PEDAL POWER 3®
Please register your Voodoo Lab product at voodoolab.com/register
If you have questions about this product, contact us at info@voodoolab.com
For the most up-to-date manual and information go to voodoolab.com/pedalpower_3
INTRODUCTION
Congratulations! You’ve purchased the finest fully isolated pedalboard power supply available. The
Voodoo Lab Pedal Power 3 is the culmination of years of research and experimentation. The result sets
new benchmarks in lowest noise, compact size, light weight, and total flexibility where every output
powers the most sensitive vintage analog stompboxes with zero noise and optimum tone, as well as
power hungry, high current digital effects.
A novel DC transformer design combines state-of-the-art organic polymer and ceramic filters with
traditional analog linear voltage regulation to achieve it’s industry leading zero noise performance.
Pedal Power 3 is the ultimate pedalboard power solution. It’s expandable up to 24 isolated outputs
with Voodoo Lab Pedal Power X4 and X8. Pedal Power 3 operates at all line voltages from 100-240VAC,
so you’re ready for international touring without step up/down transformers. You can even power 18V
and 24V pedals with optional voltage doubler cables.
Pedal Power 3 is made in the USA.
UNPACKING
Your Voodoo Lab Pedal Power 3 box contains the following:
Pedal Power 3 isolated DC power supply
AC line cord
DC power cables
CONNECTIONS
Important! DC power cables with a red or white plug end are reverse polarity. Almost all pedal effects
are standard polarity, using the wrong cable may damage them.
Pedal Power 3 is powered directly from 100-240VAC mains using the supplied region-specific AC line
cord. This is a standard computer-type IEC line cord, so it’s easy to obtain a replacement or different
length. For international touring simply use a plug adapter or the correct cable for that country.
Before connecting power to your pedals, verify that they require 9 or 12VDC and standard center
negative polarity. Then use any of the included cables with black plug ends. Otherwise, obtain the
correct cable and voltage adapter if necessary.
(1) X-LINK expansion ports. These power X-series expanders to add more isolated outputs.
(2) LED Status Indicator - Steady ON during normal operation.
(3) 9V/12V isolated DC outputs. Each output supplies up to 500mA @ 12V and 200mA @ 9V.
(4) 9V isolated DC outputs. Each output supplies up to 500mA.
(5) AC power input jack. Standard “IEC-type” connector accepts any mains voltage 100-240VAC.
AVAILABLE DC POWER CABLES AND ADAPTERS
Voodoo Lab can supply cables with different lengths, connectors or polarity. These and many more are
available at voodoolab.com or from your Voodoo Lab retailer.
Output Splitter: Allows two pedals to share a single isolated output. One side is ground lifted to
minimize interaction between the pedals (Part# PPAV)
Voltage Doubler Adapter: Combines voltages of two isolated outputs to power 18V and 24V
pedals (Part# PPAY). Also available as an all-in-one Voltage Doubler cable (Part# PPY)
Current Doubler Adapter: Combines current supply of two isolated outputs to power effects
requiring more than 500mA (Part# PPAP)
Line-6 HX Cable: Combines current of two isolated 9V outs to power Line 6 HX Effects and HX
Stomp (Part# PPHX)
Battery Snap Cable: Powers older vintage pedals without a DC power jack (Part# PPBAT or
PPBAT-R)
Pedal Power Replacement Cable Kit: Complete cable kit for Pedal Power 3 (Part# PPPK-3)
Voodoo Lab cables have color coded plug ends for easy identification. Black are standard polarity
(center negative) with 2.1mm center. Blue are standard polarity with larger 2.5mm center. White are
reverse polarity (center positive) with 2.1mm center, and red are reverse polarity with 2.5mm center.
USING X-LINK EXPANSION PORTS
X-LINK expansion ports are used to add isolated DC outputs to Pedal Power 3. Connect to any Pedal
Power X-series supply including X4 (4x9V), X4/18V (2x9V, 2x18V) and X8 (8x9V).
It is preferred to run high current digital pedals directly from Pedal Power 3.
These 12V expansion ports are unfiltered and not isolated from each other. They are not intended to
directly power sensitive analog effects.
PEDALBOARDS
Voodoo Lab Dingbat pedalboards are designed with integrated mounting for all Voodoo Lab power
supplies including Pedal Power 3. Made from high grade aluminum in Sonoma county, California, they
are rugged, lightweight and include a tour ready gig bag.
Also available are Voodoo Lab mounting brackets (Part# PT) for most Pedaltrain models except Nano
and Metro. These are high quality aluminum brackets with stainless steel self-drilling screws for easy
installation.
WARRANTY (North America Only)
Voodoo Lab warrants this product against defects that are due to faulty material or workmanship for a
period of five years from the date of original retail purchase. This warranty does not include damage to
the product resulting from accident or misuse. This warranty is given to the original purchaser only and
it is not assignable to any other person.
If the product should become defective within the warranty period, Voodoo Lab will repair it or replace
it free of charge, provided it is returned freight prepaid to Voodoo Lab with a valid RMA (return
material authorization) number.
This warranty shall not apply to any goods that have been repaired or altered by anyone other than the
manufacturer. There are no warranties which extend beyond the terms described herein. Should you
experience any difficulty with this Voodoo Lab product, contact us as described below. If it is
determined that the product must be returned to the factory for repair, you will be issued an RMA and
given shipping and packaging instructions.
Outside North America
Regions outside North American please contact your country’s distributor for warranty information.
