Seite 1/39
104921,104931
104941
MODEL SKU LUMENSWATTS BODY
TYPE
TOTAL
CURRENT
INPUT
VOLTAGE
LIFE
SPAN
ON/OFF
CYCLE
SHAPE DIMENSION
(LxWxH)
BEAM
ANGLE
IP
RATING CRI
Sphere
360°
Sphere
360°
Sphere
360°
Sphere
360°
AC:220-240
50/60Hz
AC:220-240
50/60Hz
AC:220-240
50/60Hz
AC:220-240
50/60Hz
φ288.6x31.2mm
φ167.4x30.7mm
φ215.6x30.8mm
φ121.2x30.6mm
120.8x120.8x30.7mm
167.3x167.3x30.7mm
214x214x31mm
285x285x30.7mm
20000H >15000
20000H >15000
20000H >15000
20000H >15000
ROUND
SQUARE
SQUARE
SQUARE
SQUARE
ROUND
ROUND
ROUND
36mA
71mA
103mA
160mA
PLASTICIP20 >80
>80
>80
>80
IP20
IP20
IP20
PLASTIC
PLASTIC
PLASTIC
660Lm
1200Lm
1850Lm
1980Lm
2640Lm
2500Lm
6W
12W
18W
24W
VT-60006
VT-60012
VT-60018
VT-60024
LED BACKLIT SURFACE MOUNTED PANEL
TECHNICAL DATA
INTRODUCTION & WARRANTY
WARNING
INSTRUCTION MANUAL
'This product contains a light source of energy eciency class <F/E>', where <F/E> shall be replaced by
the energy eciency class of the contained light source.
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instruc-
tions carefully before starting the installation and keep this manual handy for future reference. If you have any
another query, please contact our dealer or local vendor from whom you have purchased the product. They
are trained and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The
warranty does not apply to damage caused by incorrect installation or abnormal wear and tear. The company
gives no warranty against damage to any surface due to incorrect removal and installation of the product. The
products are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the
warranty. This product is warranted for manufacturing defects only.
• Please make sure to turn o the power before starting the installation.
• Installation must be performed by a certified person.
• If the external flexible cable or cord of this luminaire is damaged, it shall be
exclusively replaced by the manufacturer or his service agent or a similar
qualified person in order to avoid a hazard.
• Method of attachment of the cable or cord such that any replacement can
only be made by the manufacturer, his service agent or similar qualifed
person.
• For Indoor use only.
SPHERE
STAYS BRIGHT
360°
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
78701,78711
78721
104951, 104961
104971
78731, 78741
78751
104981,104991
105001
78761,78771
78781
105141,105161
230231
78791,78801
78811
1.Switch OFF the power before
starting the installation
2.Confirm the installation
position of the bracket 3.Drill a hole.
4.Plug in expansion bolt.
5.Fix the bracket ( Included)
on the ceiling with screws.
SURFACE PANEL INSTALLATION DIAGRAM
ATTENTION!
USAGE GUIDELINES/MAINTENANCE
MOUNTING
Do not look directly at LED light beam. Product can only be supplied by rated voltage or voltage within
the range provided. It's forbidden to use the product with damaged protective cover. Product must not be
used in unfavorable conditions, e.g. dust, water, moisture, vibrations, explosive air atmosphere, fumes, or
chemical fumes, etc. In the area of strong electromagnetic interference, the functioning of the product
may be disrupted.
Any maintenance work must be performed when the power supply is cut o and the product has cooled
down. Clean only with so and dry cloths. Do not use chemical detergents. Do not cover the product.
Ensure free air access. Product may heat up to a higher temperature.
Read the manual before mounting. Mounting should be performed by a qualified electrician. Exercise
caution. Product has a protective contact /terminal. Failure to connect the protective lead may lead to
electric shock. Mounting diagram: see pictures. Check for proper mechanical
fastening and connection to electrical power prior to first use.
This marking indicates that this
product should not be disposed
of with other household wastes.
Replaceable (LED only)
light source by a professional
Caution, risk of electric shock.
1.Power o, tap the central area of the
diusion plate with a pointed tool, and
take out the cracked diusion plate
2.Remove the power wire from the
plug terminal
3.If there is no hot melt column in the
lamp body or the hot melt column is
not hot melt,this step will be adjusted
without treatment.If the hot-melt column
has been fused to fix the aluminum
substrate,cut the hot-melt part of the
hot-melt point with diagonal pliers.
4.Press the buckle outwards,
remove the aluminum substrate
pressing strip from the bayonet,
and remove the pressing strip.
This step is only required for
24W panel light, other items are
not required.
5.Press the buckle outwards,
remove the aluminum substrate
from the buckle, and remove
the light source board.
6.Take out two-cord cable (wire diameter
18-22AWG) and insert it into the plug-in
terminal. Connect the external power
supply for testing.
DISASSEMBLY DIAGRAM
(For Market surveillance team only)
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC
EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
Note: Light source removal will void the warranty
