Seite 1/3
INSTRUCTION MANUAL
LED FLOOD LIGHT
TECHNICAL DATA
MODEL VT-44034 VT-44053
SKU 23462 23463
POWER 30W 50W
LUMENS
@WIDE CONE 2310 Lm 4000 Lm
INPUT VOLTAGE AC: 220-240V, 50Hz
DF >0.9
CRI 70
EFFICIENCY 90+ Lm/w
LIFE SPAN 25,000 Hours
`
ON/OFF CYCLE 15,000 Times
BEAM ANGLE 115°
OPERATION
TEMPERATURE -20°C to +40°C
BODY TYPE Aluminium
MAX.MOUNTING
HEIGHT <5 M
WIRE LENGTH 0.15 M
REMOTE RANGE ≤8-10 M
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
toaccess the manual in
multiple languages.
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
*This product contains a light source of energy
eciency class<F>,where <F> shall be replaced
by the energy class of the contained light source.
NET WEIGHT 0.35Kg 0.48Kg
PROJECTED AREA
(mm2)25168.5 31011.5
DIMENSION 164.5x34x153mm 183.5x34x169mm
This marking indicates that this product
should not be disposed of with other
household wastes.
Caution, risk of electric shock.
Replaceable (LED Only) light
source by a professional
INSTALLATION DIAGRAM
INSTALLATION INSTRUCTION
• DO NOT USE IN AREAS WITH LIMITED VENTILATION OR OUTSIDE THE RATED AMBIENT TEM-
PERATURE RANGE. *CON- NECT WITH WATERPROOF CABLE HOUSE ONLY. *ENSURE ELEC-
TRICITY IS SWITCH OFF BEFORE INSTALLATION.
• Please do not mount to a surface that is prone to vibrations .*
Remove the screw and the bracket aerward. (Figure 1)Before drilling, mark the hole position for
fixing the bracket onto the wall (Screw not supplied). (Figure 2)
• Screw the retaining bracket to the wall with a suitable quantity of screws. (Figure 4)
• Mount the bracket back to the fixture. Adjust the floodlight according to the desired position.
Tighten the screw. (Figure 5) Connect your main cable (HO5RN-F3G1.0mm2 Recommended)
with the input lead of our product through the waterproof junction box. Note, the line (-) of the
lead. (Need to use the junction box of IP65 or above, ensure to tighten the waterproof screw)
Switch on the power to make sure if the product is working.
WARNING
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. If the external flexible cable or cord of this luminaire is damaged, it shall be
exclusively replaced by the manufacturer or his service agent or a similar
qualified person in order to avoid a hazard.
4. Replace any cracked protective shield.
5. Terminal block not included.
6. Proper grounding should be ensured throughout the installation.
7. Minimum distance from lighted objects 1m.
8. Limitation of use indoors and outdoor.
NOTE: To reduce the risk of strangulation the flexible wiring connected to this luminaire shall be eectively
fixed to the wall if the wiring is within arm’s reach.
DISASSEMBLY DIAGRAM
REMOTE CONTROL FUNCTIONS
For Market surveillance team only
Note: Light source removal will void the warranty
REMOTE CONTROL FUNCTIONS
On O
Increase
Brightness Red
Decrease
Brightness Blue
6500K Green
Red,Green & Blue
alternating rapidly
flashing
Red,Green & Blue
alternating slow
flashing
Red, Green & Blue
Mixed alternating
Red, Green & Blue
Breathing state
Multiple
Color Options

Produktspezifikationen

Marke: V-TAC
Kategorie: niet gecategoriseerd
Modell: VT-44053
