set a desired number of repeats for a given

step, enter the div·mlt menu by holding the

corresponding step’s button for 2 seconds. The

number of repeats is indicated by one blinking

button and three unlit buttons. Press step 2

for one repeat (2 total triggers), step 3 for

two repeats (3 total triggers), or step 4 for

three repeats (4 total triggers) of the given

step. To reset the desired step back to a single

trigger, press cancel (step 1 button). Tirana

automatically exits the div·mlt menu mode

once a choice is made.

To set a desired number of ratchets for a given

step, enter the div·mlt menu by pressing the

corresponding step’s button for 2 seconds. The

number of divisions is indicated by one blinking

button and three unlit buttons. Hold step 2 for

two triggers (step divided by 2), step 3 for three

triggers (step divided by 3), or step 4 for four

triggers (step divided by 4) within the given step.

fig. 2
