Instruction Manual for the
and
Do not le a ve the o ptical tube uncapp e d in the daytime . Sunlight pa ssing thro ugh the telescope or find e r scope may cause a fire.
Do not use the product while moving or walking, injuries could result from a collision with objects or from stumbling or falling.
Keep sm all caps, plastic bags, or plastic packing materials away from children. These may ca use a danger of swallowing or suffocation.
Do n ot use th e p rod uct in a w e t e nvir on me n t a nd do no t ha nd l e wi t h w et h an ds.
Do not le a ve the p roduct inside a ca r in brigh t sunshine , or in o ther h o t places. Keep any s t r ong h e at sour ces away f r om th e prod u ct.
When clea n ing, do n ot use s o lvents such as paint t hinner o r similar produ c ts.
Do not e xpose th e prod u ct to ra in, water, dirt or sand.
Avoid touching an y lens or mirro r surfa c e s directly with your h ands. In case a le n s or m irror b ecome s dirty with fin g erpr in ts or ge neral
smears, gently wipe it using a commercially available lens cleaner and a le ns cleaning pa per or cloth, or consult your local Vixen dealer.
Blow off dust on lense s using a co mmer cially available b lower br ush.
For s t orage , keep th e prod uct in a d r y place a nd do n ot expose to dire c t sunlight.
●
●
●
●
●
●
Never look directly at the sun with the telescope or its finder or guide scope.
Permanent and irreversible eye damage may result.
Th a n k you v ery much for y o ur p urcha s e of a Vi x e n cata d ioptr ic re flecto r.
This manual applies to the VMC200L and VC200L telescopes. ou may occasionally find descriptions in the text not relevant Y
to your particular model. The specifications in English are for export models and supplied accessories are different from the
Japanese domestic models.
Re ad th e ins t ructi o ns fo r your mo unt a long with this man u al if you p u rchas e d the tele s c o p e as a complete packag e .
CAUTION
HANDLING ORAGEAND ST
Attaching the Telescope to the Mount
Lo o s en b o t h the d o ve t a i l-pl a t e
lock screw and safety screw until
the tips of these screws no longer
extended into the inner part of the
dovetail block.
Slide the dovetail mounted scope
into the dovetail mounting block as
shown in the figure. ighten the T
dovetail lock screw (centered on
the notch) onto the dovetail slide
bar until snug.
First tighten the dovetail lock screw,
and then tighten the small chrome
s a fe t y s c r e w o n th e do v e t a i l
mounti n g bl o c k unti l snug .
Attaching the Finder Scope
(Finder Scope and Finder Bracket
may be optional at your particular
model.)
Loosen the finder bracket lock screw
on the telescope's finder bracket
shoe. Attach the finder scope as
shown in the figure and tighten the
finder bracket lock screw securely.
WARNING!
SETTING UP THE TELESCOPE
PREFACE
Refer to your mount instructions along with this manual.
Optical ubeT
Metal Carry Handle
Finder Bracket Shoe
Finder Bracket Lock Screw
Safety Screw
Figure (SXD2 mount and VMC200L optical tube shown here.)
Lock Screw
Flip Mirror
Finder Scope
Finder Adjustment
Screws
Finder Bracket
Focus Knob
Drawtube
Drawtube Lock Screw
Dovetail Slide Bar
5
OPT IONAL ACCESSORY CHART
You may need an eyepiece as sold separately. The telescope
d o e s n o t c o m e w i t h t h e e y e p i e c e a s s t a n d a r d a c c e s s o r y
un l e s s you p urcha s e d a p a ckage.
Ma gnificat io n of t h e Teles cop eVisu al C onfigu ra tio n
W h e n u s i n g a n e y e p i e c e w i t h s h o r t f o c a l l e n g t h
(small number in millimeters), the image will be dim
and the range of sharp focus will be small.
The i ma g e w i l l be h a r d e r to s e e s o b e g i n with a n
eyepiece with long focal length (low magnification).
Dividing the focal length of the telescope by the focal
length of the eyepiece gives the magnification.
Focusing the Telescope
Look into the eyepiece. The image will likely be out of
focus at first. urn the focus knob slowly clockwise or T
counterclockwise to find a point where the image in
the field of view of the eyepiece becomes sharpest.
Eyepiece Focal length of telescope ÷ Focal length of eyepiece ＝ Magnification
S L ÷ ＝ 98xV20m m 1950m m 20mm
S LV m ÷ 5 ＝ 217x 5mm 1950m m m
EA60mm to 50.8mm SX, or 50.8mm
Compression Ring (Supplied)
EA60mm to 50.8mm SX,
or 50.8mm Compression
Ring (Supplied)
Extension Tube VC
Eyepiece
31.7mm
Eyepiece 31.7mm
Eyepiece 50.8mm
Flip Mirror Diagonal
Fo cusi n g T en sio n
Adju stm ent Scr e w
(Us e to ho ld t he
dr awt ube tig htly .)
Example: Calculating the eyepiece magnification of a telescope
with 1000mm focal length.
OPT IONAL ACCESSORY CHART
So me of t h e opt ional a ccessori e s shown in this c h art wil l be n e eded i f you take p ictur e s wi th ( D)S LR c a me ra,
compact digit a l camera or CCD vid e o camera.
Phot o grap h ic Configu ra tio n
Focus knobFocus knob
Vixen
VMC200L
VC200L
EA60mm to 50.8mm SX,
or 50.8mm Compression
Ring (Supplied)
Eyepiece Projection Photography
Digiscoping Photography
Prime Focus Photography
T-C Ring
Digital Camera Quick Bracket II
(D)SLR
Camera
T-Ring
(Appropriate
to your camera.)
Vixen NPL,NLV or SLV
Eyepiece 31.7mm
Compact Digital
Camera
/ Digital Video
Camera
LCD / TV MonitorCCD Imaging Camera
(with C-mount)
EA42mm to
31.7mm SX
(Part of Flip
Mirror Diagonal)
Flip Mirror Diagonal
Eyepiece Projection Camera Adapter
6
