Seite 1/12
1
RoadTripยฎ MinimaxTM
Stationary
Automatic Satellite TV Antenna
Model RT8000S (white dome)
Model RT8035S (black dome)
WINEGARDยฎ
Printed in U.S.A. ยฉ Winegard Company 2009 2452185 rev1 8-09
Made in the U.S.A.
PRODUCT REGISTRATION
Please register your Winegard product by ๎ฟlling
out and returning the Product Registration card
provided or by completing the online registration
form at http://www.winegard.com/registration
Serial No.
May also be packaged as:
RTS-80W (white dome) or RTS-80B (black dome)
2
Parts Included โข Tools Needed โข Unpacking the Unit
1 Dome
1 base with electronics, dish, dual LNBF
*Aftermarket versions also include all mounting hardware and cabling required for a
single receiver installation
PARTS INCLUDED*:
USE 2 PEOPLE
when removing the unit
from the carton.
!DO NOT PAINT DOME!
Painting dome will cause
signal degradation and
will void your warranty.
TOOLS NEEDED FOR UNPACKING & INSTALLATION:
Level
Drill with 3/4โ bit
1-1/4โ hole saw (if mounting switch in wall)
Phillips screw driver #2
3/8โ Open end wrench
7/16โ Open end wrench
Sealant (consult RV manufacturer for proper type
for your roof material)
Trademarks:
Winegard and RoadTrip Minimax are registered trademarks of Winegard Company. DISH Network is a registered
trademark of EchoStar Communications Corp. DIRECTV is a registered trademark of Hughes Electronics Corp.
All trademarks contained in this manual are property of their respective owners. Reference made to products or
services provided by companies, other than Winegard Company, does not represent any endorsement of those
products or services.
Disclaimer:
Although every effort has been made to insure the information in this manual is correct and complete, no company
shall be held liable for any errors or omissions in this manual. Changes and technological advances are continu-
ously being made in the satellite market. Information provided in this manual was accurate at the time of printing.
If the RoadTrip Minimax does not function as expected, please contact Winegard Company at (800) 788-4417 or
visit our website at www.winegard.com.
For Winegard Warranty Information:
Attn: Technical Services
Winegard Company
3111 Kirkwood St.
Burlington, IA 52601
800-788-4417
Fax: 319-758-5854
1. Open box and remove packing material.
!If using knife to open
carton, BE CAREFUL.
Do not cut the dome on
the unit.
UNPACKING THE UNIT:
2. Lift unit out of box vertically. Do not turn box
and โrollโ out, or turn upside down to remove.
3
FIGURE 1
4. After selecting location for unit (see Step 2), place
the unit on the centerline of the vehicle.
5. Position base so that cables exit toward the rear of
vehicle.
The distance from the edge of the roof to the rear cor-
ner of any foot should be at least 12โ on both sides of
the dish to ensure proper installation.
Hybrid Mode settings are for use in areas where the
standard DISH Network settings fail to provide HD
programming.
Quick Reference Guide
This model is PRESET for DIRECTV receivers.
If you have a receiver, you must change DISH Network BELL TV or
the numbered switches (see ๎ฟgures below).
TO CHANGE SWITCH SETTINGS FOR DISH
NETWORK. SIMPLY MOVE #4 & #7 TO DOWN
POSITION (#8 SHOULD REMAIN DOWN
ALSO).
๏
๏
๏
๏
๏
๏
1 2 3 4 5 6 7 8
๏
DIRECTV DISH NETWORK
FACTORY PRESET
DIRECTV SWITCH SETTINGS
๏ ๏ ๏ ๏ ๏ ๏ ๏ ๏
1 2 3 4 5 6 7 8 0 = UP
1 = DOW N
KEY
๏
๏
๏
BELL TV
๏
๏
๏
๏
1 2 3 4 5 6 7 8
๏
๏
๏
๏
DISH NETWORK HYBRID
๏
๏
1 2 3 4 5 6 7 8
๏ ๏ ๏ ๏ ๏
๏
!Install in DRY conditions only!
Installing unit on roof of vehicle โ
Obstruction Ht. Unit Clearance
8โ .....................................15โ
10โ ...................................20โ
12โ ...................................25โ
15โ ...................................35โ
IMPORTANT! Do not install this system in the rain, or
under any wet conditions. Moisture may affect electron-
ics and void your warranty!
1. For best performance and to reduce signal acquisi-
tion time, park vehicle on a level surface; level the RV.
2. Select a level spot on your roof for installation.
WARNING: Level the base front to back and side to
side. If base is not level the antenna may require more
time to locate the correct satellite or may not locate the
correct satellite.
3. Ensure proper distance to other rooftop equipment is
maintained.
Be sure no roof-mounted equipment is blocking the
satellite โline of sightโ; see chart below.
Using this chart, determine the minimum distances to
other equipment.
At least 12โ
At least 12โ
RoadTrip Minimax
MUST Face FRONT
of Vehicle
FIGURE 2
FRONT OF VEHICLE
Cable connections
MUST face REAR
OBSTRUCTION
UNIT BASE
23 4 5
